Please ensure the Owner's Manual stays with the unit at all times.
Owner's Manual

Advertisement

Table of Contents
loading

Related Manuals for EasyStand Altimate Medical Zing

Summary of Contents for EasyStand Altimate Medical Zing

  • Page 1 Please ensure the Owner’s Manual stays with the unit at all times. Owner’s Manual...
  • Page 2 SYMBOL LEGEND ENVIRONMENTAL CONDITIONS CAUTION/ATTENTION DATE OF MANUFACTURE PINCHPOINT SEE INSTRUCTIONS FOR USE SERIAL NUMBER MANUFACTURER Please be environmentally responsible and recycle this product through your recycling facility at its end of life. Afin de préserver l’environnement, veuillez confier ce produit à votre centre de recyclage à la fin de sa durée de vie.

  • Page 3: Introduction

    Introduction Congratulations on your purchase of the Zing standing frame. We at Altimate Medical have designed the Zing with your needs in mind. ZING Description The Zing line of products is intended for individuals who are able to transfer with assistance from a caregiver and/or lifting device.

  • Page 4: Safety Precautions

    Safety Precautions • Please read and understand all safety precautions and user instructions prior to use. Call Altimate Medical at 800-342-8968 or 507-697-6393 with any questions or for additional information. • If a user does not meet the specifications below and has not been properly fitted by a qualified therapist or physician, Altimate Medical, Inc., does not recommend using the Zing.

  • Page 5: Table Of Contents

    Table of Contents Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Safety Precautions .

  • Page 6: Assembly

    Assembly 1. Remove the base from the box and position as shown. 2. Spread the three legs out and position as shown. Caution: Beware of pinch point between handle and the rear leg. 3. Lock the center mechanism by pushing down on it to lock the snap pin into position.
  • Page 7 4. Locate the rubber washer on each of the abduction bolts. 5. Remove only the rubber washer on both abduction bolts and discard. 6. Place each medium size knob from the parts bag onto each bolt as shown. Page 4...
  • Page 8 7. There are 4 pads, 3 pads have straps on them, they are the pelvic support pad, supine upper body support pad and prone upper body support pad. The other pad without the strap is the head sup- port. Remove 2 bolts from the parts bag and place one of the pads with the strap on to the unit as shown.
  • Page 9 10. Remove 2 small knobs and washers from the parts bag. Place washer onto the tray bracket as shown. 11. Place knob onto tray bracket, only start the threads, you will tighten the knob later on. Repeat steps for other side of the tray bracket. 12.
  • Page 10 13. Place the head support bracket into the tube as shown. Depress the spring button. 14. While supporting the head support bracket, place one of the large knobs from the parts bag onto the unit as shown. Tighten securely. 15. Remove 2 bolts from the head support pad (the head support pad does not have straps).
  • Page 11 16. Place the head support pad bracket into the tube on the head support bracket as shown and tighten knob securely. 17. Using the lever with one hand and supporting the unit with your other hand, position the unit as shown.
  • Page 12 19. Place knee into position and tighten knobs securely. Repeats steps 18 and 19 for other knee pad. 20. Depress the spring button on the leg and insert foot plate onto tube as shown. Put into position and tighten securely. Repeat steps for other foot plate. 21.
  • Page 13 22. Place tray as shown. 23. Tighten both tray knobs securely. 24. Place prone tray as shown. Loosen knob on the side of the tray and position the bracket vertical. Tighten knob securely. Page 10...
  • Page 14 25. Using 2 bolts from the parts bag, place the prone upper body support pad (with strap) onto the unit as shown. Insert 2 bolts. 26. Tighten 2 bolts securely Page 11...

  • Page 15: Adjustment/Usage

    Adjustment/Usage CAUTION: Trays should not be loaded with greater than 10lbs. (4.5KG). Use caution when positioning mast (steps 16 and 17) with any object on the tray. Changing from Supine to Prone 1. Loosen the knob and depress the spring button on the tube to remove the Supine tray assembly.
  • Page 16 Trays-Supine 4. To adjust tray height, loosen knob on the back of unit and set to desired position. Tighten knob securely. 5. To adjust the tray depth, loosen the knob under the table, set to desired position. Tighten knob securely. 6.
  • Page 17 Trays-Prone 7. To adjust tray height, loosen knob on the back of unit and set to desired position. Tighten knob securely. To adust the angle, loosen the knob on the side of tray and set to desired position. Tighten knob securely.
  • Page 18 Foot Plates Caution: Never reposition the foot plates with the child in the standing position. 10. To adjust the foot plate height, loosen knob and set to desired position. Tighten knob securely. 11. To adjust the Toe-in/Toe-out/Abduction, loosen knobs underneath foot plates, slide foot plates into position.
  • Page 19 Abduction 13. To adjust leg abduction, loosen the knob behind the pelvic pad. 14. Abduct each leg out to the desired position up to 15 degrees per leg. Tighten securely. Upholstery and Upholstery Straps 15. Upholstery is constructed with velcro compatible neoprene material.
  • Page 20 Supine 16. With one hand supporting the unit, Adjust to the desired supine position by depressing the lever on the rear handle and tilting. This can be done with the user in the unit. Rear Handle Prone 17. With one hand supporting the unit, Adjust to the desired prone position by depressing the lever on the rear handle and tilting.

  • Page 21: Parts Detail

    19. The unit can be easily transported or stored. Parts Detail Page 18...

  • Page 22: Maintenance

    Maintenance • Check the Zing at least weekly to ensure all nuts, bolts and adjustable parts are tightened securely, failure to do so may result in parts falling off which may cause a choking hazard for children. • Mechanisms work better when clean and free of dirt, dust, lint and other debris. When not in use store the unit in an area that will allow the unit to remain clean.

  • Page 23: Limited Warranty

    Limited Warranty This warranty is extended only to the original purchaser/customer (or supplier non consumer who does not buy or resell). Altimate Medical, Inc., warrants the Zing against defects in materials and workmanship as listed below. • Steel Frames - 5 year warranty •...
  • Page 24 262 West 1st St. Morton, MN 56270 USA Toll Free: 800.342.8968 or 507.697.6393 Fax Free: 877.342.8968 or 507.697.6900 email: info@zingstanders.com Zingstanders.com Standing technology should only be used under the guidance of a physician with recommendations for standing program protocol and any medical precautions.
