7. PRINTER MANAGER OPERATIONS

SETTING THE PRIN T ORIGIN
Print origin sets the print starting point from the Carriage Home Position (right side from the front of the machine).
It can be set by two ways; moving & positioning the carriage and typing the offset value directly in the given field.
Follow these steps to change the print origin:
Step 1: Move the carriage at the position from where you want to start the printing by clicking on the left and right
buttons on the Quick Access Toolbar, as shown below:
Step 2: After positioning the carriage, click on the Set print origin icon on the Quick Access Toolbar, as shown
below:
On clicking the Set print origin icon, the current position of the carriage gets updated in the Origin X text box, as
shown below:
Now, the printing origin gets set. Additionally, you can also directly enter the print origin value in the Origin X field
under the Print Parameter section.
VastraJet K2
Fig 36: Adjusting the Carriage Position
Fig 37: Selecting the Set Print Origin Option
Fig 38: Displaying the Origin Value
Page 33 of 73
