MAINTENANCE INSTRUCTIONS
Maintenance tips and
cleaning
Z40 ADAPT
We recommend the use of protective gloves when handling
our juicers.
Cleaning the squeezing system and front protector is
recommended at least once a day.
Do not forget to check the bark deposits promptly.
All parts are dishwasher safe
(except the front protection).
The front protectors of our juicers are
made up of polycarbonate and ABS
models, that is why we recommend not
cleaning them in the dishwasher, to
avoid scratches or damage.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Z40 ADAPT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zummo Z40 ADAPT

Summary of Contents for Zummo Z40 ADAPT

  • Page 1 MAINTENANCE INSTRUCTIONS Maintenance tips and cleaning Z40 ADAPT We recommend the use of protective gloves when handling our juicers. Cleaning the squeezing system and front protector is recommended at least once a day. Do not forget to check the bark deposits promptly.

  • Page 2: Maintenance Instructions

    100 ppm, which means 2.5 ml of household bleach per liter of water or 1 ml of industrial bleach per liter of water. C/ Cádiz, 4 - 46113 Moncada - Valencia (Spain) - (+34) 961 301 246 - zummo@zummo.es - www.zummocorp.com MAINTENANCE INSTRUCTIONS...
  • Page 3 Assembly 1. Place the inner basket 2. Place the lower separator 3. Place the top spacer. 4. Screw on the nut. 5. Insert the basket. 6. Activate the tab blocking. 7. Screw the balls. 8. Fit the juice extraction sys- 9.
  • Page 4 Assembly 13. Screw the nuts of the 14. Turn the lower flange and fit 15. Remove the blade Adapt tray. one side of the front cover. protector. 16. Insert the front cover. 17. Turn the lower flange and 18. Fit the chutes. fit the other side of the front cover.
  • Page 5 Disassembly 1. With the machine stopped 2. Unplug the machine from the 3. Turn the flange upwards and press the off button. mains. remove the side of the front cover. 4. Extract the front cover. 5. Now remove the other side 6.
  • Page 6 Disassembly 13. Remove the scraper from 14. Separate the two chutes. 15. Turn the locking flange the tray. 16. Take out the basket by 17. Unscrew the nuts and re- 18. Pull out the spacer turning counterclockwise. move the spacer. superior.
  • Page 7 P.O. Box 23 | C/Cádiz, 4, 46113 Moncada. Valencia. Spain. zummo@zummo.es | www.zummocorp.com | (+34)961 301 246...
