ALANTE
2023 OWNER'S MANUAL
A subsidiary of Thor Industries, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALANTE 2023 and is the answer not in the manual?

Questions and answers

Related Manuals for Jayco ALANTE 2023

Summary of Contents for Jayco ALANTE 2023

  • Page 1 ALANTE 2023 OWNER’S MANUAL A subsidiary of Thor Industries, Inc.

  • Page 3: Table Of Contents

    Suggestions For Obtaining Service Obtaining Service At Our Customer Service Facility Obtaining Service For Separately Warranted Items Parts and Accessories Aftermarket Accessories 2023 Jayco Motorized Limited Warranty Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Fire Safety Fire Extinguisher...
  • Page 4 Table of Contents Section 6: Electrical System The Electrical System Command Center Energy Management System 30A Testing The Campsite Power Connection Inverter Power Converter 12-volt DC System Batteries Load Center Automatic Transfer Switch (ATS) 120-Volt Circuit Breakers Approximate Electrical Load Ratings 120-Volt 30-amp AC Electric System Generator Starting the Generator...
  • Page 5 Table of Contents Section 11: Electronics Winegard Connect 2.0 Exterior Entertainment Center Section 12: Interior Cleaning The Interior Sofa and Dinette Pantry or Hutch (if so equipped) Countertops Flooring Privacy Drape Installation Bed Storage Cab-Over Power Bunk Bed Bunk Beds and Bunk Ladders (if so equipped) Section 13: Exterior Cleaning The Exterior Cleaning The Diamond Shield Surface...
  • Page 6 WARNING: Read all instructions in this manual and component man- ufacturer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.

  • Page 7: Introduction

    Commercial use means using the recreation vehicle as a business asset such as a mobile office or using the recreation vehicle for lease or rental purposes. Jayco reserves the right to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever. Recreation vehicles built for sale in Canada may differ to conform to Canadian Codes.
  • Page 8 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.
  • Page 9 Section 1: Warranty & Service Failure to contact Jayco Customer Service, unauthorized or improper warranty re- pairs, or failure to return requested original parts may result in loss of reimbursements and/or loss of warranty. To Contact Us Mailing address Shipping address Jayco, Inc.

  • Page 10: About This Manual

    Section 1: Warranty & Service About This Manual This manual is a guide to operation of the features, equipment and controls in your rec- reation vehicle. If you find components vary significantly from what is described, please contact your dealer to ensure you have the correct information. Nothing in this manual creates any warranty, either expressed or implied, nor does it cover every possible detail of equipment, standard or option, installed on or in your recreation vehicle.

  • Page 11: Reporting Safety Defects

    Section 1: Warranty & Service ™ NOTE: Gives helpful information This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a potential situation that,if not avoided, may result in property dam- age or damage to your motorhome.

  • Page 12: Customer Responsibility

    Section 1: Warranty & Service In Canada: If you believe your vehicle has an alleged safety defect, you should contact Transport Canada and our Customer Service Department immediately. To file a safety concern, you can complete an on-line form at https://tc.canada.ca/en/road- transportation/defects-recalls-vehicles-tires-child-car-seats/report-potential-safety-defect- vehicles-tires-child-car-seats, or call to speak with a defect investigator.

  • Page 13: Obtaining Service At Our Customer Service Facility

    Section 1: Warranty & Service Contact your dealer at once Do not wait until you are ready to use your RV. Your dealer may not be able to service it im- mediately and/or the repair may require parts be ordered. The dealer’s service department is busiest on Mondays, Fridays and before holidays.

  • Page 14: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreation vehicle before delivery, and has an interest in your continued satisfaction. We recommend your dealer perform all inspection, warranty and maintenance services. Some dealers may be authorized service centers for those OEMs whose products are warranted separately and excluded from the Limited Warranty.

  • Page 15: 2023 Jayco Motorized Limited Warranty

    HOME IS TITLED OR REGISTERED IN A BUSINESS NAME OR WHEN THE JAYCO IS SOLD IN CANADA. There is no warranty of any nature made by Jayco beyond that contained in this Limited Warranty. No person has authority to enlarge, amend or modify this Limited Warranty. The dealer is NOT Jayco’s agent.
  • Page 16 Jayco reserves the right to make changes in the design or material of its prod- ucts without incurring any obligation to incorporate such changes in any product previously manufactured.
  • Page 17 (1) you notify Jayco or an authorized dealer within 10 days of your discovery of a defect; AND (2) you deliver the Motor home to Jayco OR an authorized dealership at your cost and expense.
  • Page 18 The written warranty provided by the manufacturer of the component part is the direct and exclusive responsibility of that manufacturer). EVENTS DISCHARGING JAYCO FROM OBLIGATION UNDER WARRANTY: • Any rental, business or commercial use or purchase of the Motor home;...
  • Page 19 Jayco, your Warranty will be registered. The failure to submit this warranty registration to Jayco will not affect your rights under this limited warranty as long as you can present proof of purchase, however, it can cause delays in obtaining the remedies offered by this limited warranty, and it may adversely affect any servicing facility’s ability...
  • Page 20 Section 1: Warranty & Service ™ Notes: Maintenance Record Table of Contents...

  • Page 21: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 22: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle.

  • Page 23: Smoke Alarm

    Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.
  • Page 24 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.

  • Page 25: Formaldehyde

    Section 2: Occupant Safety (but not limited to): acetone, alcohol, butane and gasoline. These chemicals can be found in commonly used items such as deodorants, colognes, per- fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans.

  • Page 26: Extended Or Full Time Usage

    Section 2: Occupant Safety To aid in dissipation, ventilate the recreation vehicle by opening all windows and circulate the air with a fan. This label is located inside the vehicle near the entry door. The label should be left permanently affixed to the recreation vehicle.

  • Page 27: Vehicle Labels

    Section 3: Pre-Travel Information Vehicle Labels Decals and data plates used throughout the motor home aid in its safe and efficient operation; others give service instructions. Read all decals, data and instruction plates before operat- ing your recreation vehicle. Any decal, data or instruction plate painted over, damaged or removed should be replaced.
  • Page 28 Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity): The upper portion of this yellow label is federally required and indicates the total combined weight value of occupants and cargo that may be placed in or on your motor home as it was manufac- tured and weighed before leaving the factory.

  • Page 29: Loading Your Motor Home

    Section 3: Pre-Travel Information Loading Your Motor Home Never load the motor home in excess of the GVWR or the GAWR for either axle. Overloading your motor home may result in adverse han- dling characteristics and damage to the chassis. DO NOT EXCEED YOUR GVWR! This means you should weigh your vehicle as loaded for your normal travel to determine the actual weight.

  • Page 30: Weighing Your Motor Home

    Section 3: Pre-Travel Information White Ground Blue Electric Brakes Green Running lights Black House batteries charge line Stop & left turn Brown Stop & right turn Yellow Back up Lights The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact.
  • Page 31 Section 3: Pre-Travel Information Dump the gray and black water holding tanks before traveling to avoid carry- ing unnecessary weight. Full tanks can affect your fuel consumption, and de- pending on tank location, can affect your vehicle handling characteristics. If you cannot immediately empty your holding tanks, reduce your vehicle speed until you reach a dumping station.
  • Page 32 Section 3: Pre-Travel Information ™ Notes: Maintenance Record Table of Contents...

  • Page 33: Vehicle Operation

    Section 4: Vehicle Operation Vehicle Operation Your motor home will travel safely and comfortably at highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Allow more time to go around the vehicle you are passing. Avoid situations that might require sudden momentum changes as the length of the motor home affects your ability to quickly cut back into traf- fic.
  • Page 34 Section 4: Vehicle Operation Towing will affect vehicle handling, durability and fuel economy. Exceeding any of the listed weight ratings will result in unacceptable overall vehicle performance. Your safety and satisfaction require proper use of correct equipment. For maximum pulling load and vertical tongue weight, refer to the label located on the rear hitch.

  • Page 35: Power Entrance Step

    Section 4: Vehicle Operation Maintenance Keep the hitch clean along with your general frame maintenance. At the beginning of the season, and monthly or thereafter, clean the inside of the receiver tube with a wire brush and spray with a silicone spray. Always remove the utility mount from the receiver when it is not in use.

  • Page 36: Driver And Passenger Seat

    Section 4: Vehicle Operation Driver and Passenger Seat Do not adjust the seat while driving. After adjusting the seat, make sure that it is locked in position. To ensure that the seat is locked securely, try to move the seat forward or backward without using the adjusting lever or button.

  • Page 37: Child Safety Restraint Systems

    Section 4: Vehicle Operation Always use seat belts. In an accident, injury to the driver and passengers may be reduced if seat belts are properly used. If your motor home is equipped with a booth dinette, hide-a-bed sofa, or easy bed sofa they will have two-point lap-seat belts installed. Seat belts should be used in all seating positions.

  • Page 38: Vehicle Dash

    Section 4: Vehicle Operation Booth Dinette (if equipped) The dinette table should be lowered and secured with the safety strap when- ever adding a child safety seat to the dinette seat. Failure to follow these guidelines can result in serious injury or death. If your child requires a child safety restraint system (seat), it can be installed in the forward or rear facing booth dinette according to the instructions of the safety seat manufacturer.

  • Page 39: Outside Rearview Mirrors

    Section 4: Vehicle Operation Outside Rearview Mirrors Adjust the outside rearview mirrors before driving. After adjusting the front driver’s seat, adjust the outside rearview mirrors to your driving preference. Have someone help you adjust the mirrors in the desired direction for maximum rear visibility before driving.

  • Page 40: Campsite Hook-Up

    Section 4: Vehicle Operation Camera/monitor system aids in the use of, but does not replace ve- hicle side/rear-view mirrors. Objects in camera/monitor view are closer than they appear. When backing up, proceed cautiously and be prepared to stop. Campsite Hook-Up Refer to Electrical Systems section before connecting the shore line power cord (when using full hook-up) OR before starting the generator or operating the ve- hicle on 12-volt power when dry camping.
  • Page 41 Section 4: Vehicle Operation For detailed operating and safety information, refer to the manufacturer’s user guide. Leveling your motor home is important for the following reasons The water drainage systems are designed with proper slope and must be level for proper operation.
  • Page 42 Section 4: Vehicle Operation completed, the keypad will signal a successful level with a dual-level tone. The keypad may be left on once level has been achieved. The keypad will enter “sleep mode” after five minutes of inactivity. Retracting the Jacks: The Equalizer System provides the ability to retract the jacks using the ALL RETRACT button or the UP button for each individual jack.

  • Page 43: Emergency Stopping

    Section 4: Vehicle Operation Helpful Hints Your leveling system is a microprocessor-controlled system. Proper and adequate battery voltage and permanent chassis ground are essential. Your system may be equipped with a manual override option. Refer to the proce- dure for proper operation of this option. It is better to review this procedure prior to its actual use.

  • Page 44: Emergency Towing

    Section 4: Vehicle Operation Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic. Place the second warning indicator 100 feet behind the recreation vehicle in the center of the lane and toward approaching traffic. Place the third warning indicator 100 feet in front of the recreation vehicle in the center of the lane and away from the traffic approaching from behind.

  • Page 45: Wheel Lug Nuts/Wheel Liners

    Section 4: Vehicle Operation Wheel Lug Nuts/Wheel Liners Check and tighten the wheel lug nuts regularly to ensure they did not loosen during travel. Refer to your Chassis Guide for torque recommen- dations. Failure to tighten and maintain wheel lug nuts to the proper torque speci- fication, could allow the wheels to come off while driving, resulting in serious injury or property damage in the event of a collision or loss of vehicle control.

  • Page 46: Tires

    Section 4: Vehicle Operation Tires Read and understand the following before taking your first trip in your RV. Routine maintenance on your RV is important. To ensure your tires are operating safely, regular inspection of the tires and checking tire pressures is absolutely mandatory. Alignment, balance and bearing wear will affect tire wear.

  • Page 47: Changing A Tire

    Section 4: Vehicle Operation Proper inflation should be monitored closely. Failure to do so could result in the overheating of a tire causing a blowout. Inflation pressure should be as recommended by the tire manu- facturer or as the federal label for the recreation vehicle indicates. When you are using your Recreation Vehicle, check inflation pressure weekly.

  • Page 48: Awnings

    Section 4: Vehicle Operation Awnings Awnings must be closed (and secured) while the RV is in transit. Keep clear of arm assemblies while opening, adjusting or closing the aw- ning. Failure to obey this caution could result in injury and/or property damage.
  • Page 49 Section 4: Vehicle Operation stowage (rolled up). Leave the awning open during warm weather to minimize wrinkling. A slight “travel line” may appear where the door roller (if installed) contacts the fabric. This is normal and does not affect the integrity of the fabric. To clean the fabric: Open the awning.
  • Page 50 Section 4: Vehicle Operation ™ Notes: Maintenance Record Table of Contents...

  • Page 51: Electric Slide Room(S) (If So Equipped)

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
  • Page 52 Section 5: Slideout Systems sure the slideout has extended properly and has adequate clearance from any outside obstructions. If the slideout is equipped with rubber seals, verify that the corners of the black rubber seal are set up correctly. The seal corners are cut at a 45°...
  • Page 53 Section 5: Slideout Systems Error Codes: When an error code occurs during operation, the board LEDs lights will in- dicate where the problem is. For motor specific faults the green LED will blink (1) time for motor #1 and (2) times for motor #2. The red LED will blink 2 to 9 times depending on the error code.
  • Page 54 Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed. Call your dealer or Customer Service if: During the override procedure the motors are not synchronized.
  • Page 55 Section 5: Slideout Systems The room must be travel locked to keep the room in place for road travel. DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
  • Page 56 Section 5: Slideout Systems Locate the slideout motor (Fig. 1) mounted to one of the slideout rails. Some models may require removal of the underbelly or cover to access the motor. In a bedroom slideout, it may be located under the bed. Rotate the brake lever, on the backside of the motor, counter-clockwise (looking from the rear of the motor) about 1/8 of a turn to the released position.
  • Page 57 Section 5: Slideout Systems Remove (4) screws holding the panel to the top of the compartment. Remove the cover. Unplug the motor leads at the connector. Gray connec- tor with red and black wires. To release the motor brake you must depress the spring lock lever, which then allows you to pivot the brake le- ver, which in turn releases the brake.
  • Page 58 Section 5: Slideout Systems ™ Notes: Maintenance Record Table of Contents...
  • Page 59 Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.
  • Page 60 Section 6: Electrical System Awning control switches (press and hold to extend / retract) Systems monitor with LED indicators for tank levels and battery charge status Auto leveling control panel (for leveling the RV) Inverter panel (power switch with display) Power bunk bed lift control switch Speaker selector switch Touch Dimmer Switch...
  • Page 61 Section 6: Electrical System ™ NOTE: The order of the devices above is referred to as the “shedding” order. If the load exceeds the service amperage on the display, the system goes down this list sequentially and sheds appliances in that order until the system has reduced amperage below the service amperage shown on the display.
  • Page 62 Section 6: Electrical System with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. To help prevent power surges from damaging the connected loads, please follow these in- structions when hooking up to the external power source: Turn off the load center main 120-volt circuit breaker.
  • Page 63 Section 6: Electrical System Status LED Indicators Indicator Definition Solid green. Indicates grid mode in which shore power is available and passing through to the loads. Solid green. Indicates Battery mode (Inverter mode) in which the in- verter is running and supplying power to the loads from the battery. Solid red.
  • Page 64 Section 6: Electrical System It is important that the fluid level of any connected batteries be checked on a regular basis. All batteries will “gas” and lose some fluid when continuously connected to any charging source (does not apply to “gel-cell” batteries). Before checking for converter output voltage, the battery cables must be disconnected at the battery.
  • Page 65 Section 6: Electrical System Normal Mode: Green LED flashes once per second; battery is between 50% and 90% charged. Green LED flashes 2-3 times per second; battery is 90% charged. Output voltage is 13.6VDC and the converter is safely completing the charge of the battery. Boost Mode: Green LED is on solid.
  • Page 66 Section 6: Electrical System Keep the protective dust cap on the 12-volt DC outlet when not in use to pre- vent ingestion of foreign material and potential short circuit conditions. Batteries Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals.
  • Page 67 Section 6: Electrical System of power are drawn from the house auxiliary batteries, they will become deeply discharged. Permanent battery damage will occur after repeated deep discharge cycles. Battery Inspection and Care Check the level of electrolyte in each battery cell once a year. Add distilled water as needed to reach the split-level marker on each battery.
  • Page 68 Section 6: Electrical System when using 12-volt devices in the house section of your motor home. When the engine is running the isolator solenoid engages allowing the house batteries to be charged by the vehicle alternator. Auxiliary Start System Depending on your model, the Battery Boost switch or the Auxiliary Start button engages the solenoid and joins the house battery with the chassis battery to provide a “boost”...
  • Page 69 Section 6: Electrical System The ATS will disconnect from shore power completely if the power coming in is not high enough quality (i.e. either low/high voltage, or low/high frequency). When the generator is operating, it powers the inverter/charger which in turn functions as a multi-stage battery charger to charge the house auxiliary and chassis batteries.
  • Page 70 Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; LED 1.7 AMPS Light;...
  • Page 71 Section 6: Electrical System 120-Volt 30-amp AC Electric System The 30-amp 120-volt 60hz AC electrical system is designed to operate on 1 leg of 120-volt power at a maximum current flow of 30-amperes. Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the service life of the electrical system and appliances.
  • Page 72 Section 6: Electrical System Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. Regularly inspect the shore power cord for cuts, cracks, worn insulation and other damage.
  • Page 73 Section 6: Electrical System Excessive usage can overheat and damage the generator starter motor. Do not engage the starter motor for more than 20 seconds at a time. If the generator does not start after the first attempt, wait at least two minutes before beginning another start sequence.
  • Page 74 Section 6: Electrical System Solar Panel Adding solar panels or equipment will affect the carrying capacity of your recreation vehicle. Vehicle weight ratings should be considered before adding these components. Solar panels produce 12-volt DC electricity when exposed to sunlight. Energy produced by the solar panels is used to charge the house auxiliary and chassis batteries.
  • Page 75 Section 7: Fuel System Fuel Safety Automotive fuels can cause serious injury or death if misused or mishandled. If you have further questions, consult your dealer or Customer Service for assistance. Always shut OFF the vehicle engine while refueling. Do not bring or store fuel or other flammable liquids inside the motor home as a fire or explosion may result.
  • Page 76 Section 7: Fuel System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a parked motor home with either the engine running or a generator running there is a potential for exhaust fumes to filter back into the motor home.
  • Page 77 Section 7: Fuel System at all connections soon after the purchase of your vehicle, and after the initial filling of the propane tanks. Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year) by a qualified propane service representative as part of your normal maintenance is recommended.
  • Page 78 Section 7: Fuel System Servicing or Filling Always shut OFF the engine while refueling. Do not smoke and do not operate other ignition sources while refueling. When the propane container is disconnected from the main supply hose and the P.O.L. connection, install the P.O.L. plastic cap that is at- tached to the container.
  • Page 79 Section 7: Fuel System Single stage regulator Some models are equipped with a single stage regulator. Two stage regulator The two-stage regulator has the only moving components in the propane system. Its sole function is to reduce the pressure from the propane containers to a safe and consistent low operating pressure.
  • Page 80 Section 7: Fuel System Never use an open flame to test for a propane leak. Do not check for leaks using products that contain ammonia or chlorine; these products can cause cracks to form on the metal tubing and brass fittings. Using the Propane System Use the following steps for propane operation: Close ALL burner valves, controls and pilot light valves.
  • Page 81 Section 7: Fuel System Ensure a supply of fresh air (Canada units only) Cooking / Comfort Heating Label Calculating Propane Gas Usage Most RV gas appliances are operated intermittently, and each has a different BTU rating. You will need to consider this when planning your propane supply and consumption. Unless there is heavy use of hot water, the water heater consumption of propane is minimal.
  • Page 82 Section 7: Fuel System ™ Notes: Maintenance Record Table of Contents...
  • Page 83 Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, water heater, tub/shower. On some models, it may also include the water purification system or outside shower assembly (if so equipped).
  • Page 84 Section 8: Plumbing System The LEDs on the panel indicate the following: C= Charge at 12.7 volts G = Good at 12.1 volts F = Fair at 11.6 volts L = Low at 6.0 volts Tank monitors on the touch screen have a constant readout. There are no buttons to push.
  • Page 85 Section 8: Plumbing System DO NOT drink water deemed microbiologically unsafe or of unknown quality. Avoid traveling with full fresh, black or grey water holding tanks. The weight of holding tank contents in not calculated into the RV cargo car- rying capacity.
  • Page 86 Section 8: Plumbing System 12-volt Water Pump There must be sufficient 12-volt DC power to run the water pump when your recreation ve- hicle is not hooked up to city water. Once activated, the water pump (also known as the de- mand pump) will self-prime, and provide water.
  • Page 87 Section 8: Plumbing System Filters should be replaced at the beginning of each camping season or if they have come into contact with contaminated water. When not in use, the water filter cartridge should be stored out of freezing temperatures. RV antifreeze will damage the water filter cartridge. Filter locations will vary by model.
  • Page 88 Section 8: Plumbing System Low point drains are installed at the lowest point of the water lines. A label is placed on the outside of the RV to indicate where the drains are located. The type of drain may vary by model.
  • Page 89 Section 8: Plumbing System Winterize plumbing lines and fixtures Bypass the hot water heater when winterizing to avoid damage to the water heater Rinse the black tank to help control odors and prevent waste buildup Rinse off items outside the unit with hot/cold faucet Connect up to (3) coax lines with satellite, cable and auxiliary The city water connection inlet is located in the Uni-Dock utility center.
  • Page 90 Section 8: Plumbing System NOT OVERFILL. Tank level can be viewed on the monitor panel inside the RV. Disconnect water source from the spigot/faucet first, then disconnect from the city wa- ter fill inlet on the utility center. DRY CAMPING (pump supplies water from the fresh water tank) Make sure the fresh water tank has an adequate supply of water.
  • Page 91 Section 8: Plumbing System How to Sanitize Turn water heater power OFF (both electric and LP gas on standard storage water heater). Single switch is inside the RV for the tankless water heater. Level the recreational vehicle and drain the fresh water system. (see Draining the Fresh Water System).
  • Page 92 Section 8: Plumbing System 12. After the recommended amount of sanitizing solution is in the tank make sure: The water tank is full of fresh water The cartridge water filter (if so equipped) is bypassed or the filter is removed from the full system canister water filter (if so equipped) Power to water heater is turned OFF (both electric and LP gas).
  • Page 93 Section 8: Plumbing System After draining the system: Water heater power should still be OFF (both electric and LP Gas on standard storage water heater). Single switch is inside the RV for the tankless water heater. Put the vinegar solution into the fresh water tank and set the valves to the SANITIZE setting.
  • Page 94 Section 8: Plumbing System ™ Appliances must be winterized. Refer to the manufacturer’s manual for pos- sible additional information or contact Customer Service for assistance. ™ NOTE: The water heater must be drained to prevent damage from freezing. Do not drain the water heater while it is hot or under pressure! The water heater MUST BE BYPASSED DURING THE WINTERIZATION PRO- CESS when introducing RV antifreeze into the plumbing system.
  • Page 95 Section 8: Plumbing System Open the hot water line faucets (kitchen/bath sinks, shower and outside shower (if equipped) until RV antifreeze begins to flow continuously. Close the hot water line faucets and repeat with the cold water line faucets (kitchen/ bath sinks, shower and outside shower).
  • Page 96 Section 8: Plumbing System Before applying air pressure to the utility center, 4 colored valves (WHITE, RED, GREEN, BLUE) MUST be set to 45° or damage may occur to the utility center. Never apply air pressure to the water system with any valves in the closed position.
  • Page 97 Section 8: Plumbing System 12. Attach a blowout plug to the City Water Inlet on the utility center panel (Fig 2). 13. Attach the air hose to the blowout plug. Set the compressor to 30 PSI. Set the four-col- or valves to 45° angle (Fig 2). Red, Blue, Green &...
  • Page 98 Section 8: Plumbing System Tank (Storage) Water Heater The water heater manufacturer has preset the sensing limit to maintain the water temperature when the water heater is activated. Read the safety and operating information in the manu- facturer’s user guide before attempting to activate the water heater. Gas/Electric DSI Tank (Storage) Water Heater System Make sure the water heater is filled with water before use as even momentary operation of the water heater without water in it may result in damage to the tank and/or controls.
  • Page 99 Section 8: Plumbing System High altitude deration Operation of the water heater at high altitudes may require derating. If the water heater is not properly derated, lack of sufficient oxygen for combustion may produce improper burner operation. Pilot outage caused by burner lift-off or sooting from a yellow burner may occur, indicating the possibility of carbon monoxide.
  • Page 100 Section 8: Plumbing System drained to prevent damage from freezing. Damage to the water heater caused by freezing is not warrantable. It is recommended the water heater be drained and bypassed during the winterization process, particularly if introducing RV antifreeze into the plumbing sys- tem.
  • Page 101 Section 8: Plumbing System Unlike your home, the recreational vehicle does not contain a water pressure balance valve. If someone is using the shower, it is recommended that the fresh water system NOT BE USED until they are finished. Water temperatures over 125°F (49°C) can cause severe burns instantly there- fore, be careful when using hot water.
  • Page 102 Section 8: Plumbing System Sewer Hose Storage Depending on your RV model, the sewer drain hose may be stored in an exterior compart- ment marked “Sewer Hose” or it may be located in the hollow square tube bumper. The bumper has removable plastic end caps, and the hose slides inside the hollow bumper. Vents Vent pipes and vents release air from the grey and black water holding tanks.
  • Page 103 Section 8: Plumbing System Black and Grey Tank Drains There are labels on the exterior of the recreation vehicle indi- cating the location of the grey and black tank drains (also called dump valves). Depending on your model, you may have one or two valves.
  • Page 104 Section 8: Plumbing System Black Tank Flush The black tank flush (no fuss flush) inlet is typically located on the utility center panel (if so equipped) labeled as “Tank Flush”. For models not equipped with a utility center, the inlet is located on the side of the recreation vehicle.
  • Page 105 Section 8: Plumbing System Connect the blowout plug to the Black Tank Flush inlet at the utility center panel. 10. Colored valves have no effect on the black tank flush inlet. 11. Connect the air hose to the blowout plug. Set the compressor to 30 PSI maximum. 12.
  • Page 106 Section 8: Plumbing System The tank heater switch should be turned OFF: When there is NO liquid present (tanks are empty). When dumping the black and gray holding tanks and the drain pipes. When fresh water tank and supply lines are empty or being drained for storage. When the recreation vehicle is connected to city sewer and the gate valves are open.
  • Page 107 Section 9: Heating & Cooling Air Conditioner Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.
  • Page 108 Section 9: Heating & Cooling The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.
  • Page 109 Section 10: Appliances Cooking Safety In Case Of a Grease Fire Do not attempt to use water to put out the fire. Water can spread some types of fire, and electrocution is possible with an electrical fire. Grease is flammable. Never allow grease to collect around top burners or on the cook top surface.
  • Page 110 Section 10: Appliances If a spillover occurs while cooking, immediately clean the spill from the cooking area while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe spill with a clean, dry towel. Kitchen Range and Oven (if so equipped) ™...
  • Page 111 Section 10: Appliances Control panel: sponge or soft cloth and water. Stainless steel (on some models): mild soap and water, then rinse with clean water and dry with soft cloth, or use stainless steel cleaner. Turntable: mild soap and water or dishwasher. Rack(s): mild soap, water and washcloth.
  • Page 112 Section 10: Appliances Push the plug until the sleeve snaps forward, locking the plug into the socket. Turn the handle ON to allow propane to flow to the drop in stove. Range Hood Whenever the stove in the RV is being used, the range hood MUST be turned on, and the inner flap MUST be unsnapped and free to move.
  • Page 113 Section 10: Appliances The ice maker should be turned off and the ice tray emptied when power to your motor home has been shut off. With no power, the ice will melt and water will “pool” in the refrigerator door. When power is restored, the vibration will cause this water to run out of the door and on to the motor home floor.
  • Page 114 Section 10: Appliances ™ Notes: Maintenance Record Table of Contents...
  • Page 115 Section 11: Electronics Winegard Connect 2.0 The Winegard Connect is an integrated system that works together for faster speeds and increased range from Wi-Fi sources. It has the following features: Expands your Wi-Fi coverage to receive signal inside your RV from farther away. Advanced Wi-Fi protected access (WPA and WPA2-PSK), guest network access, double firewall protection (SPI and NAT), and denial-of-service (DoS) attack pre- vention.
  • Page 116 Section 11: Electronics ™ Notes: Maintenance Record Table of Contents...
  • Page 117 Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 118 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
  • Page 119 Section 12: Interior at the front of the sofa seat bottom out towards you firmly and gently. To convert the hide-a- bed back into the upright sofa position, reverse the process (make sure to pull the seat belts out into their usable positions). Be sure to hold the sofa strap firmly to ensure the hide-a-bed sofa does not suddenly drop shut.
  • Page 120 Section 12: Interior Lower the table top down between the seats (B). Place the extra cushion on the table top between the 2 seats. Replace the seat cushions. To convert back to a table: Remove cushions. Lift table top back up to the bracket. Hold the table top at an angle (A).
  • Page 121 Section 12: Interior Use coasters under all glasses, bottles and cans. Do not store toiletry products directly on your countertop surface. Hair products, perfumes, colognes, nail products, creams, lotions and potions have a tendency to spill or leak and go overlooked. Even though the counter top is sealed, a substance that remains on the surface for an extended period may stain the countertop.
  • Page 122 Section 12: Interior Bed Storage Additional storage has been provided under the bed. To access the storage area, grasp the ledge at the foot of the bed and lift carefully. The bed platform must be held when raised. It is recommended that two people retrieve stored items from under the bed so that one person may hold the platform, and the other can retrieve the stored items from under the bed.
  • Page 123 Section 12: Interior The bunk bed may include a steel ladder that hooks on to the side of the bed in order to ac- cess the sleeping area. Do not exceed the weight limit of the bunk ladder. There should be no people, pets or objects on or below the bunk while raising or lowering it.
  • Page 124 Section 12: Interior The top of the ladder is secured to the ladder storage compartment. To operate the ladder, lift up and out of the storage tray. Pivot the bottom of the ladder out. Be sure the ladder is securely in place on the floor before climbing to the upper bunk. When storing the wood ladder, place the bottom of the ladder back into the tray in the storage compartment.
  • Page 125 Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. You may wash and wax your new recreation vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface. Careful maintenance for the first 60 days will assure a long lasting durable finish.
  • Page 126 Section 13: Exterior During cold weather Salt and other chemicals that are spread on winter roads in some geographical areas can have a detrimental effect on the recreation vehicle’s underbody. If your recreation vehicle is exposed to these conditions, spray the underbody with a high-pressure hose every time you wash the exterior of your recreation vehicle.
  • Page 127 Section 13: Exterior Do not allow plastic to come into contact with brake fluid, engine oil, grease, paint thinner, or battery acid. These will damage plastic. Use a soft cloth and a mild detergent solution to wipe away any such contact. Chrome parts To prevent chrome parts from spotting or corroding, wash with water, dry thoroughly, and apply a non-abrasive automotive wax.
  • Page 128 Section 13: Exterior The mud flap(s) should never be tilted towards the exhaust pipe when the motor home is not in motion or when the motor home is moving in reverse. Caution should be used when parking the motor home to assure the mud flap does not become caught or hung up on stationary items on the ground.
  • Page 129 Section 13: Exterior If your recreation vehicle is equipped with a roof ladder, do not leave items attached to it while traveling. DO NOT exceed the weight rating of the ladder. The ladder weight capacity label is located under the bottom step of the ladder.
  • Page 130 Section 13: Exterior Have the sealant replaced if you notice any cracks, peeling, voids, gaps, breaks, looseness or any sign of physical deterioration. Reseal at least one time each year as preventative maintenance. Always use the same type of sealant that was removed. Your dealer service or parts manager can help you obtain the correct sealant(s).
  • Page 131 Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Refer to your Chassis Guide for information on chassis pre-trip inspections and maintenance.
  • Page 132 Section 14: Travel/Camping/Storage Checklists Before leaving the campsite: Check the area under the motor home after overnight parking and look for fuel, water, oil or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks (if so equipped). Empty black and gray holding tank, rinse as needed.
  • Page 133 Section 14: Travel/Camping/Storage Checklists Drain and flush all holding tanks (fresh water, gray water, black water and/or hot water tanks). Adding fuel stabilizer to the generator will aid in preventing condensation and fuel varnishing. Turn OFF the motor home 12-volt battery disconnect switch. Turn OFF the inverter mode at remote.
  • Page 134 Section 14: Travel/Camping/Storage Checklists ™ Notes: Maintenance Record Table of Contents...
  • Page 135 Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 136 Section 15: Additional Information Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Shurflo East www.shurflo.com Water Pump, 12V Maintenance Record Table of Contents...
  • Page 137 Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Engine: Engine Serial#: Serv i ce P e r f o r m e d Mileage Work Performed Notes Date Maintenance Record Table of Contents...
  • Page 138 Section 15: Additional Information ™ Notes: Maintenance Record Table of Contents...
  • Page 139 Section 15: Additional Information Jayco Ownership Notification Email the form to unitfile@jayco.com ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ Change of Owner □Transfer of Limited Warranty...
