Table of Contents Section 6: Electrical System The Electrical System Command Center Vegatouch System Testing The Campsite Power Connection Inverter Power Converter 12-volt DC System Batteries Load Center Automatic Transfer Switch (ATS) 120-Volt Circuit Breakers Approximate Electrical Load Ratings 120-Volt 30-amp AC Electric System Generator Starting the Generator Solar Prep...
Page 5
Table of Contents Section 11: Electronics Winegard Connect 2.0 Exterior Entertainment Center (if so equipped) Section 12: Interior Cleaning The Interior Sofa and Dinette Pantry or Hutch (if so equipped) Countertops Flooring Ceiling Fabric Privacy Drape Installation Bed Storage Cab-Over Bunk Bed Section 13: Exterior Cleaning The Exterior Cleaning The Diamond Shield Surface...
Page 6
WARNING: Read all instructions in this manual and component man- ufacturer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.
Commercial use means using the recreation vehicle as a business asset such as a mobile office or using the recreation vehicle for lease or rental purposes. Jayco reserves the right to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever. Recreation vehicles built for sale in Canada may differ to conform to Canadian Codes.
Page 8
(or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.
Page 9
Section 1: Warranty & Service Failure to contact Jayco Customer Service, unauthorized or improper warranty re- pairs, or failure to return requested original parts may result in loss of reimbursements and/or loss of warranty. To Contact Us Mailing address Shipping address Jayco, Inc.
Section 1: Warranty & Service About This Manual This manual is a guide to operation of the features, equipment and controls in your rec- reation vehicle. If you find components vary significantly from what is described, please contact your dealer to ensure you have the correct information. Nothing in this manual creates any warranty, either expressed or implied, nor does it cover every possible detail of equipment, standard or option, installed on or in your recreation vehicle.
Section 1: Warranty & Service NOTE: Gives helpful information This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a potential situation that,if not avoided, may result in property dam- age or damage to your motorhome.
Section 1: Warranty & Service In Canada: If you believe your vehicle has an alleged safety defect, you should contact Transport Canada and our Customer Service Department immediately. To file a safety concern, you can complete an on-line form at https://tc.canada.ca/en/road- transportation/defects-recalls-vehicles-tires-child-car-seats/report-potential-safety-defect- vehicles-tires-child-car-seats, or call to speak with a defect investigator.
Section 1: Warranty & Service Contact your dealer at once Do not wait until you are ready to use your RV. Your dealer may not be able to service it im- mediately and/or the repair may require parts be ordered. The dealer’s service department is busiest on Mondays, Fridays and before holidays.
Section 1: Warranty & Service Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreation vehicle before delivery, and has an interest in your continued satisfaction. We recommend your dealer perform all inspection, warranty and maintenance services. Some dealers may be authorized service centers for those OEMs whose products are warranted separately and excluded from the Limited Warranty.
Page 15
HOME IS TITLED OR REGISTERED IN A BUSINESS NAME OR WHEN THE JAYCO IS SOLD IN CANADA. There is no warranty of any nature made by Jayco beyond that contained in this Limited Warranty. No person has authority to enlarge, amend or modify this Limited Warranty. The dealer is NOT Jayco’s agent.
Page 16
Jayco reserves the right to make changes in the design or material of its prod- ucts without incurring any obligation to incorporate such changes in any product previously manufactured.
Page 17
(1) you notify Jayco or an authorized dealer within 10 days of your discovery of a defect; AND (2) you deliver the Motor home to Jayco OR an authorized dealership at your cost and expense.
Page 18
The written warranty provided by the manufacturer of the component part is the direct and exclusive responsibility of that manufacturer). EVENTS DISCHARGING JAYCO FROM OBLIGATION UNDER WARRANTY: • Any rental, business or commercial use or purchase of the Motor home;...
Page 19
Jayco, your Warranty will be registered. The failure to submit this warranty registration to Jayco will not affect your rights under this limited warranty as long as you can present proof of purchase, however, it can cause delays in obtaining the remedies offered by this limited warranty, and it may adversely affect any servicing facility’s ability...
Page 20
Section 1: Warranty & Service Notes: Maintenance Record Table of Contents...
Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.
Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle.
Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.
Page 24
Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
Page 25
Section 2: Occupant Safety (but not limited to): acetone, alcohol, butane and gasoline. These chemicals can be found in commonly used items such as deodorants, colognes, per- fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans.
Section 2: Occupant Safety To aid in dissipation, ventilate the recreation vehicle by opening all windows and circulate the air with a fan. This label is located inside the vehicle near the entry door. The label should be left permanently affixed to the recreation vehicle.
Section 3: Pre-Travel Information Vehicle Labels Decals and data plates used throughout the motor home aid in its safe and efficient operation; others give service instructions. Read all decals, data and instruction plates before operat- ing your recreation vehicle. Any decal, data or instruction plate painted over, damaged or removed should be replaced.
Page 28
Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity): The upper portion of this yellow label is federally required and indicates the total combined weight value of occupants and cargo that may be placed in or on your motor home as it was manufac- tured and weighed before leaving the factory.
Section 3: Pre-Travel Information Loading Your Motor Home Never load the motor home in excess of the GVWR or the GAWR for either axle. Overloading your motor home may result in adverse han- dling characteristics and damage to the chassis. DO NOT EXCEED YOUR GVWR! This means you should weigh your vehicle as loaded for your normal travel to determine the actual weight.
Section 3: Pre-Travel Information White Ground Blue Electric Brakes Green Running lights Black House batteries charge line Stop & left turn Brown Stop & right turn Yellow Back up Lights The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact.
Page 31
Section 3: Pre-Travel Information Dump the gray and black water holding tanks before traveling to avoid carry- ing unnecessary weight. Full tanks can affect your fuel consumption, and de- pending on tank location, can affect your vehicle handling characteristics. If you cannot immediately empty your holding tanks, reduce your vehicle speed until you reach a dumping station.
Page 32
Section 3: Pre-Travel Information Notes: Maintenance Record Table of Contents...
Section 4: Vehicle Operation Vehicle Operation Your motor home will travel safely and comfortably at highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Allow more time to go around the vehicle you are passing. Avoid situations that might require sudden momentum changes as the length of the motor home affects your ability to quickly cut back into traf- fic.
Page 34
Section 4: Vehicle Operation Towing Behind Your Motor Home Do not install a frame equalizing type hitch on your motor home. Towing will affect vehicle handling, durability and fuel economy. Exceeding any of the listed weight ratings will result in unacceptable overall vehicle performance. Your safety and satisfaction require proper use of correct equipment.
Section 4: Vehicle Operation Contact your dealer for assistance in determining whether a separate braking system is rec- ommended for your towing and traveling safety. Failure to follow these instructions will create a safety hazard and may result in an accident. Maintenance Keep the hitch clean along with your general frame maintenance.
Section 4: Vehicle Operation Driver and Passenger Seat Do not adjust the seat while driving. After adjusting the seat, make sure that it is locked in position. To ensure that the seat is locked securely, try to move the seat forward or backward without using the adjusting lever or button.
Section 4: Vehicle Operation Always use seat belts. In an accident, injury to the driver and passengers may be reduced if seat belts are properly used. If your motor home is equipped with a booth dinette, hide-a-bed sofa, or easy bed sofa they will have two-point lap-seat belts installed. Seat belts should be used in all seating positions.
Page 38
Section 4: Vehicle Operation Booth Dinette (if equipped) The dinette table should be lowered and secured with the safety strap when- ever adding a child safety seat to the dinette seat. Failure to follow these guidelines can result in serious injury or death. If your child requires a child safety restraint system (seat), it can be installed in the forward or rear facing booth dinette according to the instructions of the safety seat manufacturer.
Section 4: Vehicle Operation Outside Rearview Mirrors Adjust the outside rearview mirrors before driving. After adjusting the front driver’s seat, adjust the outside rearview mirrors to your driving preference. Have someone help you adjust the mirrors in the desired direction for maximum rear visibility before driving.
Section 4: Vehicle Operation Camera/monitor system aids in the use of, but does not replace ve- hicle side/rear-view mirrors. Objects in camera/monitor view are closer than they appear. When backing up, proceed cautiously and be prepared to stop. Campsite Hook-Up Refer to Electrical Systems section before connecting the shore line power cord (when using full hook-up) OR before starting the generator or operating the ve- hicle on 12-volt power when dry camping.
Page 41
Section 4: Vehicle Operation Depending on your model, the system may vary slightly from the following instructions. FAILURE TO ACT IN ACCORDANCE WITH THE FOLLOWING WARNINGS MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH! The use of the electronic automatic leveling system to support the coach for any reason other than which it is intended is prohibited and will violate terms of the limited warranty.
Page 42
Section 4: Vehicle Operation Prior to operation, make sure the following conditions are met: The recreation vehicle is parked on a reasonably level surface. Transmission should be in PARK. Apply the parking brake. REMOVE IGNITION KEY FROM VEHICLE IGNITION! (System will not operate with the ignition ON).
Page 43
Section 4: Vehicle Operation When the lights stop flashing, push the button labeled “FRONT” 5 times. Press the button labeled “REAR” 5 times. All lights on the panel will begin to flash. This means you have reached “zero mode” in the system. At this time you can operate each corner or pair of levelers individually.
Section 4: Vehicle Operation Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping. Turn ON your vehicle hazard warning flashers. If traveling at night, use three red warning indicators such as flares, reflectors or lanterns as required by the Uniform Vehicle Code and Model Traffic Ordinance as follows: Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic.
Section 4: Vehicle Operation After this road test has been completed, front-end alignment and/or vibrations will not be covered as part of the new vehicle limited warranty. Follow the Chassis Guide maintenance instructions for the front and rear axle for wheel and suspension maintenance, including the brakes and wheel bearings.
Page 46
Section 4: Vehicle Operation Tires Read and understand the following before taking your first trip in your RV. Routine maintenance on your RV is important. To ensure your tires are operating safely, regular inspection of the tires and checking tire pressures is absolutely mandatory. Alignment, balance and bearing wear will affect tire wear.
Section 4: Vehicle Operation Proper inflation should be monitored closely. Failure to do so could result in the overheating of a tire causing a blowout. Inflation pressure should be as recommended by the tire manu- facturer or as the federal label for the recreation vehicle indicates. When you are using your Recreation Vehicle, check inflation pressure weekly.
Page 48
Section 4: Vehicle Operation Awnings Awnings must be closed (and secured) while the RV is in transit. Keep clear of arm assemblies while opening, adjusting or closing the aw- ning. Failure to obey this caution could result in injury and/or property damage.
Page 49
Section 4: Vehicle Operation stowage (rolled up). Leave the awning open during warm weather to minimize wrinkling. A slight “travel line” may appear where the door roller (if installed) contacts the fabric. This is normal and does not affect the integrity of the fabric. To clean the fabric: Open the awning.
Page 50
Section 4: Vehicle Operation Notes: Maintenance Record Table of Contents...
Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
Page 52
Section 5: Slideout Systems sure the slideout has extended properly and has adequate clearance from any outside obstructions. If the slideout is equipped with rubber seals, verify that the corners of the black rubber seal are set up correctly. The seal corners are cut at a 45°...
Page 53
Section 5: Slideout Systems Error Codes: When an error code occurs during operation, the board LEDs lights will in- dicate where the problem is. For motor specific faults the green LED will blink (1) time for motor #1 and (2) times for motor #2. The red LED will blink 2 to 9 times depending on the error code.
Page 54
Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed. Call your dealer or Customer Service if: During the override procedure the motors are not synchronized.
Page 55
Section 5: Slideout Systems The room must be travel locked to keep the room in place for road travel. DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
Page 56
Section 5: Slideout Systems Locate the slideout motor (Fig. 1) mounted to one of the slideout rails. Some models may require removal of the underbelly or cover to access the motor. In a bedroom slideout, it may be located under the bed. Rotate the brake lever, on the backside of the motor, counter-clockwise (looking from the rear of the motor) about 1/8 of a turn to the released position.
Page 57
Section 5: Slideout Systems Remove (4) screws holding the panel to the top of the compartment. Remove the cover. Unplug the motor leads at the connector. Gray connec- tor with red and black wires. To release the motor brake you must depress the spring lock lever, which then allows you to pivot the brake le- ver, which in turn releases the brake.
Page 58
Section 5: Slideout Systems Notes: Maintenance Record Table of Contents...
Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.
Section 6: Electrical System Awning control switches (press and hold to extend / re- tract) Systems monitor with LED indicators for tank levels and battery charge status Auto leveling control panel (for leveling the RV) Inverter panel (power switch with display) Power bunk bed lift control switch Speaker selector switch Touch Dimmer Switch...
Page 61
Section 6: Electrical System Do not hook the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity That has non-functioning ground circuits That shows outward signs of heat damage.
Page 62
Section 6: Electrical System When you are ready to leave, reverse the power cord connection process. Use care to prevent damaging the power cord electrical connection pins when connecting or disconnecting the shore power cord. Grasp the plug to remove the power cord from the outlet; do not unplug it by pulling on the cord.
Section 6: Electrical System Power Converter The power converter converts 120-volt AC power to useable 12-volt DC power when the shore power cord is connected to an external power source. The converter has a built-in protective thermal breaker that will shut it down should over- heating occur.
Section 6: Electrical System Converter voltage will drop to 13.2VDC. If the converter sees any load during this period or after it is in Float Mode it will revert back to Absorption (Normal) Mode. 13.6VDC. Bulk Mode: Converter will not jump into the Bulk Mode unless the battery is below 50% of charge, or approximately below 13.2VDC output voltage.
Page 65
Section 6: Electrical System 12-Volt Fuse Panel Replacement fuses must be of the same voltage, amperage rating and type. Never use a higher rated replacement fuse; doing so may cause a fire by overheating the RV wiring. The 12-volt fuse panel is labeled to indicate fuse sizes, positions and the components pow- ered.
Page 66
Section 6: Electrical System Batteries Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals. Contact with the battery or battery cable terminals could cause an electrical short circuit, discharge the batteries, or start an electrical fire. Keep sparks, cigarettes and flames away from the batteries as the hydrogen gas they create may explode.
Page 67
Section 6: Electrical System Check the external condition of the batteries periodically. Look for cracks in the cover and case. Make sure battery vent caps are tight and replace them if they are cracked or broken. Battery Storage Instructions To prevent house auxiliary battery discharge when your motor home will not be connected to shore power for extended periods of time, it is recommended you turn “off”...
Section 6: Electrical System The auxiliary start switch can momentarily connect both the house and chassis batteries should the chassis battery become discharged. To operate, depress either the “Aux. Start” switch (located on the front driver’s dash) or the Battery Boost switch on the driver console and hold it down. While the “Aux. Start” switch or Battery Boost switch is depressed use the ignition key to start the chassis engine.
Section 6: Electrical System NOTE: The generator requires 12-volt power from the house auxiliary bat- teries to start, and draws fuel to operate from the chassis fuel tank. If the fuel level in the chassis fuel tank drops to or below ¼ full, the generator will shut “off”...
Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; LED 1.7 AMPS Light;...
Page 71
Section 6: Electrical System 120-Volt 30-amp AC Electric System The 30-amp 120-volt 60hz AC electrical system is designed to operate on 1 leg of 120-volt power at a maximum current flow of 30-amperes. Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the service life of the electrical system and appliances.
Page 72
Section 6: Electrical System Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. Regularly inspect the shore power cord for cuts, cracks, worn insulation and other damage.
Section 6: Electrical System Excessive usage can overheat and damage the generator starter motor. Do not engage the starter motor for more than 20 seconds at a time. If the generator does not start after the first attempt, wait at least two minutes before beginning another start sequence.
Section 6: Electrical System Solar Prep Adding solar panels or equipment will affect the carrying capacity of your recreation vehicle. Vehicle weight ratings should be considered before adding these components. Your motor home is equipped with a roof mount solar panel quick connection.
Section 7: Fuel & Propane System Fuel Safety Automotive fuels can cause serious injury or death if misused or mishandled. If you have further questions, consult your dealer or Customer Service for assistance. Always shut OFF the vehicle engine while refueling. Do not bring or store fuel or other flammable liquids inside the motor home as a fire or explosion may result.
Section 7: Fuel & Propane System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a parked motor home with either the engine running or a generator running there is a potential for exhaust fumes to filter back into the motor home.
Page 77
Section 7: Fuel & Propane System at all connections soon after the purchase of your vehicle, and after the initial filling of the propane tanks. Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year) by a qualified propane service representative as part of your normal maintenance is recommended.
Page 78
Section 7: Fuel & Propane System Servicing or Filling Always shut OFF the engine while refueling. Do not smoke and do not operate other ignition sources while refueling. When the propane container is disconnected from the main supply hose and the P.O.L. connection, install the P.O.L. plastic cap that is at- tached to the container.
Section 7: Fuel & Propane System Single stage regulator Some models are equipped with a single stage regulator. Two stage regulator The two-stage regulator has the only moving components in the propane system. Its sole function is to reduce the pressure from the propane containers to a safe and consistent low operating pressure.
Page 80
Section 7: Fuel & Propane System Never use an open flame to test for a propane leak. Do not check for leaks using products that contain ammonia or chlorine; these products can cause cracks to form on the metal tubing and brass fittings. Using the Propane System Use the following steps for propane operation: Close ALL burner valves, controls and pilot light valves.
Page 81
Section 7: Fuel & Propane System Ensure a supply of fresh air (Canada units only) Cooking / Comfort Heating Label Calculating Propane Gas Usage Most RV gas appliances are operated intermittently, and each has a different BTU rating. You will need to consider this when planning your propane supply and consumption. Unless there is heavy use of hot water, the water heater consumption of propane is minimal.
Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, water heater, tub/shower. On some models, it may also include the water purification system or outside shower assembly (if so equipped).
Section 8: Plumbing System The LEDs on the panel indicate the following: C= Charge at 12.7 volts G = Good at 12.1 volts F = Fair at 11.6 volts L = Low at 6.0 volts Tank monitors on the touch screen have a constant readout. There are no buttons to push.
Page 84
Section 8: Plumbing System DO NOT drink water deemed microbiologically unsafe or of unknown quality. Avoid traveling with full fresh, black or grey water holding tanks. The weight of holding tank contents in not calculated into the RV cargo car- rying capacity.
Section 8: Plumbing System 12-volt Water Pump There must be sufficient 12-volt DC power to run the water pump when your recreation ve- hicle is not hooked up to city water. Once activated, the water pump (also known as the de- mand pump) will self-prime, and provide water.
Section 8: Plumbing System Do not allow water in the canister housing to freeze. Remove the filter before using anti-freeze to winterize the system or chlorine solution to sanitize the system. Flush canister housing thoroughly before it is put back into service after winterizing or sanitizing.
Page 87
Section 8: Plumbing System These low-point drains will release water in the supply lines by opening the valves and all faucets. The water heater has its own drain plug. To drain the permanent fresh water holding tank and supply lines: Turn the water heater power OFF (turn off the electric and LP gas switches).
Page 88
Section 8: Plumbing System Water Heater Switches The water heater switches are typically located on the monitor panel. Refer to the Monitor Panel section for function details. NOTE: A short hose is supplied with your motor home for use in sanitizing or winterizing the water lines in your RV.
Page 89
Section 8: Plumbing System A vertical utility center (Fig C). This utility center contains an outside shower, city water connection inlet, black tank flush inlet, pump switch and water valve controls. Water Valve Control Operation City Fixtures: Use this setting if the motor home can be hooked up to an external pressurized water source (city water).
Page 90
Section 8: Plumbing System Remove the city water connection inlet cap and attach one end of the short hose sup- plied with the motor home to the city water connection inlet, and the other end into a container of fresh water. Place the utility center valves in the COUNTRY FILL position (Fig A).
Page 91
Section 8: Plumbing System ppm in the water system and should remain in system for at least 4 hours. If a 100 ppm concentration is prepared, use ½ cup of household bleach with one gallon of water. One gallon of the solution should be used for each 15 gallons of tank capacity. Allow to remain in system for at least 1 hour.
Page 92
Section 8: Plumbing System Rinse the system with fresh water 10. Fill the fresh water tank full of clean (potable) water. Fill fresh water tank from an ex- ternal container. Pour fresh water into the inlet using a hose (or funnel). 11.
Page 93
Section 8: Plumbing System Attach the short hose supplied with your recreation vehicle to the fresh water connec- tion inlet (on the utility center or on the outside of the motor home). Place the other end of the hose in a container holding the sanitized solution. To aid in siphoning, set the container on a surface approximately (2) feet off the ground.
Page 94
Section 8: Plumbing System follow the same procedure used to add the sanitizer to the system. Refer to the Lingering Chlorine Taste detail in the previous section for instructions on how to flush the system with the vinegar solution. Winterization If the motor home is going to be stored in a non-temperature controlled envi- ronment with a risk of temperatures reaching 32°F (0°C) or lower, the demand (power) system with RV antifreeze must be used in the motor home plumb-...
Page 95
Section 8: Plumbing System Winterizing with Antifreeze Method (NO UTILITY CENTER) Turn water heater power OFF. Turn water heater gas valve (if so equipped) OFF (out- side of the RV). Level the RV and drain the fresh water plumbing system. (See Draining the Fresh Water System).
Page 96
Section 8: Plumbing System Move the valves to the “Sanitize/Winterize Lines” position. The low point drains must be closed for the antifreeze to siphon through the lines. Attach the short hose supplied with the motor home to the fresh water connection inlet and insert the other end of the hose into a gallon container of RV antifreeze.
Section 8: Plumbing System Water Heater Your RV is equipped with a tank (storage) water heater. Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.
Page 98
Section 8: Plumbing System If lock-out occurs before the main burner lights, turn the water heater control switch to OFF, wait five seconds and turn the switch to the ON position. This will restart the ignition cycle. The first start-up of the heater may require several ignition cycles before all the air is purged form the propane lines.
Page 99
Section 8: Plumbing System This “weeping” or dripping will continue until the pressure is reduced to below 150 pounds, and the valve closes. This condition is normal and does not indicate a defective relief valve. One way to reduce the frequency of this occurrence is to maintain an air pocket at the top of the water heater tank.
Page 100
Section 8: Plumbing System Danger of combustion, personal injury and damage to the RV! Keep the area around the appliance free from combustible materials, gasoline and other flammable liquids or vapors. Switch OFF the appliance and gas supply: ○ If you smell gas ○...
Page 101
Section 8: Plumbing System Turn water heater ON Make sure the LP gas supply is turned ON. Turn on the 12VDC power in the RV. Open the water heater access door. Turn the power switch on by selecting either ECO or COMFORT position.
Page 102
Section 8: Plumbing System COMFORT MODE: The appliance is running in a mode that provides rapid availability of hot water. Water tem- perature at the fixtures is 120°F (49°C). System is operating in Stand By Heat, which keeps water temperature in the appliance at 102°F (39°C). While run- ning in COMFORT MODE the yellow status LED (3) on the rotary dial will be lit.
Section 8: Plumbing System When the drain chute is folded out, it pro- trudes past the sidewall of the RV. When walking past or stooping down, make sure you and others have sufficient clearance to prevent injuries. Never actuate the Easy Drain Lever as long as the appliance is under water pressure or is still hot.
Section 8: Plumbing System Remove the handheld shower from its holder. Turn ON the hot and cold faucet knobs, and adjust the water temperature as desired. To activate the handheld shower turn ON the sprayer head attachment (some models). To turn off the water, always close the hot/cold control (faucet) knobs. The lever on the shower head will not completely stop the flow of water;...
Section 8: Plumbing System The tub/shower walls are made of ABS plastic material. Use a mild detergent soap and warm water to clean. Do not use gritty or abrasive particle soaps or scouring compound to clean ABS plastic. Avoid using “Citrus” or biodegradable cleaners which contain “D-Limonene.” They will damage plastic materials.
Page 106
Section 8: Plumbing System could cause you to exceed the individual tire ratings and/or the RV GAWR or RV GVWR. Potential damage to suspension components, such as springs, tires and axles, could result. If you are dry camping and cannot immediately empty your holding tanks, reduce your ve- hicle speed until you reach a dumping station.
Section 8: Plumbing System Close the sewer hose housing dust cap. You can locate dump stations throughout the United States and Canada in Woodall’s, Rand McNally Camp Guide, Good Sam Camp Guide, KOA Kampgrounds Camp Guide and vari- ous other publications. Some fuel stations also have dump stations.Please contact your RV dealer for assistance in the purchase and installation of a sewer hose or sewer hose extension (if needed).
Page 108
Section 8: Plumbing System The black tank drain valve must be OPEN any time there is a hose (water supply) connected to the black tank flush. Do not leave any hose (water supply) connected to the black tank flush when it is not in use. Do not use the same hose to fill your fresh (potable) water tank that is used for the black tank flush.
Page 109
Section 8: Plumbing System Tank Heaters Your recreation vehicle may be equipped with heaters for the fresh, gray, black water tanks. These heaters will prevent water in the tanks and lines from freezing down to -11°F (-24°C) (contingent on recreation vehicle setup). The larger tank heaters are 120VAC and attach directly to the tanks.
Page 110
Section 8: Plumbing System It is important to prevent solid waste buildup. Follow the toilet manu- facturer’s recommended instructions each time after emptying the black water holding tank. To help prevent toilet blockage, always use RV grade single-ply toilet pa- per.
Section 9: Heating & Cooling Air Conditioner Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.
Section 9: Heating & Cooling The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.
Section 10: Appliances Cooking Safety In Case Of a Grease Fire Do not attempt to use water to put out the fire. Water can spread some types of fire, and electrocution is possible with an electrical fire. Grease is flammable. Never allow grease to collect around top burners or on the cook top surface.
Page 114
Section 10: Appliances If a spillover occurs while cooking, immediately clean the spill from the cooking area while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe spill with a clean, dry towel. Gas Drop-In Cooktops Your model is equipped with either a 2 burner cooktop. The 2 burner match-light cooktop has two 6500 BTU/H burners with control panel.
Page 115
Section 10: Appliances LP Gas Grill Hookup Be sure to read, understand and follow all information supplied with your recreation vehicle concerning the use of propane before operating the BBQ grill. The propane hose must be correctly connected before lighting the grill.
Section 10: Appliances Range Hood Whenever the stove in the RV is being used, the range hood MUST be turned on, and the inner flap MUST be unsnapped and free to move. Failure to do so can create an asphyxiation hazard by restricting airflow through this vent.
Page 117
Section 10: Appliances Cleaning the Interior Unplug refrigerator or disconnect power. Hand wash, rinse, and dry removable parts and interior surfaces thoroughly. Use a clean sponge or soft cloth and a mild detergent in warm water. Inside the refrigerator, use a warm water and baking soda solution consisting of ap- proximately 1-tablespoon (15ml) baking soda to 1 quart (1 liter) of water.
Page 118
Section 10: Appliances Notes: Maintenance Record Table of Contents...
Section 11: Electronics Winegard Connect 2.0 The Winegard Connect is an integrated system that works together for faster speeds and increased range from Wi-Fi sources. It has the following features: Expands your Wi-Fi coverage to receive signal inside your RV from farther away. Advanced Wi-Fi protected access (WPA and WPA2-PSK), guest network access, double firewall protection (SPI and NAT), and denial-of-service (DoS) attack pre- vention.
Page 120
Section 11: Electronics Notes: Maintenance Record Table of Contents...
Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
Page 122
Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
Page 123
Section 12: Interior at the front of the sofa seat bottom out towards you firmly and gently. To convert the hide-a- bed back into the upright sofa position, reverse the process (make sure to pull the seat belts out into their usable positions). Be sure to hold the sofa strap firmly to ensure the hide-a-bed sofa does not suddenly drop shut.
Section 12: Interior Lower the table top down between the seats (B). Place the extra cushion on the table top between the 2 seats. Replace the seat cushions. To convert back to a table: Remove cushions. Lift table top back up to the bracket. Hold the table top at an angle (A).
Section 12: Interior Use coasters under all glasses, bottles and cans. Do not store toiletry products directly on your countertop surface. Hair products, perfumes, colognes, nail products, creams, lotions and potions have a tendency to spill or leak and go overlooked. Even though the counter top is sealed, a substance that remains on the surface for an extended period may stain the countertop.
Section 12: Interior Attach the Velcro® at the top edge of the drape to the corresponding Velcro® on the cab area roof (above the driver’s and passenger’s doors). Attach the Velcro® at the bottom corners of the drape to the corresponding Velcro® on the wall.
Page 127
Section 12: Interior Cab-Over Bunk Bed Your motor home may be equipped with an over-the-cab bunk bed. This bunk bed is ac- cessed through the use of a steel ladder that hooks to the bed platform. Exercise extreme care when entering or exiting the bunk bed and using the ladder Do not allow horseplay on the bed and prohibit jumping on the bed.
Page 128
Section 12: Interior Notes: Maintenance Record Table of Contents...
Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. You may wash and wax your new recreation vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface. Careful maintenance for the first 60 days will assure a long lasting durable finish.
Page 130
Section 13: Exterior During cold weather Salt and other chemicals that are spread on winter roads in some geographical areas can have a detrimental effect on the recreation vehicle’s underbody. If your recreation vehicle is exposed to these conditions, spray the underbody with a high-pressure hose every time you wash the exterior of your recreation vehicle.
Page 131
Section 13: Exterior Do not allow plastic to come into contact with brake fluid, engine oil, grease, paint thinner, or battery acid. These will damage plastic. Use a soft cloth and a mild detergent solution to wipe away any such contact. Chrome parts To prevent chrome parts from spotting or corroding, wash with water, dry thoroughly, and apply a non-abrasive automotive wax.
Page 132
Section 13: Exterior The mud flap(s) should never be tilted towards the exhaust pipe when the motor home is not in motion or when the motor home is moving in reverse. Caution should be used when parking the motor home to assure the mud flap does not become caught or hung up on stationary items on the ground.
Page 133
Section 13: Exterior exterior attachments. A quick walk around the recreation vehicle before leaving may help prevent potential problems during trips and vacations. Have the sealant replaced if you notice any cracks, peeling, voids, gaps, breaks, looseness or any sign of physical deterioration. Reseal at least one time each year as preventative maintenance.
Page 134
Section 13: Exterior Notes: Maintenance Record Table of Contents...
Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Refer to your Chassis Guide for information on chassis pre-trip inspections and maintenance.
Section 14: Travel/Camping/Storage Checklists Before leaving the campsite: Check the area under the motor home after overnight parking and look for fuel, water, oil or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks (if so equipped). Empty black and gray holding tank, rinse as needed.
Page 137
Section 14: Travel/Camping/Storage Checklists Drain and flush all holding tanks (fresh water, gray water, black water and/or hot water tanks). Adding fuel stabilizer to the generator will aid in preventing condensation and fuel varnishing. Turn OFF the motor home 12-volt battery disconnect switch. Turn OFF the inverter mode at remote.
Page 138
Section 14: Travel/Camping/Storage Checklists Notes: Maintenance Record Table of Contents...
Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
Page 140
Section 15: Additional Information Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Shurflo East www.shurflo.com Water Pump, 12V Maintenance Record Table of Contents...
Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Engine: Engine Serial#: Serv i ce P e r f o r m e d Mileage Work Performed Notes Date Maintenance Record Table of Contents...
Page 142
Section 15: Additional Information Notes: Maintenance Record Table of Contents...
Page 143
Section 15: Additional Information Jayco Ownership Notification Email the form to unitfile@jayco.com ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ Change of Owner □Transfer of Limited Warranty...
