Jayco ALANTE 2021 Owner's Manual

Class a
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
2021
Class A Motorhome
Owner's Manual
A subsidiary of Thor Industries, Inc.
0253835.2021

Advertisement

Table of Contents
loading

Related Manuals for Jayco ALANTE 2021

Summary of Contents for Jayco ALANTE 2021

  • Page 1 2021 Class A Motorhome Owner’s Manual A subsidiary of Thor Industries, Inc. 0253835.2021...
  • Page 3 Towing and Braking Label Power Entrance Step Entrance Door Driver and Passenger Seat Seat Belts Child Safety Restraint Systems Outside Rearview Mirrors Power Remote Mirrors (if so equipped) Remote Mirror Control / Mirror Heat Control 2021 Jayco Alante Rev B: Revise page 77...
  • Page 4 Table of Contents Rear Vision Camera Campsite Hook-Up Hydraulic Leveling System Operating the Leveling System Manual Operation Hydraulic Control Panel Helpful Hints Panel Indicator LED Emergency Stopping Emergency Towing Front Axle Tire Alignment Wheel Lug Nuts/Wheel Liners Tires Changing A Tire Awnings (if so equipped) Awning Care Electric Patio Awning With Remote Control...
  • Page 5 Table of Contents Battery Inspection and Care Battery Replacement 12-Volt Battery Disconnect Battery Isolator Solenoid (if so equipped) Battery Isolation Manager (if so equipped) Auxiliary Start System (if so equipped) Load Center Automatic Transfer Switch (ATS) 120-Volt Circuit Breakers Replacement Maintenance Approximate Electrical Load Ratings 120-Volt, 30 AMP AC Electric System (if so equipped)
  • Page 6 Table of Contents Sanitizing The Plumbing System Winterizing the Plumbing System Winterize the Macerator System (if so equipped) Water Heater Operating Instructions Water Heater Bypass High Altitude Deration Draining and Winterization Outside Shower and Courtesy Light Faucets Bathroom Tub / Shower Black/Grey Water System and Tanks Black and Grey Tank Drains Black/Grey Tank Drain and Valves...
  • Page 7 Table of Contents Section 13: Exterior Cleaning The Exterior Frame Mud Flap Exterior Roof and Sidewall Vents Windows Exterior Ladder (if so equipped) Sealants Section 14: Travel/Camping/Storage Checklists Travel Checklist Motorhome Storage Section 15: Additional Information Featured Components Quick Reference Chart Vehicle Maintenance Record...

  • Page 9: Section 1: Warranty & Service

    Section 1: Warranty & Service WARNING: Read all instructions in this manual and compo- nent manufacturer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.
  • Page 10 Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new recreation vehicle, your Jayco dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation ve- hicle must pass the dealer’s pre-delivery inspection (PDI), including all systems...
  • Page 11 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 12: About This Manual

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 13: Chassis Guide

    Section 1: Warranty & Service Chassis Guide Throughout this manual, frequent reference is made to the vehicle’s Chassis Guide. The Chassis Guide includes the owner’s manual provided by the manufacturer of the chassis on which this motorhome is built, warranty cards and/or registrations. It also includes pertinent information regarding the transmission, tires, etc.

  • Page 14: Reporting Safety Defects

    Section 1: Warranty & Service Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 15: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 16: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreational vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 17 TORHOME IS TITLED OR REGISTERED IN A BUSINESS NAME OR WHEN THE JAYCO IS SOLD IN CANADA. There is no warranty of any nature made by Jayco beyond that contained in this Limited Warranty. No person has authority to enlarge, amend or modify this Limited Warranty. The dealer is NOT Jayco’s agent.
  • Page 18 Jayco reserves the right to make changes in the design or material of its prod- ucts without incurring any obligation to incorporate such changes in any product previously manufactured.
  • Page 19 REPAIR REMEDY: Jayco’s obligation is to repair any covered defect discovered within the warranty coverage period provided: (1) you notify Jayco or an authorized dealer within 10 days of your discovery of a defect; AND (2) you deliver the Motorhome to Jayco OR an authorized dealership at your cost and expense.
  • Page 20 Section 1: Warranty & Service If you need assistance, you may contact JAYCO, INC. at 903 South Main Street, P. O. Box 460, Middlebury, Indiana 46540, Attn: Customer Service, (800) 283-8267. WHAT IS NOT COVERED: Equipment and appliances installed after the Motorhome is assembled by Jayco;...
  • Page 21 Jayco, your Warranty will be registered. The failure to submit this warranty registration to Jayco will not affect your rights under this limited warranty as long as you can present proof of purchase, however, it can cause delays in obtaining the remedies offered by this limited warranty, and it may adversely affect any servicing facility’s ability...
  • Page 22 Section 1: Warranty & Service dealership, Jayco or supplier of the component part if you have questions. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS; YOU MAY HAVE OTH- ER RIGHTS THAT VARY FROM STATE TO STATE. JAYCO, INC. 903 S. Main Street * P. O. Box 460 * Middlebury, IN 46540...

  • Page 23: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 24: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper rightarrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the win- dow. Push the lever (and window) out to open and exit the ve- hicle.

  • Page 25: Smoke Alarm

    Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 26: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety The LED light will indicate the battery is functioning properly. When the production of combustion is sensed, the smoke detector sounds a loud alarm that continues until the air is cleared. The LED light will also give a visual indication of a sounding alarm. When the battery becomes weak, the alarm will “beep”...
  • Page 27 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
  • Page 28 Section 2: Occupant Safety fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans. High temperatures can activate glue and adhesive vapors. If you close up a recreational vehicle on a hot day, the chemicals used in its construction may be detected for months after the vehicle was constructed (for more information, refer to Sec.
  • Page 29 Section 2: Occupant Safety any combustion equipment not inspected by the technician and consult the manufacturer’s instructions or contact the manufacturer directly for more information about carbon monox- ide safety and this alarm. Alarm features and functions Includes an 85db audible horn, two LEDs, and a SILENCE/TEST button. Alarm States Normal operation: The Green LED is ON steady.

  • Page 30: Extended Or Full Time Usage

    Section 2: Occupant Safety NOTE: The carbon monoxide/propane alarm manufacturer strongly rec- ommends replacement of the detector five years after the date of purchase. Formaldehyde Some components in the recreation vehicle contain formaldehyde-based adhesives that may release formaldehyde fumes into the air for an unknown period of time. Individuals who are allergic to formaldehyde gas fumes may experience irritation to eyes, ears, nose and throat.
  • Page 31 Section 2: Occupant Safety Condensation is a natural phenomenon. The amount of condensation will vary with climate conditions, particularly the relative humidity. Condensation occurs because there is water vapor present in the air. When the temperature reaches the “dew point” the water vapor in the air condenses and changes to a liquid form.
  • Page 32 Section 2: Occupant Safety Notes: Maintenance Record Table of Contents...

  • Page 33: Section 3: Pre-Travel Information

    Section 3: Pre-Travel Information Vehicle Labels Decals and data plates used throughout the motorhome aid in its safe and efficient operation; others give service instructions. Read all decals, data and instruction plates before operat- ing your recreation vehicle. Any decal, data or instruction plate painted over, damaged or removed should be replaced.
  • Page 34 Section 3: Pre-Travel Information This label also indicates the number of safety seat belts that have been installed at the factory. Addi- tions or other changes made to the motorhome after it left the factory will affect (reduce) the OCCC. The lower portion of the label is provided voluntari- ly and indicates the weight value of the motorhome as it was manufactured and weighed before leaving...

  • Page 35: Loading Your Motorhome

    Section 3: Pre-Travel Information Loading Your Motorhome Never load the motorhome in excess of the GVWR or the GAWR for either axle. Overloading your motorhome may result in adverse handling characteristics and damage to the chassis. DO NOT EXCEED YOUR GVWR! This means you should weigh your vehicle as loaded for your normal travel to determine the actual weight.

  • Page 36: Trailer Plug

    Section 3: Pre-Travel Information Trailer Plug If you choose to tow behind your RV, a chassis manufacturer supplied 7-way trailer plug (located at the hitch) is pre-wired into your motorhome. Before hitching up to a trailer, please read Using the Rear Hitch, vehicle weight ratings, etc. Your motorhome may have both 4-way and 7-way trailer receptacles.
  • Page 37 Section 3: Pre-Travel Information If there is a difference in the weights on one side of the vehicle as compared to weights on the other side, components (tires, wheels, brakes, springs, etc.) on the heavier side may be overloaded, although the total axle load is within the GAWR. It is important to redistribute the load to avoid component failure as well as to improve the handling characteristics of the vehicle.
  • Page 38 Section 3: Pre-Travel Information Notes: Maintenance Record Table of Contents...

  • Page 39: Vehicle Operation

    Section 4: Vehicle Operation Vehicle Operation Your motorhome will travel safely and comfortably at highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Allow more time to go around the vehicle you are passing. Avoid situations that might require sudden momentum changes as the length of the motorhome affects your ability to quickly cut back into traffic.

  • Page 40: Using The Rear Hitch

    Section 4: Vehicle Operation Using The Rear Hitch Do not install a frame equalizing type hitch on your motorhome. Towing will affect vehicle handling, durability and fuel economy. Exceeding any of the listed weight ratings will result in unacceptable overall vehicle performance. Your safety and satisfaction require proper use of correct equipment.

  • Page 41: Power Entrance Step

    Section 4: Vehicle Operation In addition, a separate supplemental braking system must be installed if the towed trailer or vehicle meets or exceeds the minimum weight determined by the chassis manufacturer (this minimum weight rating will vary by chassis and chassis manufacturer). Contact your dealer for assistance in determining whether a separate braking system is rec- ommended for your towing and traveling safety.
  • Page 42 Section 4: Vehicle Operation NOTE: Locks on entrance and baggage doors need biannual lubrication using a light coat of silicone spray. Conditions such as rain, salt, dust and pollution may increase the maintenance needs. Driver and Passenger Seat Do not adjust the seat while driving. After adjusting the seat, make sure that it is locked in position.

  • Page 43: Seat Belts

    Section 4: Vehicle Operation Seat Belts Seat belts should always be worn by anyone who drives or rides in this vehicle. Never use one seat belt for more than one occupant. Never carry more people in the motorhome than there are seat belts. Only seats equipped with seat belts are to be occupied while the vehicle is in motion.

  • Page 44: Outside Rear View Mirrors

    Section 4: Vehicle Operation Vehicle Dash Do not set anything on, or attach anything to, the instrument panel or dash. Do not attach anything to the steering wheel cover. Failure to follow these warn- ings may restrict the driver’s visibility or cause an object to strike and injure an occupant in the case of a collision or sudden stop.

  • Page 45: Rear Vision Camera

    Section 4: Vehicle Operation Rear Vision Camera The rear vision monitor gives a limited televised view of what is behind your motorhome. The rear vision camera will aid you in backing up the motorhome, and can be used for a greater field of vision when driving in heavy traffic.

  • Page 46: Hydraulic Leveling System

    Section 4: Vehicle Operation Hydraulic Leveling System FAILURE TO ACT IN ACCORDANCE WITH THE FOLLOWING WARNINGS MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH! The leveling system is designed only for leveling the unit and should never be used to provide service for any reason under the motorhome such as changing tires or servicing the system.
  • Page 47 Section 4: Vehicle Operation Operating the Leveling System Auto Leveling Operation Baseline Zero Point Calibration: “Baseline zero point” is the term used to de- fine the point at which the motorhome interior floor is level in the “X” and “Y” plains.
  • Page 48 Section 4: Vehicle Operation Manual Operation Power on: Push and release the POWER keypad button to engage power. The LED next to the POWER button should be RED when power is on. If you attempt to extend individual jacks by pressing the DOWN keypad button or all jacks with the AUTO-LEVEL button, you will hear a “deny”...
  • Page 49 Section 4: Vehicle Operation Helpful Hints The ALL RETRACT function is a timed event. Pressing ALL RETRACT will cause the pump to run in retract mode for 60 seconds (or 90 seconds, depending on your specific system). Your leveling system is a microprocessor-controlled system. Proper and adequate battery voltage and permanent chassis ground are essential.

  • Page 50: Emergency Stopping

    Section 4: Vehicle Operation Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping. Turn ON your vehicle hazard warning flashers. If traveling at night, use three red warning indicators such as flares, reflectors or lanterns as required by the Uniform Vehicle Code and Model Traffic Ordinance as follows: Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic.

  • Page 51: Wheel Lug Nuts/Wheel Liners

    Section 4: Vehicle Operation NOTE: Always have the alignment checked and adjusted by a qualified shop with the proper equipment to handle heavy vehicles. NOTE: A road test by the dealer should be included as part of the pre-delivery inspection. The dealer can check for and correct any steering problems before you take delivery.
  • Page 52 Section 4: Vehicle Operation Check and re-torque after the first 10, 25 and 50 miles (16, 40 and 80 kilometers). Thereafter, check and maintain the torque according to the listed torque values. Wheel lugs If you suspect or notice the wheel stud bolts are cracked or broken, they must be replaced, along with adjacent bolts that have probably also been weakened due to the additional stress placed on them.
  • Page 53 Section 4: Vehicle Operation Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is cor- rected. Tire pressure Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death.

  • Page 54: Changing A Tire

    Section 4: Vehicle Operation Changing A Tire If you experience a flat tire on your motorhome while driving, gradually decrease your The motorhome is very heavy. Raising the motorhome to replace the spare tire should only be done with extreme caution by a qualified techni- cian.

  • Page 55: Power Awnings (If So Equipped)

    Section 4: Vehicle Operation Awning Care Keep your awnings clean and in good condition to prevent costly repairs. Periodically check that the fasteners are tight. Tighten if necessary. Keep the awning fabric clean. For detailed cleaning information, refer to the manufacturer’s owner information.
  • Page 56 Section 4: Vehicle Operation Carefree® Longitude Awnings (if so equipped) Offer the following features: Scissor style arms that do not require vertical ground supports. Adjustable arms with ( 6 ) position pitch adjustment. Worm gear driver motor eliminating the need for travel locks. Single switch operation, 12V motorized awning.
  • Page 57 Section 4: Vehicle Operation Additional Awning Operation Information Operating the awning repeatedly over a short time period may cause the circuit to sense an overheat condition and shut off the motor. If this occurs, wait approxi- mately 15 minutes to allow the motor to cool then operate the awning in normal fashion.
  • Page 58 Section 4: Vehicle Operation Emergency Operation If power to the vehicle is not available, the awning can be retracted by jumping the motor using a 10VDC – 14VDC power source such as a cordless drill battery or car battery. NOTE: If the awning is equipped with the Direct Response system, this procedure is not applicable.

  • Page 59: Section 5: Slideout Systems

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
  • Page 60 Section 5: Slideout Systems To retract the slideout, press the in section of the slideout control switch and hold it until the slideout is fully retracted. Operating the switch after the room is fully extended or retracted may damage the switch and motor.
  • Page 61 Section 5: Slideout Systems NOTE: For long-term storage it is recommend the room be closed (retracted). Trouble shooting the flush floor slideout Refer to the general troubleshooting check list before proceeding. Electric Operation NOTE: Install transit bars (if so equipped) on the slideout room during storage and transportation.
  • Page 62 Section 5: Slideout Systems Schwintek In-Wall Slideout System The in-wall slideout system requires no maintenance or adjustments. This system has two vertical columns with a drive motor located at the top of each column. The right and left motors are synchronized by a circuit board.Schwintek slideouts are typically used on both towables and motorhomes.
  • Page 63 Section 5: Slideout Systems Trouble shooting the in-wall slideout system Checking Fuses: The in-wall slide requires a minimum 30-amp fuse. Check the load center for blown fuses and replace any if necessary. If the fuse blows immediately upon replace- ment, there is a problem with the wiring to the in-wall slide control box. A qualified service person should be called to check and repair.
  • Page 64 Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diag- nosed.
  • Page 65 Section 5: Slideout Systems Repeat this process for both sides of the slide room. Physically push/ pull the room back into the opening; keep both sides relatively even. The room must be travel locked to keep the room in place for road travel. DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
  • Page 66 Section 5: Slideout Systems Norco Slideout Manual Operation Locate the included flexible shaft in your own- er’s packet. Attach flexible shaft to the 1/4” hex fitting on the end of the motor. Attach 1/4” socket & ratchet, or drill to the other end, and turn in the proper direction to move the room.
  • Page 67 Section 5: Slideout Systems If the room does not move when the switch is pressed, check the following: Make sure the slideout system is turned on. Battery is fully charged and connected. Transit bars have been removed (if so equipped). When the motor brake is disengaged the slideout room WILL NOT lock into place and will not be sealed.
  • Page 68 Section 5: Slideout Systems The room is now free to move. Using either a 5/8” or 3/4” wrench or socket, crank the room either in or out completely. If the slideout system is supplied with a gearbox override (optional), use the crank handle to move the room.
  • Page 69 Section 5: Slideout Systems Turn ON the on/off switch or key. Press and hold the OUT button (Fig 4). To retract, press and hold the IN button. There will be a slight delay be- fore the room begins moving. The GREEN LED should be solid ON when room is in motion.
  • Page 70 Section 5: Slideout Systems -Check all connections at control box and motor. -Bad or loose connec- Excessive -Check the harness for bro- tion Major Battery Volt- ken wires. -Defective harness -Put 12.0 VDC direct to -Open or shorted motor the motor. If it does not run replace the motor.
  • Page 71 Section 5: Slideout Systems NOTE: After overriding the system, the room control will need to be re- programmed by an OEM authorized dealer. Emergency Retract Mode Use this procedure when there is NO loss of power or electrical problem with the system. Remove the touchpad (Fig 4) from the wall.
  • Page 72 Section 5: Slideout Systems Repeat steps 1-4 for the other side. Place a socket wrench with a 3-inch extension and a 5/8” deep well socket (Fig 12) through the motor access opening and seat the socket onto the coupler (Fig 13). One person alternating from side to side of the room can retract a 1500 lb.
  • Page 73 Section 5: Slideout Systems Power Gear Ram Slideout System Typically used for Class C motorhomes. Manual Override Procedure The system has been equipped with 3/4” hex override couplers located on the drive compo- nent of the system. Due to the size and weight of some rooms, assistance may be needed to push the room in.
  • Page 74 Section 5: Slideout Systems 11. When the slideout is retracted, check to make sure you have a good seal, and re- place the skirting on the slideout. 12. Return the brake release lever back to the “engaged” position (parallel to the spring lock lever).

  • Page 75: Section 6: Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 76: Controls And Switches

    Section 6: Electrical System Controls and Switches Your motorhome is equipped with various switches and controls that allow you to operate and monitor the systems in your motorhome. Information on these controls and their location will be provided throughout this manual. Additional information on the various components can be found in the component manu- facturer’s user guide.
  • Page 77 Section 6: Electrical System The dimmer has a memory so it remembers what the light setting was when the lights were turned OFF. When turned ON again, the lights return to that same setting. NOTE: If your RV model includes the 5 way/8 way remote control: the LIGHT button on the remote only controls the awning LED lights GFCI Circuit Breakers Ground fault current interrupter breakers are en-...

  • Page 78: Testing The Campsite Power Connection

    Section 6: Electrical System By using the scroll button you can view the appliances the system controls: • Water Heater • Refrigerator • Rear AC • Front AC The device name will display with either SHED or POWERED next to it depending on total amperage available to the coach and whether or not the device is capable of being operated under the existing load.
  • Page 79 Section 6: Electrical System Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity With non-functioning ground circuits That shows outward signs of heat damage.
  • Page 80 Section 6: Electrical System Maintenance There are no customer serviceable parts inside the inverter case and the manufacturer’s warranty will be void if the case has been removed. The inverter cooling fins and the cooling fan should be kept clear of any obstructions. Your RV may have an inverter remote display (appearance may vary) on the Command Center switch panel.

  • Page 81: Power Converter

    Section 6: Electrical System Pressing the SELECT button also cycles through in- verter settings. Inverter settings can be changed, but 12VDC must be removed from the Ignition Start Port on the back of the inverter. Unplug the 12VDC wire(s) on the back of the inverter to make changes to invert- er settings.
  • Page 82 Section 6: Electrical System If the converter output voltage at the battery reads in the 0.0VDC range, or the battery is not charging, check for: An open inline fuse in the battery wire An open wire between the converter and the RV battery Loose ground connection Improper torques If the converter fuses and AC voltage are good, but the converter output still reads zero volts,...

  • Page 83: Volt Dc System

    Section 6: Electrical System the converter when a battery is used. If the battery is connected backwards to the fuse board a fuse will blow preventing damage to the converter. Four easily accessible fuses are located next to the wizard button. Replace with fuses of the same type and rating. 12-volt DC System The majority of your motorhome lighting is powered by 12-volt electricity.
  • Page 84 Section 6: Electrical System Batteries Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals. Contact with the battery or battery cable terminals could cause an electrical short circuit, discharge the batteries, or start an electrical fire. Keep sparks, cigarettes and flames away from the batteries as the hydrogen gas they create may explode.
  • Page 85 Section 6: Electrical System Add distilled water as needed to reach the split-level marker on each battery. Keep batteries and battery terminals clean and tight. Check the external condition of the batteries periodically. Look for cracks in the cover and case.

  • Page 86: Load Center

    Section 6: Electrical System Breaking this connection prevents discharge of the chassis battery (used to start the engine) when using 12-volt devices in the house section of your motorhome. When the engine is running the isolator solenoid engages allowing the house batteries to be charged by the vehicle alternator.

  • Page 87: Volt Circuit Breakers

    Section 6: Electrical System Automatic Transfer Switch (ATS) Your motorhome is equipped with an Automatic Transfer Switch. The ATS is microproces- sor controlled and will automatically detect which power source is being used (generator or shore power) and allow power from that connection only. You will not have to plug and unplug power to the coach if you decide to run the generator.
  • Page 88 Section 6: Electrical System Maintenance Replacement circuit breakers must be of the same voltage, amperage rating and type. Never use a higher rated replacement circuit breaker; doing so may cause a fire by overheating the RV wiring. At the beginning of the camping season, inspect the circuit breakers and replace as needed. Test by turning each circuit breaker “off”...

  • Page 89: Approximate Electrical Load Ratings

    Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling sSystem 95.0 AMPS* LP Detector .125 AMP Light; LED 1.7 AMPS Light;...
  • Page 90 Section 6: Electrical System 120-Volt, 30 AMP AC Electric System (if so equipped) The 30 amp 120-volt 60hz AC electrical system is designed to operate on 1 leg of 120-volt power at a maximum current flow of 30 amperes. Exposure to voltages higher or lower than a nominal 120-volts will damage or shorten the service life of the electrical system and appliances.
  • Page 91 Section 6: Electrical System Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. Regularly inspect the shore power cord for cuts, cracks, worn insulation and other damage.
  • Page 92 Section 6: Electrical System CARBON MONOXIDE IS DEADLY! Do not run the generator when your motorhome is indoors or in a confined space. Asphyxiation or carbon monoxide poisoning hazards exist whenever generator exhaust gasses can ac- cumulate. MOVING PARTS AND ELECTRICITY can cause severe personal injury or death.

  • Page 93: Starting The Generator

    Section 6: Electrical System Starting the Generator Your motorhome, depending on the model, will have a touchscreen to control the generator or manual switches located at the Command Center panel. There may also be secondary switches located on the dash or on the generator itself. A digital hour meter that keeps track of generator hours used is located either on the touchscreen or on a separate hour meter on the Command center panel.

  • Page 94: Solar Prep (If So Equipped)

    Section 6: Electrical System Solar Prep (if so equipped) Your motorhome may be equipped with a roof mount solar panel quick connection. This allows a (customer purchased) solar panel to be installed permanently on the roof. Installa- tion will consist of the solar panel(s), regulator and wiring/fusing between the regulator and batteries.

  • Page 95: Fuel Safety

    Section 7: Fuel System Fuel Safety Automotive fuels can cause serious injury or death if misused or mishandled. If you have further questions, consult your dealer or Customer Service for assistance. Always shut OFF the vehicle engine while refueling. Do not bring or store fuel or other flammable liquids inside the mo- torhome because a fire or explosion may result.

  • Page 96: Exhaust Gas Fumes

    Section 7: Fuel System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a parked motorhome with either the engine running or the generator running there is a potential for exhaust fumes to filter back into the motorhome.
  • Page 97 Section 7: Fuel System leakage. Travel vibrations can loosen fittings. Have the vehicle propane system checked at all connections soon after the purchase of your vehicle, and after the initial filling of the propane tanks. Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year) by a qualified propane service representative as part of your normal maintenance is recommended.
  • Page 98 Section 7: Fuel System Servicing or Filling Always shut OFF the engine while refueling. Do not smoke and do not operate other ignition sources while refueling. When the propane container is disconnected from the main supply hose and the P.O.L. connection, install the P.O.L. plastic cap that is at- tached to the container.
  • Page 99 Section 7: Fuel System Propane Regulator Propane regulators must always be installed with the regulator vent facing downward. Regulators that are not located in baggage compartments have been equipped with a protective cover. Make sure the regulator vent faces downward and (if applicable) the cover is in place to minimize vent blockage that could result in excessive gas pressure causing fire or explosion.

  • Page 100: Propane Use And Safety

    Section 7: Fuel System Propane Use and Safety Propane is a colorless and odorless gas that, in the lique- fied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully per- form the procedure listed on the propane system label.
  • Page 101 Section 7: Fuel System tally exhausted. Using one cylinder until it is empty and then using the second cylinder will allow you to fill the empty cylinder at your convenience without running out of propane. Cooking With Propane Gas Do not turn gas range burner controls to ON and allow gas to escape before lighting.
  • Page 102 Section 7: Fuel System Traveling With Propane NOTE: Some states prohibit propane appliances to be operated dur- ing travel, especially in underground tunnels. Know the laws for the areas where you travel. Use care when fueling your motor fuel tanks and/or propane containers.

  • Page 103: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).
  • Page 104 Section 8: Plumbing System Operation Press only one tact switch at a time. As you push either the FRESH, BLK GREY1 or GREY2 switch, one or more LED lights will illuminate (from left to right) indicating the content level for that tank. When pushing the “BATT” switch, the LED lights illuminate from left (lowest) to right (highest) to indicate the estimated auxiliary battery condi- tion.

  • Page 105: Fresh Water System

    Section 8: Plumbing System NOTE: This light will not appear on touchscreens, RV remote controls or on a WiFi app, it will only appear on the Command Center switch panel. Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors.

  • Page 106: Water Purification System (If So Equipped)

    Section 8: Plumbing System 12-Volt Water Pump and Switch There must be sufficient 12-volt DC power to run the water pump when your recreation vehicle is not hooked up to city water. Once activated, the water pump (also known as the demand pump) will self-prime, and provide water.

  • Page 107: Draining The Fresh Water System

    Section 8: Plumbing System Using a spanner wrench, rotate the filter housing. Unscrew the hous- ing completely, dump water out and remove the filter (dispose of the old filter properly). Clean the inside of the filter housing with mild detergent. Thorough- ly rinse and wipe clean.

  • Page 108: Nautilus P3 Uni-Dock Utility Center

    Section 8: Plumbing System located inside the RV adjacent to the water tank (turn 45° to open or close). Open the “low point drains” by turning, then pulling the handles up. They are installed at the lowest point of the water lines. A label is placed on the outside of the RV to indicate where the drains are located.
  • Page 109 Section 8: Plumbing System The city water connection inlet is located in the Uni-Dock utility center. Use a non-toxic drinking water hose dedicated only to supplying fresh water. To prevent contamination, keep the non-toxic drinking water hose from coming into contact with the ground. Install the city water connection inlet cap when the fresh water connection is not being used.
  • Page 110 Section 8: Plumbing System Connect the other end of the hose to a pressurized fresh water source (faucet or spigot). Turn the pressurized water source ON, the tank should begin filling. When water has reached the desired level, turn the pressurized water source OFF. DO NOT OVERFILL (tank level can be viewed on the monitor panel inside the RV).
  • Page 111 Section 8: Plumbing System NOTE: To fill the fresh water tank without a pressurized water source, re- fer to SANITIZE (Siphon Fill) section, and use a container holding fresh potable water and a hose. Water will be drawn into the tank by the pump. There is no gravity fill inlet on the recreation vehicle.
  • Page 112 Section 8: Plumbing System How to Sanitize Turn water heater power OFF (both electric & LP gas on standard storage water heater). Single switch inside the RV for Truma AquaGo tankless water heater. Set the col- ored valves to SANITIZE as indicated on the utility center label.
  • Page 113 Section 8: Plumbing System Open all hot water faucets one by one until water begins to flow continuously and a chlorine smell is noticeable. Include outside shower faucets (if so equipped). Close hot water faucets. Repeat this process with the cold water faucets.
  • Page 114 Section 8: Plumbing System Lingering Chlorine Taste: If a chlorine taste lingers in the water, flush the water system with a solution consisting of one-quart vinegar to five gallons of clean water. Re-flush as necessary. The vinegar solution may damage the water heater or the water filter, so both must be bypassed again before performing this operation.
  • Page 115 Section 8: Plumbing System Refill the fresh water tank with clean potable water. Use the city water fill connection inlet and one of the two methods explained in Step 3. Open faucets and check that the chlorine taste is gone. 10.
  • Page 116 Section 8: Plumbing System Winterize with Air Pressure This method uses compressed air to blow out any remaining water in the system after ini- tially draining water using drain valves. Tools required would be an air compressor and a blowout plug. Before applying air pressure to the utility center, 4 colored valves (WHITE, RED, GREEN, BLUE) MUST be set to 45°...
  • Page 117 Section 8: Plumbing System NOTE: Filters should be replaced at the beginning of the camping season or if they have been exposed to contaminated water or antifreeze. Open all faucets in the RV. If there is an outside shower, attach the shower hose to the shower, and open shower faucets.
  • Page 118 Section 8: Plumbing System If the recreation vehicle is going to be stored in a non-temperature controlled environment with a risk of temperatures reaching 32°F (0°C) or lower, the air pressure method is not adequate, winterizing with RV antifreeze must be used in the plumbing system.
  • Page 119 Section 8: Plumbing System NOTE: When set to WINTERIZE: antifreeze will not enter the water heater or the fresh water tank. There are no dedicated water heater bypass valves. Turn the water pump ON with the pump switch on the utility center panel. Antifreeze will be drawn into the water lines when a fixture in the RV is opened.

  • Page 120: Water Heater

    Section 8: Plumbing System As an added safety measure, open the Macerator Bypass valve and let it drain. The bypass valve may be either at the utility center or under the RV. De-winterize the macerator system: Emptying the black tanks in the spring will flush antifreeze out of the macerator system.
  • Page 121 Section 8: Plumbing System Water Heater Bypass Use the factory installed water heater bypass, available in most floor plans, to avoid filling the entire water heater with RV antifreeze. See the Utility Center section for details on using the bypass system. High Altitude Deration Operation of the water heater at high altitudes may require derating.
  • Page 122 Section 8: Plumbing System is not warrantable. It is recommended the water heater be drained and bypassed during the winterization process, particularly if introducing RV antifreeze into the plumbing sys- tem. Never drain the water heater when it is HOT or UNDER PRESSURE. Outside Shower and Courtesy Light A handheld shower assembly with both hot and cold water is available in the utility center for washing or rinsing.

  • Page 123: Bathroom Tub / Shower

    Section 8: Plumbing System Bathroom Tub / Shower Keep the water heater and holding tank capacities in mind when using the fresh water sys- tem. The used water will drain through the plumbing pipes into the grey water holding tank. Be sure the water heater is ON and had sufficient time to heat the water.
  • Page 124 Section 8: Plumbing System piping to open the drain. Passing a cleanout tool through the waterless valve may cause damage to the internal seal that may potentially allow sewer gases to escape into the RV interior. The waterless trap can be unscrewed from the water lines. A label has been placed near the location of the waste valve that reads as follows: REMOVE WATERLESS TRAP BEFORE USING MECHANICAL DRAIN CLEANING DEVICES...
  • Page 125 Section 8: Plumbing System Never leave the black tank drain in the open position continuously when connected to the campground sewer system. Leaving the drain open will allow the liquid to drain out increasing the potential for a blockage in the tank.

  • Page 126: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System Waste (grey) holding tank preparation No special preparation is required, however, placing a small quantity of chemicals into this tank, such as baking soda or an approved RV chemical, will reduce odors from food particles in the system. Cleaning and Maintenance The toilet should be cleaned regularly for maximum sanitation and operational efficiency.

  • Page 127: Tank Heaters (If So Equipped)

    Section 8: Plumbing System Tank Heaters (if so equipped) Your recreation vehicle may be equipped with heaters for the fresh, gray, black water tanks and the water lines or drain lines. The larger tank heaters are 120VAC and attach directly to the tanks.

  • Page 128: Toilet (If So Equipped)

    Section 8: Plumbing System Toilet (if so equipped) The toilet is efficient and easy to operate. Prior to using the sanitation system, it is strongly recommended to flush the toilet several times to release sufficient water into the holding tank. Generally, more water is required only when flushing solids. It is important to prevent solid waste buildup.

  • Page 129: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Air Conditioner The air conditioning system is controlled by a thermostat. Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 130: Fireplace (If So Equipped)

    Section 9: Heating & Cooling NOTE: For RV models with touch screens, the powered roof vent(s) may be controlled on one of the selectable screens on the touch screen. Furnace The furnace installed in your recreation vehicle is controlled by a 12-volt DC thermostat. Depending on your model, there may be up to two thermostats enabling you to control the temperature to your comfort level.

  • Page 131: Section 10: Appliances

    Section 10: Appliances Microwave To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source. Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.
  • Page 132 Section 10: Appliances Cooking With Propane (if so equipped) See the Propane System section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Cooktops, Range and Oven (if so equipped) For detailed operating and safety information, refer to the manufacturer’s user guide.

  • Page 133: Range Hood (If So Equipped)

    Section 10: Appliances Do not use aluminum foil on the electric range cooktop, as this material will damage the cooktop surface if it melts. Do not use aluminum foil under any circumstances on the electric range cooktop. Gas Drop-In Cooktops (if so equipped) Depending on your model, it may be equipped with either a 2 burner or 3 burner cooktop.
  • Page 134 Section 10: Appliances Whenever the stove in the RV is being used: The range hood MUST be turned on, and the inner flap MUST be unsnapped and free to move. Failure to do so can create an asphyxiation hazard by restricting air flow to this vent. Refrigerator The refrigerator is not intended for quick freezing or cooling.
  • Page 135 Section 10: Appliances Converter output (12VDC) is not intended for normal operation of the 3-way refrigerator. When the camping trailer is parked and the power cord is plugged in, set the 3-way refrigerator to “AC power.” The “DC mode” is to be used only when traveling and will pull power from the auxiliary battery charge line (if so equipped).

  • Page 136: Water Heater - See Plumbing Section

    Section 10: Appliances IMPORTANT: Do not allow the Stainless Steel Cleaner and Polish to come into con- tact with any plastic parts such as the trim pieces, dispenser covers or door gaskets. If unintentional contact does occur, clean plastic part with a sponge and mild detergent in warm water.
  • Page 137 Section 11: Electronics HDTV Antenna/Satellite System Your recreation vehicle may be equipped with an exterior amplified high definition TV antenna. The antenna comes equipped with a signal meter and a power injector to aid in receiving the strongest possible signal when tuning in HDTV stations.

  • Page 138: Exterior Entertainment Center (If So Equipped)

    Section 11: Electronics Antenna Power Supply (if so equipped) For good station reception, the antenna power supply must be turned ON to view local television stations. Turning the antenna power supply ON sends 12-volt DC through the cable to the TV roof antenna. The voltage energizes the transistors in the antenna head amplifier.

  • Page 139: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 140 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
  • Page 141 Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, first try on a spot in an inconspicuous area. Sofa and Dinette Always use seatbelts if sitting in the sofa or dinette while the motorhome is in transit Your motorhome may be equipped with one of the following sofa styles.
  • Page 142 Section 12: Interior Booth Dinette (if so equipped) The dinette is designed to seat up to four adults. Depending on your model, there may be a storage area in the dinette bench. To access this storage, remove all the cushions and lift up on the bottom seat support.

  • Page 143: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Free Standing Dinette Chairs (if so equipped) Two free standing chairs and two folding chairs are included in the free standing table/chair package (if so equipped). When traveling in the motorhome, it is recommended the free standing dinette chairs be fastened securely at the dinette table, and the folding chairs be secured in a closet or storage area.
  • Page 144 Section 12: Interior Countertops To prevent permanent damage Always use hot pads or trivets under hot pans, dishes, or heat producing appli- ances. Use a cutting board to prevent unnecessary damage to the countertops. Do not cut directly on the solid surface countertop. Avoid harsh chemicals such as drain cleaners, oven cleaners, etc.

  • Page 145: Privacy Drape Installation

    Section 12: Interior Vinyl Flooring Periodically vacuum or sweep to remove dirt and gritty particles. Although most common spills will not permanently stain the vinyl floors, they are usually easier to remove if wiped up before they set. Blot with a paper towel and wipe clean with a damp cloth. Do not use dish detergents or vinegar and water because they will dull your floor.
  • Page 146 Section 12: Interior Before lifting, be sure there is nothing on the bed that will restrict its movement or add extra weight. Use caution when opening or closing the bed to keep hands and fingers at the end ledge provided (not on the side or farther back than necessary). Exercise extreme caution when opening the bed storage platform.
  • Page 147 Section 12: Interior There should be no people, pets or objects on or below the bunk while raising or lowering it. Failure to comply may result in serious injury or property damage. With vehicle in transit, the bunk should always be in the raised storage position with the interlock belt latched.
  • Page 148 Section 12: Interior Bunk Beds (if so equipped) Your recreational vehicle may be equipped with bunk style beds. Bunk bed weight ratings will vary depending on the style of bunk bed. Refer to the warnings for bunk beds below. Bunk Bed Ladder (if so equipped) Your recreational vehicle may be equipped with a ladder to access the upper bunk.

  • Page 149: Cleaning The Exterior

    Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. For recreation vehicles with painted exterior graphics, if desired you may wash and wax your vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface.
  • Page 150 Section 13: Exterior Drying the recreation vehicle is just as important as washing your vehicle. Tap and well water contain many chemicals that could water stain your vehicle’s finish. We suggest using a damp natural or synthetic chamois. Other drying products such as lint-free micro-fiber towels work as well.
  • Page 151 Section 13: Exterior Damaged paint To prevent corrosion, touch up small cracks and scratches in the paint coat as soon as pos- sible with touch-up film or paint. Carefully check the body areas facing the road and the tires for damage to the paint coat caused by flying stones, etc. Use the closest automotive paint (available locally) match possible when touch-up paint is needed.

  • Page 152: Exterior Ladder (If So Equipped)

    Section 13: Exterior Windows To avoid exhaust gas entry into the motorhome, keep windows closed when the chassis or generator engines are running. Any ventilating window may permit water inside, especially during heavy rainstorms or while driving. This is normal and water should only be seen in the lower track portion of the window frame.
  • Page 153 Section 13: Exterior LADDER CAPACITY MAXIMUM 300 lbs. (136 kg) DO NOT exceed the ladder maximum weight rating. The maximum rating includes the person's weight PLUS weight of items carried. When climbing: • Always face the ladder. • Climb slowly with weight centered between side rails. •...
  • Page 154 Section 13: Exterior Notes: Maintenance Record Table of Contents...

  • Page 155: Section 14: Travel/Camping/Storage Checklists

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Refer to your Chassis Guide for information on chassis pre-trip inspections and maintenance.

  • Page 156: Motorhome Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite: Check the area under the motorhome after overnight parking and look for fuel, water, oil or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks (if so equipped). Empty black and gray holding tank, rinse as needed.
  • Page 157 Section 14: Travel/Camping/Storage Checklists Drain and flush all holding tanks (fresh water, gray water, black water and/or hot water tanks). Adding fuel stabilizer to the generator will aid in preventing condensation and fuel varnishing. Turn OFF the motorhome 12-volt battery disconnect switch. Turn OFF the inverter mode at remote.
  • Page 158 Section 14: Travel/Camping/Storage Checklists Notes: Maintenance Record Table of Contents...

  • Page 159: Featured Components Quick Reference Chart

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 160 Section 15: Additional Information www.airxcel.com/coleman- Thermostat Coleman-Mach mach Toilet Thetford Corp. www.thetford.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Water Pump, 12V Shurflo East www.shurflo.com Maintenance Record Table of Contents...

  • Page 161: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Engine: Engine Serial#: Serv i ce P e r f o r m e d Mileage Work Performed Notes Date Maintenance Record Table of Contents...
  • Page 162 Section 15: Additional Information Notes: Maintenance Record Table of Contents...
  • Page 163 Section 15: Additional Information Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ Change of Owner □Transfer of Limited Warranty...

Table of Contents
