REDHAWK
REDHAWK SE
2023 OWNER'S MANUAL
A subsidiary of Thor Industries, Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REDHAWK 2023 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jayco REDHAWK 2023

Summary of Contents for Jayco REDHAWK 2023

  • Page 1 REDHAWK REDHAWK SE 2023 OWNER’S MANUAL A subsidiary of Thor Industries, Inc.
  • Page 3 Suggestions For Obtaining Service Obtaining Service At Our Customer Service Facility Obtaining Service For Separately Warranted Items Parts and Accessories Aftermarket Accessories 2023 Jayco Motorized Limited Warranty Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Fire Safety Fire Extinguisher...
  • Page 4 Table of Contents Section 6: Electrical System Command Center Energy Management System 30A Testing The Campsite Power Connection Power Converter 12-volt DC System Batteries Load Center Automatic Transfer Switch (ATS) 120-Volt Circuit Breakers Approximate Electrical Load Ratings 120-Volt 30-amp AC Electric System Generator Starting the Generator Solar Prep...
  • Page 5 Table of Contents Section 11: Electronics Exterior Entertainment Center (if so equipped) Section 12: Interior Cleaning The Interior Sofa and Dinette Pantry or Hutch (if so equipped) Countertops Flooring Privacy Drape Installation Bed Storage Bunk Beds and Bunk Ladders (if so equipped) Cab-Over Bunk Bed Section 13: Exterior Cleaning The Exterior...
  • Page 6 WARNING: Read all instructions in this manual and component man- ufacturer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.

  • Page 7: Section 1: Warranty & Service

    Commercial use means using the recreation vehicle as a business asset such as a mobile office or using the recreation vehicle for lease or rental purposes. Jayco reserves the right to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever. Recreation vehicles built for sale in Canada may differ to conform to Canadian Codes.
  • Page 8 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.
  • Page 9 Section 1: Warranty & Service Failure to contact Jayco Customer Service, unauthorized or improper warranty re- pairs, or failure to return requested original parts may result in loss of reimbursements and/or loss of warranty. To Contact Us Mailing address Shipping address Jayco, Inc.

  • Page 10: About This Manual

    Section 1: Warranty & Service About This Manual This manual is a guide to operation of the features, equipment and controls in your rec- reation vehicle. If you find components vary significantly from what is described, please contact your dealer to ensure you have the correct information. Nothing in this manual creates any warranty, either expressed or implied, nor does it cover every possible detail of equipment, standard or option, installed on or in your recreation vehicle.

  • Page 11: Reporting Safety Defects

    Section 1: Warranty & Service ™ NOTE: Gives helpful information This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. Indicates a potential situation that,if not avoided, may result in property dam- age or damage to your motorhome.

  • Page 12: Customer Responsibility

    Section 1: Warranty & Service In Canada: If you believe your vehicle has an alleged safety defect, you should contact Transport Canada and our Customer Service Department immediately. To file a safety concern, you can complete an on-line form at https://tc.canada.ca/en/road- transportation/defects-recalls-vehicles-tires-child-car-seats/report-potential-safety-defect- vehicles-tires-child-car-seats, or call to speak with a defect investigator.

  • Page 13: Obtaining Service At Our Customer Service Facility

    Section 1: Warranty & Service Contact your dealer at once Do not wait until you are ready to use your RV. Your dealer may not be able to service it im- mediately and/or the repair may require parts be ordered. The dealer’s service department is busiest on Mondays, Fridays and before holidays.

  • Page 14: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreation vehicle before delivery, and has an interest in your continued satisfaction. We recommend your dealer perform all inspection, warranty and maintenance services. Some dealers may be authorized service centers for those OEMs whose products are warranted separately and excluded from the Limited Warranty.
  • Page 15 HOME IS TITLED OR REGISTERED IN A BUSINESS NAME OR WHEN THE JAYCO IS SOLD IN CANADA. There is no warranty of any nature made by Jayco beyond that contained in this Limited Warranty. No person has authority to enlarge, amend or modify this Limited Warranty. The dealer is NOT Jayco’s agent.
  • Page 16 Jayco reserves the right to make changes in the design or material of its prod- ucts without incurring any obligation to incorporate such changes in any product previously manufactured.
  • Page 17 (1) you notify Jayco or an authorized dealer within 10 days of your discovery of a defect; AND (2) you deliver the Motor home to Jayco OR an authorized dealership at your cost and expense.
  • Page 18 The written warranty provided by the manufacturer of the component part is the direct and exclusive responsibility of that manufacturer). EVENTS DISCHARGING JAYCO FROM OBLIGATION UNDER WARRANTY: • Any rental, business or commercial use or purchase of the Motor home;...
  • Page 19 Jayco, your Warranty will be registered. The failure to submit this warranty registration to Jayco will not affect your rights under this limited warranty as long as you can present proof of purchase, however, it can cause delays in obtaining the remedies offered by this limited warranty, and it may adversely affect any servicing facility’s ability...
  • Page 20 Section 1: Warranty & Service ™ Notes: Maintenance Record Table of Contents...

  • Page 21: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 22: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the window. Push the lever (and window) out to open and exit the vehicle.

  • Page 23: Smoke Alarm

    Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.
  • Page 24 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
  • Page 25 Section 2: Occupant Safety (but not limited to): acetone, alcohol, butane and gasoline. These chemicals can be found in commonly used items such as deodorants, colognes, per- fumes, adhesives, lacquer, kerosene, glues, wine, liquor, most cleaning agents and the pro- pellants of aerosol cans.

  • Page 26: Extended Or Full Time Usage

    Section 2: Occupant Safety To aid in dissipation, ventilate the recreation vehicle by opening all windows and circulate the air with a fan. This label is located inside the vehicle near the entry door. The label should be left permanently affixed to the recreation vehicle.

  • Page 27: Section 3: Pre-Travel Information

    Section 3: Pre-Travel Information Vehicle Labels Decals and data plates used throughout the motor home aid in its safe and efficient operation; others give service instructions. Read all decals, data and instruction plates before operat- ing your recreation vehicle. Any decal, data or instruction plate painted over, damaged or removed should be replaced.
  • Page 28 Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity): The upper portion of this yellow label is federally required and indicates the total combined weight value of occupants and cargo that may be placed in or on your motor home as it was manufac- tured and weighed before leaving the factory.

  • Page 29: Loading Your Motor Home

    Section 3: Pre-Travel Information Loading Your Motor Home Never load the motor home in excess of the GVWR or the GAWR for either axle. Overloading your motor home may result in adverse han- dling characteristics and damage to the chassis. DO NOT EXCEED YOUR GVWR! This means you should weigh your vehicle as loaded for your normal travel to determine the actual weight.

  • Page 30: Weighing Your Motor Home

    Section 3: Pre-Travel Information White Ground Blue Electric Brakes Green Running lights Black House batteries charge line Stop & left turn Brown Stop & right turn Yellow Back up Lights The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact.
  • Page 31 Section 3: Pre-Travel Information Dump the gray and black water holding tanks before traveling to avoid carry- ing unnecessary weight. Full tanks can affect your fuel consumption, and de- pending on tank location, can affect your vehicle handling characteristics. If you cannot immediately empty your holding tanks, reduce your vehicle speed until you reach a dumping station.
  • Page 32 Section 3: Pre-Travel Information ™ Notes: Maintenance Record Table of Contents...

  • Page 33: Vehicle Operation

    Section 4: Vehicle Operation Vehicle Operation Your motor home will travel safely and comfortably at highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Allow more time to go around the vehicle you are passing. Avoid situations that might require sudden momentum changes as the length of the motor home affects your ability to quickly cut back into traf- fic.
  • Page 34 Section 4: Vehicle Operation Towing Behind Your Motor Home Do not install a frame equalizing type hitch on your motor home. Towing will affect vehicle handling, durability and fuel economy. Exceeding any of the listed weight ratings will result in unacceptable overall vehicle performance. Your safety and satisfaction require proper use of correct equipment.

  • Page 35: Power Entrance Step

    Section 4: Vehicle Operation Contact your dealer for assistance in determining whether a separate braking system is rec- ommended for your towing and traveling safety. Failure to follow these instructions will create a safety hazard and may result in an accident. Maintenance Keep the hitch clean along with your general frame maintenance.

  • Page 36: Seat Belts

    Section 4: Vehicle Operation Driver and Passenger Seat Do not adjust the seat while driving. After adjusting the seat, make sure that it is locked in position. To ensure that the seat is locked securely, try to move the seat forward or backward without using the adjusting lever or button.

  • Page 37: Child Safety Restraint Systems

    Section 4: Vehicle Operation Always use seat belts. In an accident, injury to the driver and passengers may be reduced if seat belts are properly used. If your motor home is equipped with a booth dinette, hide-a-bed sofa, or easy bed sofa they will have two-point lap-seat belts installed. Seat belts should be used in all seating positions.
  • Page 38 Section 4: Vehicle Operation Booth Dinette (if equipped) The dinette table should be lowered and secured with the safety strap when- ever adding a child safety seat to the dinette seat. Failure to follow these guidelines can result in serious injury or death. If your child requires a child safety restraint system (seat), it can be installed in the forward or rear facing booth dinette according to the instructions of the safety seat manufacturer.

  • Page 39: Outside Rear View Mirrors

    Section 4: Vehicle Operation Outside Rearview Mirrors Adjust the outside rearview mirrors before driving. After adjusting the front driver’s seat, adjust the outside rearview mirrors to your driving preference. Have someone help you adjust the mirrors in the desired direction for maximum rear visibility before driving.

  • Page 40: Campsite Hook-Up

    Section 4: Vehicle Operation Campsite Hook-Up Refer to Electrical Systems section before connecting the shore line power cord (when using full hook-up) OR before starting the generator or operating the ve- hicle on 12-volt power when dry camping. Refer to Fuel & Propane System section before using the LP system. Open the LP gas tank valve (if so equipped) slowly.
  • Page 41 Section 4: Vehicle Operation Prior to operation, make sure the following conditions are met: The recreation vehicle is parked on a reasonably level surface. EXCESS ANGLE will appear on the LCD display if the coach is 3.5° out of level front to rear or side to side. Refer to error modes in the OEM operating manual in your warranty packet.
  • Page 42 Section 4: Vehicle Operation When in alarm mode, all LEDs will flash and buzzer will beep. The Status LEDs will show the system status. The system performs an automatic retract. No other features are available in this mode. Miscellaneous ○ The system automatically shuts down after (4) minutes of no operation.
  • Page 43 Section 4: Vehicle Operation ™ NOTE: The right and left jacks are used to level the coach side to side. Push- ing LEFT on the control panel will extend both left jacks. Pushing RIGHT will extend both right jacks. Jacks always work in pairs; both front, both right, etc.

  • Page 44: Emergency Stopping

    Section 4: Vehicle Operation Jacks Down Alarm The Leveling System is designed to sound an alarm and illuminate the control panel in the event of (2) possible scenarios: A “RETRACT” hose leaks. The pressure holding the jacks in the retracted position falls to approximately 1500 PSI. If the alarm sounds and the control panel illuminates and flashes while driving the vehicle: Immediately find a place to pull vehicle off roadway.

  • Page 45: Front Axle Tire Alignment

    Section 4: Vehicle Operation Never allow anyone to go under the motor home while it is being lifted by towing equipment. Be aware of the strap locations. Misplaced straps could result in damage to the exterior of your unit. Damage resulting from misplaced straps is the responsibility of the towing company, and is not covered by the unit warranty.
  • Page 46 Section 4: Vehicle Operation After your first trip, check the wheel lug torque periodically for safety according to your Chassis Guide. If you suspect the wheel lug nuts have loosened at any time, have them checked and torqued to the proper limits immediately. Lugs should be checked: After winter storage After a wheel removal...
  • Page 47 Section 4: Vehicle Operation Tire pressure Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death. You must follow the manufacturer’s inflation guidelines for maximum load capacity; under-inflation is just as dangerous as over-inflation.

  • Page 48: Changing A Tire

    Section 4: Vehicle Operation It is recommended that the tire pressure be checked at the beginning of each trip to obtain the maximum life of the tire. Follow the instructions listed on the Federal Certification label, to determine the correct tire pressure. Under- inflation may cause tire failures and swaying resulting in loss of control, in- jury, death or property damage.
  • Page 49 Section 4: Vehicle Operation The effects of wind and rain on an awning are unpredictable and can cause severe damage to the awning and/or the recreation vehicle. Retract the awning If wind or extended periods of rain are expected. If you leave the RV unattended for a length of time, to avoid unexpected climate conditions.
  • Page 50 Section 4: Vehicle Operation Make sure the fabric is dry before closing the awning. Air-dry only. Never apply heat to the fabric. Your recreation vehicle includes the following options: Power window awnings Slide out awnings Power awning over entrance door Power patio awning Power switches to operate the awnings are found on the multiplex touchscreen and entry door switch.

  • Page 51: Section 5: Slideout Systems

    Section 5: Slideout Systems Electric Slide Room(s) (if so equipped) The mechanical components of the slide out are gear driven. Electric powered slideout room systems have a manual override to allow you to extend or retract the slideout room(s) in case of a power loss.
  • Page 52 Section 5: Slideout Systems sure the slideout has extended properly and has adequate clearance from any outside obstructions. If the slideout is equipped with rubber seals, verify that the corners of the black rubber seal are set up correctly. The seal corners are cut at a 45°...
  • Page 53 Section 5: Slideout Systems Error Codes: When an error code occurs during operation, the board LEDs lights will in- dicate where the problem is. For motor specific faults the green LED will blink (1) time for motor #1 and (2) times for motor #2. The red LED will blink 2 to 9 times depending on the error code.
  • Page 54 Section 5: Slideout Systems Using either a wall or command center panel switch, press and hold the switch toward the word IN or RETRACT until the unit comes in completely. This will allow you to get the recreation vehicle to a service center to have the slideout malfunction diagnosed. Call your dealer or Customer Service if: During the override procedure the motors are not synchronized.
  • Page 55 Section 5: Slideout Systems The room must be travel locked to keep the room in place for road travel. DO NOT MOVE THE RV UNLESS THE MOTORS ARE PLUGGED IN TO THE CONTROLLER AND THERE IS BATTERY POWER TO THE RV.
  • Page 56 Section 5: Slideout Systems Locate the slideout motor (Fig. 1) mounted to one of the slideout rails. Some models may require removal of the underbelly or cover to access the motor. In a bedroom slideout, it may be located under the bed. Rotate the brake lever, on the backside of the motor, counter-clockwise (looking from the rear of the motor) about 1/8 of a turn to the released position.
  • Page 57 Section 5: Slideout Systems Remove (4) screws holding the panel to the top of the compartment. Remove the cover. Unplug the motor leads at the connector. Gray connec- tor with red and black wires. To release the motor brake you must depress the spring lock lever, which then allows you to pivot the brake le- ver, which in turn releases the brake.
  • Page 58 Section 5: Slideout Systems ™ Notes: Maintenance Record Table of Contents...

  • Page 59: Section 6: Electrical System

    Section 6: Electrical System Command Center The command center is typically located inside the entrance door or in the living area of the RV, and contains switches and controls. Command center applications, configurations and components may vary by model. Command Center Panel or Command Center Panel with Switch Modules Items found on these panels may include: Fuel gauge and hour meter with switches for fuel pump...

  • Page 60: Testing The Campsite Power Connection

    Section 6: Electrical System Operation This system monitors incoming power and has the ability to turn off a few select loads. It can manage incoming power and avoid tripping the shore circuit breaker. 30A Service would be the normal setting displayed on the digital readout. By pressing the SELECT button you can toggle from 30A to 20A to 15A.

  • Page 61: Power Converter

    Section 6: Electrical System Do not hook the power cord to any receptacle until you have verified proper polarity and grounding. DO NOT plug the shore power cord into a campsite receptacle(s): That has reverse polarity That has non-functioning ground circuits That shows outward signs of heat damage.
  • Page 62 Section 6: Electrical System If using multiple batteries they must be the same brand and type. Adding more batteries will provide longer use of DC appliances when not on shore power but may reduce charging efficiency. The battery works in conjunction with the converter to supply DC power to the RV.

  • Page 63: Volt Dc System

    Section 6: Electrical System There are no customer serviceable parts inside the converter case and the manufac- turer’s warranty will be void if the case has been removed. If you have further concerns contact your dealer. For detailed safety and operating information, refer to the manufacturer’s owner’s manual. Converter w/Charge Wizard (if so equipped) Some converters may be equipped with a charge wiz- ard There are (3) possible charging modes;...
  • Page 64 Section 6: Electrical System Replacing a Fuse Before replacing a fuse, always turn off the electrical components protected by it. Disconnect the shore power cord. Inverter should be OFF. Remove the fuse panel cover to check fuses. Pull the fuse straight out of the fuse block. Insert a new fuse of the same specified voltage, amperage rating and type in the original location.
  • Page 65 Section 6: Electrical System House Batteries Unless a battery has been fully discharged, house auxiliary batteries are normally charged in one of two ways: When the power cord is plugged into 120-volt shore power, or when the generator is operational, the inverter/charger functions as a battery charger and will auto- matically charge the house batteries when required.

  • Page 66: Load Center

    Section 6: Electrical System When engaged the battery disconnect solenoid supplies battery power to all accessories con- nected to the house 12-volt fuse panel. The solenoid must be engaged for the 12-volt house electrical system to operate. The battery disconnect feature should be used to disconnect the motor home from house battery power during periods of storage or during maintenance.

  • Page 67: Volt Circuit Breakers

    Section 6: Electrical System Automatic Transfer Switch (ATS) Your motor home is equipped with an Automatic Transfer Switch with built in reverse polar- ity protection. The ATS is microprocessor controlled and will automatically detect which power source is being used (generator or shore power) and allow power from that connec- tion only.

  • Page 68: Approximate Electrical Load Ratings

    Section 6: Electrical System Replacement circuit breakers must be of the same voltage, amperage rating and type. Never use a higher rated replacement circuit breaker; doing so may cause a fire by overheating the RV wiring. Maintenance At the beginning of the camping season, inspect the circuit breakers and replace as needed. Test by turning each circuit breaker “off”...
  • Page 69 Section 6: Electrical System 120 VOLT SYSTEM Air Conditioner 18 AMPS Coffee Maker 6-12 AMPS Converter (each) 8 AMPS DVD System 3 AMPS Fireplace 15 AMPS Hair Dryer or Curling Iron 10-14 AMPS Microwave 15 AMPS Satellite Receiver 2 AMPS 2-4 AMPS Vacuum Cleaner 8 AMPS...
  • Page 70 Section 6: Electrical System 30-amp Power Cord Do not hook up the power cord to any receptacle until you have verified proper polarity and grounding. Polarity indicators can be purchased in most electrical and hardware stores. Do not use any cheater plug, adapter or extension cord to reconfigure incoming AC power or break the continuity of the circuit connected to the grounding pin.
  • Page 71 Section 6: Electrical System CARBON MONOXIDE IS DEADLY! Do not run the generator when your motor home is indoors or in a confined space. DO NOT use the AGS AUTO ON or QUIET ON modes (if so equipped) when your motor home is indoors or in a confined space. Asphyxiation or carbon monoxide poisoning hazards exist whenever gen- erator exhaust gasses can accumulate.

  • Page 72: Starting The Generator

    Section 6: Electrical System Completely fill the chassis diesel fuel tank to prevent water condensation and rust in the tank (only with a diesel fueled generator). Cover the end of the generator exhaust pipe with screen to prevent bug and rodent intrusion.
  • Page 73 Section 6: Electrical System Solar Panel (if so equipped) Solar panels produce 12-volt DC electricity when exposed to sunlight. Energy produced by the solar panels is used to charge the house auxiliary and chassis batteries. Controller The controller is capable of charging two battery banks – house and chassis. A status LED indicates connectivity of batteries.
  • Page 74 Section 6: Electrical System ™ Notes: Maintenance Record Table of Contents...

  • Page 75: Fuel Safety

    Section 7: Fuel & Propane System Fuel Safety Automotive fuels can cause serious injury or death if misused or mishandled. If you have further questions, consult your dealer or Customer Service for assistance. Always shut OFF the vehicle engine while refueling. Do not bring or store fuel or other flammable liquids inside the motor home as a fire or explosion may result.

  • Page 76: Exhaust Gas Fumes

    Section 7: Fuel & Propane System Exhaust Gas Fumes Avoid inhaling exhaust gases as they contain carbon monoxide, which is a potentially toxic gas that is colorless and odorless. If you are in a parked motor home with either the engine running or a generator running there is a potential for exhaust fumes to filter back into the motor home.
  • Page 77 Section 7: Fuel & Propane System at all connections soon after the purchase of your vehicle, and after the initial filling of the propane tanks. Continued periodic checks of the propane system at 5,000 miles of travel (or at least once a year) by a qualified propane service representative as part of your normal maintenance is recommended.
  • Page 78 Section 7: Fuel & Propane System Servicing or Filling Always shut OFF the engine while refueling. Do not smoke and do not operate other ignition sources while refueling. When the propane container is disconnected from the main supply hose and the P.O.L. connection, install the P.O.L. plastic cap that is at- tached to the container.

  • Page 79: Propane Use And Safety

    Section 7: Fuel & Propane System Single stage regulator Some models are equipped with a single stage regulator. Two stage regulator The two-stage regulator has the only moving components in the propane system. Its sole function is to reduce the pressure from the propane containers to a safe and consistent low operating pressure.
  • Page 80 Section 7: Fuel & Propane System Never use an open flame to test for a propane leak. Do not check for leaks using products that contain ammonia or chlorine; these products can cause cracks to form on the metal tubing and brass fittings. Using the Propane System Use the following steps for propane operation: Close ALL burner valves, controls and pilot light valves.
  • Page 81 Section 7: Fuel & Propane System Ensure a supply of fresh air (Canada units only) Cooking / Comfort Heating Label Calculating Propane Gas Usage Most RV gas appliances are operated intermittently, and each has a different BTU rating. You will need to consider this when planning your propane supply and consumption. Unless there is heavy use of hot water, the water heater consumption of propane is minimal.
  • Page 82 Section 7: Fuel & Propane System ™ Notes: Maintenance Record Table of Contents...

  • Page 83: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, water heater, tub/shower. On some models, it may also include the water purification system or outside shower assembly (if so equipped).

  • Page 84: Fresh Water System

    Section 8: Plumbing System The LEDs on the panel indicate the following: C= Charge at 12.7 volts G = Good at 12.1 volts F = Fair at 11.6 volts L = Low at 6.0 volts Tank monitors on the touch screen have a constant readout. There are no buttons to push.
  • Page 85 Section 8: Plumbing System DO NOT drink water deemed microbiologically unsafe or of unknown quality. Avoid traveling with full fresh, black or grey water holding tanks. The weight of holding tank contents in not calculated into the RV cargo car- rying capacity.

  • Page 86: Water Purification System

    Section 8: Plumbing System 12-volt Water Pump There must be sufficient 12-volt DC power to run the water pump when your recreation ve- hicle is not hooked up to city water. Once activated, the water pump (also known as the de- mand pump) will self-prime, and provide water.

  • Page 87: Draining The Fresh Water System

    Section 8: Plumbing System Do not allow water in the canister housing to freeze. Remove the filter before using anti-freeze to winterize the system or chlorine solution to sanitize the system. Flush canister housing thoroughly before it is put back into service after winterizing or sanitizing.
  • Page 88 Section 8: Plumbing System These low-point drains will release water in the supply lines by opening the valves and all faucets. The water heater has its own drain plug. To drain the permanent fresh water holding tank and supply lines: Turn the water heater power OFF (turn off the electric and LP gas switches).
  • Page 89 Section 8: Plumbing System Water Heater Switches The water heater switches are typically located on the monitor panel. Refer to the Monitor Panel section for function details. ™ NOTE: A short hose is supplied with your motor home for use in sanitizing or winterizing the water lines in your RV.
  • Page 90 Section 8: Plumbing System A vertical utility center (Fig C). This utility center contains an outside shower, city water connection inlet, black tank flush inlet, pump switch and water valve controls. Water Valve Control Operation City Fixtures: Use this setting if the motor home can be hooked up to an external pressurized water source (city water).
  • Page 91 Section 8: Plumbing System Remove the city water connection inlet cap and attach one end of the short hose sup- plied with the motor home to the city water connection inlet, and the other end into a container of fresh water. Place the utility center valves in the COUNTRY FILL position (Fig A).
  • Page 92 Section 8: Plumbing System ppm in the water system and should remain in system for at least 4 hours. If a 100 ppm concentration is prepared, use ½ cup of household bleach with one gallon of water. One gallon of the solution should be used for each 15 gallons of tank capacity. Allow to remain in system for at least 1 hour.
  • Page 93 Section 8: Plumbing System 10. Fill the fresh water tank full of clean (potable) water. Fill fresh water tank from an ex- ternal container. Pour fresh water into the inlet using a hose (or funnel). 11. Power to water heater should be OFF (both switches: electric and LP gas). When the fresh water tank is full, turn the pump ON to send water through the lines.
  • Page 94 Section 8: Plumbing System Attach the short hose supplied with your recreation vehicle to the fresh water connec- tion inlet (on the utility center or on the outside of the motor home). Place the other end of the hose in a container holding the sanitized solution. To aid in siphoning, set the container on a surface approximately (2) feet off the ground.
  • Page 95 Section 8: Plumbing System follow the same procedure used to add the sanitizer to the system. Refer to the Lingering Chlorine Taste detail in the previous section for instructions on how to flush the system with the vinegar solution. Winterization If the motor home is going to be stored in a non-temperature controlled envi- ronment with a risk of temperatures reaching 32°F (0°C) or lower, the demand (power) system with RV antifreeze must be used in the motor home plumb-...
  • Page 96 Section 8: Plumbing System Winterizing with Antifreeze Method (NO UTILITY CENTER) Turn water heater power OFF. Turn water heater gas valve (if so equipped) OFF (out- side of the RV). Level the RV and drain the fresh water plumbing system. (See Draining the Fresh Water System).
  • Page 97 Section 8: Plumbing System Move the valves to the “Sanitize/Winterize Lines” position. The low point drains must be closed for the antifreeze to siphon through the lines. Attach the short hose supplied with the motor home to the fresh water connection inlet and insert the other end of the hose into a gallon container of RV antifreeze.

  • Page 98: Water Heater

    Section 8: Plumbing System Water Heater Your RV is equipped with a tank (storage) water heater. Hydrogen gas may result if you have not used the water heater for two weeks or more. HYDROGEN GAS IS EXTREMELY FLAMMA- BLE. To reduce the risk of injury under these conditions, open the hot water faucet for several minutes at the kitchen sink before you use any electrical appliance connected to the hot water system.
  • Page 99 Section 8: Plumbing System If lock-out occurs before the main burner lights, turn the water heater control switch to OFF, wait five seconds and turn the switch to the ON position. This will restart the ignition cycle. The first start-up of the heater may require several ignition cycles before all the air is purged form the propane lines.

  • Page 100: Outside Shower

    Section 8: Plumbing System This “weeping” or dripping will continue until the pressure is reduced to below 150 pounds, and the valve closes. This condition is normal and does not indicate a defective relief valve. One way to reduce the frequency of this occurrence is to maintain an air pocket at the top of the water heater tank.

  • Page 101: Bathroom Tub / Shower

    Section 8: Plumbing System To turn off the water, always close the hot/cold control (faucet) knobs. The lever on the shower head will not completely stop the flow of water; this is intentional to allow for drain- ing. After the water has been allowed to drain from the shower head, return it to the outside shower storage.

  • Page 102: Black/Grey Water System And Tanks

    Section 8: Plumbing System Black/Grey Water System and Tanks Water from the sinks and shower flows into the gray water (or wastewater) holding tank. Water from the toilet will flow into the black water (or sewage) holding tank (see Black/ Grey Water Holding Tanks).
  • Page 103 Section 8: Plumbing System If you are dry camping and cannot immediately empty your holding tanks, reduce your ve- hicle speed until you reach a dumping station. When connected to the sewer drain line at a campground, keep the black tank drain valve closed until the holding tank is at least ¾ full. This will provide sufficient water to assist in complete draining of the black water holding tank.

  • Page 104: Black Tank Flush

    Section 8: Plumbing System You can locate dump stations throughout the United States and Canada in Woodall’s, Rand McNally Camp Guide, Good Sam Camp Guide, KOA Kampgrounds Camp Guide and vari- ous other publications. Some fuel stations also have dump stations.Please contact your RV dealer for assistance in the purchase and installation of a sewer hose or sewer hose extension (if needed).
  • Page 105 Section 8: Plumbing System The black tank drain valve must be OPEN any time there is a hose (water supply) connected to the black tank flush. Do not leave any hose (water supply) connected to the black tank flush when it is not in use. Do not use the same hose to fill your fresh (potable) water tank that is used for the black tank flush.
  • Page 106 Section 8: Plumbing System Tank Heaters Your recreation vehicle may be equipped with heaters for the fresh, gray, black water tanks. These heaters will prevent water in the tanks and lines from freezing down to -11°F (-24°C) (contingent on recreation vehicle setup). The larger tank heaters are 120VAC and attach directly to the tanks.
  • Page 107 Section 8: Plumbing System It is important to prevent solid waste buildup. Follow the toilet manu- facturer’s recommended instructions each time after emptying the black water holding tank. To help prevent toilet blockage, always use RV grade single-ply toilet pa- per.
  • Page 108 Section 8: Plumbing System Maintenance Record Table of Contents...

  • Page 109: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Air Conditioner Cooled air enters the RV through the grill. Make sure you have sufficient power available before operating the air conditioner. Do not operate the air conditioner without the return air filter. Operating the system without the filter allows the lint and dirt that is normally stopped by the filter to accumulate on the cooling coil of the air conditioner.

  • Page 110: Fireplace (If So Equipped)

    Section 9: Heating & Cooling The furnace should be inspected periodically (monthly during the heat- ing season) for presence of soot on the vent. Soot is formed whenever combustion is incomplete. This is a visual warning that the furnace is op- erating in an unsafe manner.

  • Page 111: Section 10: Appliances

    Section 10: Appliances Cooking Safety In Case Of a Grease Fire Do not attempt to use water to put out the fire. Water can spread some types of fire, and electrocution is possible with an electrical fire. Grease is flammable. Never allow grease to collect around top burners or on the cook top surface.
  • Page 112 Section 10: Appliances If a spillover occurs while cooking, immediately clean the spill from the cooking area while it is hot to prevent a tough cleaning chore later. Using extreme care, wipe spill with a clean, dry towel. Kitchen Range and Oven (if so equipped) ™...
  • Page 113 Section 10: Appliances Control panel: sponge or soft cloth and water. Stainless steel (on some models): mild soap and water, then rinse with clean water and dry with soft cloth, or use stainless steel cleaner. Turntable: mild soap and water or dishwasher. Rack(s): mild soap, water and washcloth.

  • Page 114: Range Hood

    Section 10: Appliances Range Hood Whenever the stove in the RV is being used, the range hood MUST be turned on, and the inner flap MUST be unsnapped and free to move. Failure to do so can create an asphyxiation hazard by restricting airflow through this vent.
  • Page 115 Section 10: Appliances The ice maker should be turned off and the ice tray emptied when power to your motor home has been shut off. With no power, the ice will melt and water will “pool” in the refrigerator door. When power is restored, the vibration will cause this water to run out of the door and on to the motor home floor.
  • Page 116 Section 10: Appliances ™ Notes: Maintenance Record Table of Contents...

  • Page 117: Exterior Entertainment Center (If So Equipped)

    Section 11: Electronics Exterior Entertainment Center (if so equipped) The exterior entertainment center is located on the curbside of the unit. You can access the entertainment center by opening the exterior cargo door to the stationary open position. Refer to the individual component manufacturer’s information for detailed operating in- structions.
  • Page 118 Section 11: Electronics ™ Notes: Maintenance Record Table of Contents...

  • Page 119: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 120 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
  • Page 121 Section 12: Interior at the front of the sofa seat bottom out towards you firmly and gently. To convert the hide-a- bed back into the upright sofa position, reverse the process (make sure to pull the seat belts out into their usable positions). Be sure to hold the sofa strap firmly to ensure the hide-a-bed sofa does not suddenly drop shut.

  • Page 122: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Lower the table top down between the seats (B). Place the extra cushion on the table top between the 2 seats. Replace the seat cushions. To convert back to a table: Remove cushions. Lift table top back up to the bracket. Hold the table top at an angle (A).

  • Page 123: Privacy Drape Installation

    Section 12: Interior Use coasters under all glasses, bottles and cans. Do not store toiletry products directly on your countertop surface. Hair products, perfumes, colognes, nail products, creams, lotions and potions have a tendency to spill or leak and go overlooked. Even though the counter top is sealed, a substance that remains on the surface for an extended period may stain the countertop.

  • Page 124: Bed Storage

    Section 12: Interior Bed Storage Additional storage has been provided under the bed. To access the storage area, grasp the ledge at the foot of the bed and lift carefully. The bed platform must be held when raised. It is recommended that two people retrieve stored items from under the bed so that one person may hold the platform, and the other can retrieve the stored items from under the bed.
  • Page 125 Section 12: Interior Bunk Beds and Bunk Ladders (if so equipped) Your recreational vehicle may be equipped with bunk style beds. Bunk bed weight ratings may vary depend- ing on your model and the style of bunk bed. Weight capacities are listed on the bunk capacity label. Do not exceed the bunk weight capacity.
  • Page 126 Section 12: Interior Cab-Over Bunk Bed Your motor home may be equipped with an over-the-cab bunk bed. This bunk bed is ac- cessed through the use of a steel ladder that hooks to the bed platform. Exercise extreme care when entering or exiting the bunk bed and using the ladder Do not allow horseplay on the bed and prohibit jumping on the bed.

  • Page 127: Cleaning The Exterior

    Section 13: Exterior Cleaning The Exterior To protect your recreation vehicle’s exterior finish, wash it often and thoroughly. You may wash and wax your new recreation vehicle 60 days after purchase. The exterior paint needs time to cure before any wax is applied to the exterior surface. Careful maintenance for the first 60 days will assure a long lasting durable finish.
  • Page 128 Section 13: Exterior During cold weather Salt and other chemicals that are spread on winter roads in some geographical areas can have a detrimental effect on the recreation vehicle’s underbody. If your recreation vehicle is exposed to these conditions, spray the underbody with a high-pressure hose every time you wash the exterior of your recreation vehicle.
  • Page 129 Section 13: Exterior Do not allow plastic to come into contact with brake fluid, engine oil, grease, paint thinner, or battery acid. These will damage plastic. Use a soft cloth and a mild detergent solution to wipe away any such contact. Chrome parts To prevent chrome parts from spotting or corroding, wash with water, dry thoroughly, and apply a non-abrasive automotive wax.

  • Page 130: Exterior Ladder

    Section 13: Exterior Window glass The window glass can normally be cleaned with a sponge and water. Use glass cleaner to remove wax, oil, grease, dead insects, etc. After washing the glass, wipe it dry with a clean, soft cloth. Exterior Ladder Your recreation vehicle is equipped with an exterior roof ladder.
  • Page 131 Section 13: Exterior sealants do not have “set” lifetimes. Varying environmental factors affect the pliability and adhesiveness of sealants. You or your dealer must: Inspect all sealants, a minimum of every six months. Make sure to check the roof and all four sides of the recreation vehicle including al moldings, doors, vents and exterior attachments.
  • Page 132 Section 13: Exterior ™ Notes: Maintenance Record Table of Contents...

  • Page 133: Section 14: Travel/Camping/Storage Checklists

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Refer to your Chassis Guide for information on chassis pre-trip inspections and maintenance.

  • Page 134: Motor Home Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite: Check the area under the motor home after overnight parking and look for fuel, water, oil or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks (if so equipped). Empty black and gray holding tank, rinse as needed.
  • Page 135 Section 14: Travel/Camping/Storage Checklists Drain and flush all holding tanks (fresh water, gray water, black water and/or hot water tanks). Adding fuel stabilizer to the generator will aid in preventing condensation and fuel varnishing. Turn OFF the motor home 12-volt battery disconnect switch. Turn OFF the inverter mode at remote.
  • Page 136 Section 14: Travel/Camping/Storage Checklists ™ Notes: Maintenance Record Table of Contents...

  • Page 137: Featured Components Quick Reference Chart

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 138 Section 15: Additional Information Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Shurflo East www.shurflo.com Water Pump, 12V Maintenance Record Table of Contents...

  • Page 139: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Engine: Engine Serial#: Serv i ce P e r f o r m e d Mileage Work Performed Notes Date Maintenance Record Table of Contents...
  • Page 140 Section 15: Additional Information ™ Notes: Maintenance Record Table of Contents...
  • Page 141 Section 15: Additional Information Jayco Ownership Notification Email the form to unitfile@jayco.com ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ Change of Owner □Transfer of Limited Warranty...
