2. Ports used at the remote site (IP Link): Forward port 18810 to the IP address of the IP Link.
Note 1: If you are using more than one IP Link at the same remote site, it is necessary to use a
unique port number for each IP Link. This information is used in Procedure 6, Step •
Note 2: This port is used to configure the IP Link with a web Browser and must not be forwarded.
This restricts its use to the LAN only.
TCP:
1. Ports used at the Corporate Gateway location:

Configuring the IP Link at the Remote Site

The KT-Finder is an application used to configure the IP Link over the local area network (LAN) or the
wide area network (WAN).
The KT-Finder application is on the EntraPass CD-ROM and is also available as a
Important:
free download from
1. Quit all EntraPass applications.
2. Make sure there is a DHCP server on site and the IP Link is in Factory Default (DHCP) mode. See
Table 2 on page 5.
3. Start the KT-Finder.
Note: If you try to run the KT-Finder while running EntraPass, you get an error message similar to
this.
4. Select IP Link from the Device menu.
Table 12:
IP Link Ports
Purpose
Broadcast and KT-Finder
Communication with the Gateway
Web Configuration Page
Table 13: Gateway Ports
Purpose
Firmware upgrade
Communication with IP Link
www.kantech.com
DN1670-2201
IP Link Installation Manual
Port
18803
18810 (Note 1)
80 (Note 2)
Port
18802
18802
. It does not require any installation.
