Site Checklist

Ensure the following:
• The mounting site is ready.
• The site has been approved and all wiring complies with UL requirements and other codes as
appropriate.
• All preliminary site work is completed and the site is clean and free of dust or other contaminants.

Task Lists

Table 8 lists the tasks for the configuration of the IP Link in a LAN
Task
1- Mounting the IP Link
2- Connecting the Earth Ground
3- Connecting the IP Link to the Controller Loops
4- Connecting Power
5- Powering Up the IP Link
6- Defining the EntraPass Site
7- Verifying Communication with the IP Link
Table 9 lists the tasks for the configuration of the IP Link in a WAN
Task
1- Mounting the IP Link
2- Connecting the Earth Ground
3- Connecting the IP Link to the Controller Loops
4- Connecting Power
5- Powering Up the IP Link
6- Defining the EntraPass Site
8- Configuring the IP Link in a WAN/Internet
Table 8: Task list for a LAN configuration
Table 9: Task list for a WAN configuration
