FINAL POWER ADJUSTMENTS
Ensure that the speaker is set to its lowest setting
(this will prevent an excessively loud page when
first used). Conduct test page and increase vol-
ume as necessary with a screwdriver. Turn clock-
wise to increase the volume (see Table 1). Install
the plastic cover.
NOTE: Due to high decibel output, it is not recom-
mended to test paging while working closely with
the horn speaker.
TECHNICAL ASSISTANCE
When calling, have a VOM and a telephone test
set available and call from the job site. Call (540)
427-3900 and ask for PagePac Technical Sup-
port, or call (540) 427-6000 for Valcom 24-hour
Automated Support or visit our websites at
http://www.pagepac.com and www.valcom.com.
Should repairs be necessary, attach a tag to the
unit clearly stating company name, address,
phone number, contact person, and the nature of
the problem. Send the unit to:
Roanoke, VA 24019-5056
Technical Manuals Online! - http://www.tech-man.com Technical Manuals Online! - http://www.tech-man.com
Valcom, Inc.
®
PagePac Repair Dept.
5614 Hollins Road
firealarmresources.com
ATTACHMENT RING
ERMINALS
Table 1: SWITCH SETTINGS
SWITCH
SETTINGS WATTS
1
2
3
4
5
6 DO NOT USE
7 DO NOT USE
2
10-FOOT CHAIN
SPEAKER CABLE
VOLUME LEVEL
CONTROL
(DO NOT FORCE
PAST #7)
FIGURE 1
70V 25V
WATTS
1.80 DO NOT USE
3.70 DO NOT USE
7.50 0.9
15.0 1.80
30.0 3.70
7.5
15.0
947178
