Summary of Contents for ADJ MDF2PSUX117
- Page 1 MDF2PSUX117 Safety Manual...
- Page 2 Products, LLC brands and product names are trademarks or registered trademarks of their respective companies. ADJ Products, LLC and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Limited Warranty (USA Only) Features Safety Guidelines Overview Installation Trouble Shooting Dimensional Drawings Specifications... -
Page 4: Introduction
Do not return this unit to your dealer without first contacting customer support. Introduction: The ADJ MDF2PSUX117 is a power supply unit intended for use with the ADJ MDF2 dance floor panels. To optimize the performance of this product, please read these instructions care- fully to familiarize yourself with the basic operations of this unit. -
Page 5: Limited Warranty (Usa Only)
LIMITED WARRANTY (USA ONLY) A. ADJ Products, LLC hereby warrants, to the original purchaser, ADJ Products, LLC products to be free of manufacturing defects in material and workmanship for a prescribed period from the date of purchase (see specific warranty period on reverse). This warranty shall be valid only if the product is purchased within the United States of America, including possessions and territories. -
Page 6: Features
FEATURES INCLUDED ITEMS Power Cable (x1) IP RATING This device is IP20 rated. This means that the unit is protected against intrusion from solids approximately the size of an adult finger (12mm in diameter), and that the unit is NOT protected against water intrusion of any kind! -
Page 7: Safety Guidelines
THIS FIXTURE IS COMPOSED OF SOPHISTICATED ELECTRONIC COMPONENTS. TO GUARANTEE SMOOTH OPERATION, IT IS IMPORTANT TO FOLLOW ALL INSTRUCTIONS AND GUIDELINES IN THIS MANUAL. ADJ PRODUCTS, LLC IS NOT RESPONSIBLE FOR INJURY AND/OR DAMAGES RESULTING FROM THE MISUSE OF THIS FIXTURE DUE TO THE DISREGARD OF THE INFORMATION PRINTED IN THIS MANUAL. -
Page 8: Overview
OVERVIEW... -
Page 9: Installation
INSTALLATION FLAMMABLE MATERIAL WARNING Keep fixture minimum 5.0 feet (1.5m) away from flammable materials and/or pyrotech- nics. ELECTRICAL CONNECTIONS A qualified electrician should be used for all electrical connections and/or installations. MINIMUM DISTANCE TO OBJECTS/SURFACES IS 6.6 FEET (2 METERS). MINIMUM DISTANCE OF INFLAMMABLE MATERIALS FROM THE SURFACE IS 1.6 FEET (0.5 METER) DO NOT EXPOSE TO RAIN OR MOISTURE! - Page 10 Please see the illustration below, or refer to the user manual for the ADJ MDF2-9SYS for detailed information.
-
Page 11: Trouble Shooting
Below are some common issues that you may encounter during use, along with possible solutions. If the steps below do not solve your problems, please contact the ADJ support line at the phone num- ber or e-mail address listed in the Introduction section of this manual. -
Page 12: Dimensional Drawings
DIMENSIONAL DRAWINGS... -
Page 13: Specifications
SPECIFICATIONS ELECTRICAL Input Voltage: AC 100-240V, 50/60 Hz Output Voltage: DC 24V Maximum Load Power: 2250 W Load Current: 90 A Current Overload Protector Trip Time: • Within 10A of max load: no trip • 10-15A over max load: trip within 1 hour •...
