IHP DUALBURNER24N Installation Instructions

INSTALLATION INSTRUCTIONS FOR PLACEMENT OF ASHTON WHITE BIRCH 24", 30" AND 36" LOG SETS.
GENERAL INFORMATION
THE FIREPLACE MUST BE OFF AND COLD BEFORE
BEGINNING.
READ ALL OF THE STEPS BEFORE STARTING THE
INSTALLATION.
PACKAGING LIST
1 ea. Complete Log Set
1 ea. Installation Instructions
TOOLS/SUPPLIES NEEDED
Safety Glasses
Protective Work Gloves
Heat Resistant Gloves
Installation and service must be performed by a quali-
fied installer, service agency or the gas supplier.
Any safety screen, guard, or barrier removed for ser-
vicing an appliance must be replaced prior to operat-
ing the heater. The fireplace screen or guard designed
for this appliance must be installed prior to operation.
IMPORTANT: Read the owner's manual carefully and
completely before trying to assemble, operate or ser-
vice this fireplace. Improper use of this fireplace can
cause serious injury or death from burns, fire, explo-
sion, electrical shock and carbon monoxide poisoning.
THESE LOG PLACEMENT INSTRUCTIONS ARE A SUP-
PLEMENT TO THE LOG BURNER INSTRUCTIONS. LOG
BURNER INSTRUCTIONS MUST BE READ AND FOL-
LOWED TO THEIR ENTIRETY TO ASSURE SAFE AND
PROPER INSTALLATION AND OPERATION. THE LOG
BURNER INSTRUCTIONS ARE INCLUDED SEPARATELY
INSIDE THE CARTONED LOG BURNER ASSEMBLY.
INSTALLER:
Leave instructions with the appliance.
CONSUMER:
Retain instructions for future reference.
PFS
®
US
Log sets shall not be used with any other manufactur-
ers log burners.
INSTALLATION OF LOGS ON ANY OTHER BURNER IS
STRICKLY PROHIBITED.
If your gas log burner is not listed above, please
refer to your owners manual or contact IHP Tech Sup-
port/Customer Service for further assistance.
This is a complete Log Set and shall not be used oth-
erwise. This log set shall not be used for replacement
of single logs.
It is very important to install these logs exactly as
instructed. DO NOT MODIFY LOGS.
Failure to position the parts in accordance with these
instructions or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
CAUTION: Burn hazard! Logs will remain hot after
use. If you need to reposition any log to maintain the
proper layout, use heat resistant gloves or allow logs
adequate time to cool before handling.
1. Remove the entire Log Set provided and check for
damage. If damaged, STOP!!! Contact dealer or IHP.
2. If you currently have a log set installed: Remove
the entire Log Set that is currently installed on your
Gas Log Burner and discard entire set.
3. Follow the steps found beginning on the next page
for installation of your new complete Log Set.
NOTE: DIAGRAMS & ILLUSTRATIONS NOT TO SCALE.
KITS AND ACCESSORIES
P/N 901164-00
LOG SET INSTALLATION
Rev. NC 06/2021
DUALBURNER24N
24" log sets
shall only DUALBURNEROD24N
DUALBURNER24NE
be used with
DUALBURNER24PE
burners
30" log sets DUALBURNER30N
shall only
DUALBURNEROD30N
be used with DUALBURNER30NE
burners DUALBURNER30PE
DUALBURNER36N
36" log sets
DUALBURNEROD36N
shall only
DUALBURNER36NE
be used with
DUALBURNER36PE
burners
