Levelflex FMP53 HART
 15 Engineering unit: mm (in)
To remove the cable from the terminal again:
1. Using a flat-blade screwdriver ≤ 3 mm, press down on the slot between the two terminal
holes
2. Simultaneously pull the cable end out of the terminal.
6.2.4 Closing the cover of the connection compartment
1. Screw down the cover of the connection compartment.
2. Turn the securing clamp 90 ° in the clockwise direction and, using an Allen key (3 mm),
tighten the screw of the securing clamp on the connection compartment cover with
2.5 Nm.
7

Operation options

The device can be operated as follows:
• Operation via operating menu (display)
• DeviceCare and Fieldcare, see Operating Instructions
• SmartBlue (app), Bluetooth (optional), see Operating Instructions
Endress+Hauser
3 mm
2,5 Nm
2.
1. 2.
≤ 3 (0.12)
Operation options
1.
A0013661
A0021491
