ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
XUS015L-CS02-1
2
XUS015L-CS04-1
3
17C33A0706001Y4
4
17C02A0755131Y4
5
17FA05040301-Y4
Attention:
Make sure that each bolt needed for all steps match the
corresponding figure to ensure proper assembly.

Step 1:

Place one of leg (#2) onto a non-abrasive surface, such
as a carpet, with its holes facing upwards. Fasten the
seat assembly (#1) to the leg (#2) by using bolts (#3
and #4) and washers (#5). Keep the bolts loose.
See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
XUS015L
PART
Q'TY
SEAT ASSEMBLY
LEG
BOLT M6*16
BOLT M6*14
WASHER d6.5*D13*1.0
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP DON'T RETURN TO STORE!
PAGE 1 OF 2
-WM
PART
MATERIAL CODE
NO.
1
6
18000337004
2
7
18000337006
4
8
17KAA0101----Y4
4
9
17KAA0201----Y4
10
4
61X015LC00001BA
FIGURE 1
6
3
5
#3 BOLT M6*16
PART
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
HEX.KEY WRENCH 6MM
CUSHION
4
7
16
#4 BOLT M6*14
COURTYARD CREATIONS INC.
Q'TY
4
4
1
1
1
1
2
14
