ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
XLS005W-CS01
2
XLS005W-CS02
3
XLS005W-CS03
4
XLS005W-CS04
5
47LA66145
6
47LA66144
7
47LA66143
You will need the following tools:
- Phillips Screwdriver (Not Included)
- Hex.Key Wrench (See Part #15)
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.

Step 1:

Place the right support frame (#1) onto a non-abrasive surface,
sush as a carpet. Insert the right leg (#3) to the right support
frame (#1) by using screw (#10). Repeat the same procedure
for the left support frame (#2) and the left leg (#4).
See Figure 1.
Note:
The label that are marked "1, 2, 3, 4" on the support frames
and the legs should coincide with Figure 1 & 2 to ensure proper
assembly.
Weight limit for each shelf is 35kg or 89lbs.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
!
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
XLS005W
PART
Q'TY
1
RIGHT SUPPORT FRAME
1
LEFT SUPPORT FRAME
1
RIGHT LEG
1
LEFT LEG
1
MESH FRAME A
1
MESH FRAME B
1
MESH FRAME C
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 3
