Courtyard Creations TCS28SG Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
TCS26SH-CS05-1
2
TCS28SG-CS04-1
3
62TCS26SHY101
4
13C??1B29008001
5
17C33A0706001Y4
Note:
The tiles are easy to be broken, be careful when you
remove them. Do not throw the residual tiles away,
retain them for future use.
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table top
(#1) rim by using bolts (#5) and washers (#7). Keep the
bolts loose. See Figure 1.
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely
!
assembled.
Do not sit or stand on this table.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
TCS28SG
PART Q'TY
1
TABLE TOP
4
LEG
1
CENTER
CONNECTOR
4
TILE
4
BOLT M6*16
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP DON'T RETURN TO STORE!
PAGE 1 OF 2
PART
MATERIAL CODE
NO.
6
17C01A0706001Y4
7
17FA05040301-Y4
8
18000337004
9
18000337001
10
17KAA0101----Y4
FIGURE 1
2
2
1
16
COURTYARD CREATIONS INC.
PART
BOLT M6*16
WASHER d6.5*D13*1.0
BOLT CAP
BOLT CAP M6
HEX.KEY WRENCH 4MM
2
2
8
5
7
#5 BOLT M6*16
Q'TY
8
12
4
8
1
