ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. When contacting the service center.
!
INTENDED FOR RESIDENTIAL USE ONLY.
RUS4239
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP
DON'T RETURN TO STORE!
PAGE 1 OF 7
COURTYARD CREATIONS INC.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Courtyard Creations RUS4239
Summary of Contents for Courtyard Creations RUS4239
- Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. When contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 STOP DON’T RETURN TO STORE! PAGE 1 OF 7 COURTYARD CREATIONS INC.
-
Page 2: Parts List
C. Lay out all parts on a flat surface and identify them using the table below. PARTS LIST PART 17C01A0716072Y4 MATERIAL CODE PART Q'TY BOLT M6*45 RUS4239-CS09-8 17FA09070701-Y4 TOP CROSS BEAM WASHER d10.5*D21*2.0 W/ADJUSTABLE TEETH 17FA05050401-Y4 RUS4239-CS04-5 WASHER d6.5*D16*1.2 FRONT UPRIGHT SUPPORT... - Page 3 ASSEMBLY (Note: For all nuts and bolts fastening, always use a washer (#21, #22 or #23) between the tube and bolt or the tube and nut.) Step 2 Step 1 Step 1: Fasten the front and rear upright supports (#2 and #3) at the top by using bolts (#15), washers (#21), and steel nuts (#26).
- Page 4 Step 6: Insert the U-shaped side canopy braces (#6) into the canopy frame connectors (#28) and secure with screws (#14). Please make sure that the teeth of the canopy frame connectors are facing towards the inside. Step 1 Step 2 See Fig.
- Page 5 Step 11: Insert the seat arms (#8 and #9) into the seat Step 1 supports (#10 and #11) and fasten them together by using plastic joint covers (#30), bolts (#18), washers (#22), and plastic nuts (#27). See Fig. D – Step 1. Note: 1.
- Page 6 Step 16: Hang the opposite ends of the suspension springs (#24) into the holes located on the angled braces of the top cross beam w/adjustable teeth (#1). See Fig. E. Warning: Make sure that both ends of the suspension springs (#24) go completely through the holes in the angled braces on the top cross beam w/adjustable teeth (#1) and the swing arm tubes (#13).
-
Page 7: Cleaning And Maintenance
Warranty • This product is covered by Courtyard Creations Inc. One–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from over service center.
