ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
XTM011Z-CS04-4
2
XTM011Z-CS04-3
3
62XTM011ZQ101
4
XTM011Z-CS11-1
Attention:
Make sure that each bolt needed for all steps matches
the corresponding figure to ensure proper assembly.

Step 1:

Place the right leg (#1) onto a non-abrasive surface,
such as a carpet,
with the brackets facing
Insert the
braces (#3) into legs (#1 and #2). Fasten
them
together
by using bolts (#5).
See Figure 1.
Note:
1.
The labels marked "L" and "R" on legs (#1 and #2)
should coincide with Figure 1 to ensure proper
assembly.
2. The holes in the braces (#3) must be facing towards
the inside.
Use the correct bolts as indicated. Do not tighten any of the bolts until the ottoman is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
XTM011Z
PART
Q'TY
RIGHT LEG
LEFT LEG
BRACE
SEAT ASSEMBLY
upwards.
Keep the bolts loose.
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP DO NOT RETURN TO STORE!
PAGE 1 OF 2
PART
MATERIAL CODE
NO.
1
5
17C40A0705001YX
1
6
17C40A0712001YX
2
7
17KAA0101----Y4
1
8
17KAC3101----Y3
FIGURE 1
3
PART
BOLT M6*15
BOLT M6*35
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 10MM
2
L
3
1
R
15
#5 BOLT M6*15
COURTYARD CREATIONS INC.
Q'TY
4
4
1
1
5
