Courtyard Creations XTM015W Assembly Instructions

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
XTM015W-CS04-B
2
XTM015W-CS04-C
3
XTM015W-CS02-1

Step 1:

Place the left leg (#1) onto a non-abrasive
surface, such as a carpet. Fasten legs (#1 and #2)
to the seat assembly (#3) by using bolts (#4).
Make sure that all of the bolts have been tightened
completely. See Figure 1.
Note:
The labels marked "L" and "R" on legs (#1 and #2)
should coincide with Figure 1 to ensure proper
assembly.
Use the correct bolts as indicated. Do not tighten any of the bolts until the ottoman is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
!
required.
! Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
XTM015W
PART Q'TY
LEFT LEG
RIGHT LEG
SEAT ASSEMBLY
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP DO NOT RETURN TO STORE!
PAGE 1 OF 2
4
17C40A0705001YX
1 5
17KAA0101----Y4
1 6
17KAC3101----Y3
1 7
61X015WC00001BA
FIGURE 1
4
BOLT M6*15
HEX. KEY WRENCH 4MM
HEX. KEY WRENCH 10MM
CUSHION
R
2
3
4
L
1
COURTYARD CREATIONS INC.
8
1
1
1
