  • Page 1 VL-EX150MU-1 18Gbps HDBaseT Extender with USB 2.0 150m VER 1.0...

  • Page 2: Table Of Contents

    Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shocks, lightning strikes, etc.

  • Page 3: Introduction

    1. Introduction This 18Gbps HDBaseT Extender can extend HDMI signal, bi-directional IR control signal, and USB KVM signal to a distance up to 150m via a single CAT6 cable. This product converts HDMI signal to standard HDBaseT signal and transmits it through a LAN cable. It can easily control the signal source device or display device from the remote end through a bi-directional IR signal pass-through function.

  • Page 4: Package Contents

    3. Package Contents ① 1 x 18Gbps HDBaseT Extender (Transmitter) ② 1 x 18Gbps HDBaseT Extender (Receiver) ③ 1 x IR Blaster cable (1.5 meters) ④ 1 x IR Wideband Receiver cable (1.5 meters) ⑤ 4 x Mounting Ears ⑥ 8 x Machine Screws (KM3*4) ⑦...
  • Page 5 Connection Input: 1×HDMI IN [Type A, 19-pin female] 1×IR IN [3.5mm Stereo Mini-jack] 1×SERVICE [Micro- Transmitter USB jack] 1×USB [USB-B, 4-pin female] Output: 1×HDBT OUT [RJ45] 1×IR OUT [3.5mm Stereo Mini jack] Input: 1×HDBT IN [RJ45 with light] 1×IR IN [3.5mm Stereo Mini jack] 1×SERVICE [Micro-USB jack] Receiver Output: 1×HDMI OUT [Type A, 19-pin...

  • Page 6: Operation Controls And Functions

    5. Operation Controls and Functions 5.1 Transmitter Panel Name Function Description PWR LED The red LED is on when the Transmitter is powered on. Used for audio EDID setting (dial to COPY by default). EDID DIP COPY: Copy the EDID of the HDMI OUT port of the switch Receiver.

  • Page 7: Receiver Panel

    Name Function Description Connect to IR receiver cable, the IR receive signal will emit IR IN to the IR OUT port of the Receiver. Connect to IR blaster cable, the IR emit signal is from the IR 10 IR OUT IN port of the Receiver.

  • Page 8: Ir Pin Definition

    Name Function Description ▪ Illuminate: HDMI signal with HDCP. Data Signal ▪ Flash: HDMI signal without HDCP. Indicator ▪ Dark: No HDMI signal. (Yellow) HDMI signal output port, connecting to HDMI display device HDMI OUT such as TV or monitor. Connect to the IR receiver cable.

  • Page 9: Application Example

    6. Application Example The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries. 7 / 7...
