Ikan MOTUS22 Manual

MOTUS22
3-Section Carbon Fiber Tripod Kit Payload 48.5 lbs. (E-Image)
Special Features
• Payload range: 48.5lbs / 22kg
• 1-4 grades of drag for tilt and pan
• Counterbalance adjustment: Continuous Variable Counterbalance
• Tilt range: -67° to +90°
• Bowl Size: 100mm
• Quick-release Plate Sliding Range: 4.7" / 120mm
• Dual-sided pan/tilt arm rosette mounts (two arms included)
• Flip Lock Lever
• 2-Stage/3-Section
• Tripod Height Range: 21.9 - 59.6" / 55.5 - 151cm
• Tripod Transport Length: 29.3" / 74.5cm
• Material: Carbon Fiber Tubes/Metal Body
• Net Weight: 13.9lbs / 6.3kg
Overview
Designed with both broadcast professionals and filmmakers in mind, the
MOTUS22 tripod kit is an ideal choice for anybody looking for solid payload
support. Included in the kit is the MH22 fluid head, featuring a continuous variable
counterbalance that gives operators unparalleled adjustment capabilities on the
fly for payloads up to an impressive 48.5lbs. With 1 - 4 grades of independent
fluid drag adjustments (and separate locking knobs) for both pan and tilt, allowing
the operator to easily adjust the head to suit their shooting style, the MH22 is an
incredibly responsive option for professionals that are looking for optimal control
and reliability. Longer and wider than its competitors, the MH22's double-locking
plate ensures that the camera is securely mounted to the sticks quickly and
efficiently, snapping into place from the top of the head. This quick release system
is a fantastic perk for larger rigs that struggle to move into place with a rear slider.
The ECT100M 3-Section Carbon Fiber Tripod supports payloads of up to 220.5lbs,
is made of lightweight carbon fiber, and has a bowl size of 100mm. This 3-Section
tripod has designated flip lock levers for each stage, which can be raised to
a maximum height of 59.6" and lowered to a minimum height of 21.9". No matter
the setting, the ECT100M provides exceptional stability with its extendable mid-
level spreader. Quick-release legs allow for even more flexibility to securely adapt
to the terrain and then lock the sticks into place, while removable rubber covers for
the spiked feet help to protect more delicate work surfaces.
Quick Release Plate / Dual Locking System
When you're in the field, events move fast. The last thing you need is a battle
royale between your camera and its mount. Designed to conveniently snap
equipment onto the plate system from the top of the head, but then just as easily
release the camera with the push of a button, the MH22 is ideal for those with
heavy payloads.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
What's Included
1 x MH22 Fluid Head
1 x ECT100M Carbon Fiber Tripod
1 x GP4 Quick Release Plate
1 x Bowl Locking Knob
2 x GB4 Pan Handle
Payload
Large broadcast camera? Complex
cinematography rig? Not a problem.
Secured with its 100mm bowl, the MH22
boasts payload capabilities of up to 48.5lbs,
providing sturdy support for your next
award-winning shot.
Continuous Variable Counterbalance
MH22's step-less system offers continuous
variable counterbalance support from the
maximum payload all the way down to zero, preventing a camera from tilting
forward or backward on its own. From here, MH22 really jumps beyond its
competition. A hand-crank and visualized date display allows operators to
fine-tune exact counterbalance settings, maintaining that perfect angle for an
exceptional shot.
1 x Hard Case
1 x EI-7000L Mid-Level Spreader
1 x Tripod Bag
3 x Rubber Feet
