- Page 1 BATTERY HAMMER DRILL...
-
Page 2: Security Instructions
Security instructions Caution Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire, and/or serious injury. Due to our ongoing R&D&I Note: Save all warnings and instructions for future reference. program, the specifications in this document are subject to change without notice. - Page 3 4) Use and care of battery tools Recharge the battery only with the charger specified by the manufacturer. An unsuitable charger can create a fire hazard. Use power tools only with specifically designated batteries. Use of other batteries may create a risk of injury or fire. When the batteries are not in use, keep it away from other metal objects, such as paper clips, coins, keys, nails, screws, or other small metal objects, that can make a connection from one terminal to another.
-
Page 4: Additional Security Warnings
Additional security warnings Hammer Safety Warnings Wear ear protectors. Exposure to noise can cause hearing loss. • Use auxiliary handles, if supplied with the tool. Loss of control can cause personal • injury. Hold power tool by insulated gripping surfaces when performing an operation •... -
Page 5: Technical Data
Technical data Data sheet Voltage Drilling capacity in concrete (optimal depth) 16mm (80mm) Steel drilling capacity 13mm Wood drilling capacity 42mm Product description 1. locking sleeve 5. Mango 2. mode selector switch 6. Battery (not included) 3. Variable speed controlled trigger 7. - Page 6 Set up Attention Disconnect the battery pack from the tool or place the switch in the locked or off position before making any mounting, adjustments, or changing accessories. These preventative safety measures reduce the risk of the tool being started accidentally. Mounting Installation of accessories (Fig.
- Page 7 Caveat Do not change the direction of rotation until the tool comes to a complete stop. Shifting during chuck rotation can damage the tool. Forward/reverse lever and trigger lock Mode selection switch: drill/hammer (2) The dial/selector switch allows the tool to be configured for various drilling/hammer drilling applications.
- Page 8 Work tips Following a few simple tips will reduce tool wear and the possibility of operator injury. The high efficiency available from rotary hammers can only be obtained if sharp • and well-maintained accessories are used. All hammers require a short period of time to warm up. Depending on the ambient •...
-
Page 9: Maintenance
With the locking sleeve removed, pull on the new cap until it is seated firmly on the collet and the locking sleeve can slide forward again. Should the machine fail despite the care taken in manufacturing and testing, contact your official Total dealer. Environment •... -
Page 10: Exploded View
Exploded view... - Page 11 BATTERY HAMMER DRILL...
