- Page 1 ROTARY HAMMER DRILL...
-
Page 2: Security Instructions
Security instructions Caution Read all safety warnings and all instructions. Failure to follow all warnings and instructions can result in electric shock, fire, and / or serious injury. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 3 4) Use and care of power tools a. Do not force the tool. Use the right power tool for each use. b. Do not use the power tool if its ignition switch does not work. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
-
Page 4: Additional Safety Warnings
Additional safety warnings • Wear ear protectors. Exposure to noise can cause hearing loss. • Use auxiliary handles, if supplied with the tool. Loss of control of the tool can cause personal injury. Hold the power tool by the insulated gripping surfaces when performing an •... -
Page 5: Technical Data
Technical data Grinder datasheet Voltage 220-240V ~ Frequency 50 / 60Hz Power 800W Maximum revolutions 0-1200 / min Impact frequency 0-5300 / min Concrete drilling capacity 26mm Steel drilling capacity 13mm Wood drilling capacity 30mm Product description 1. Chuck 7. Release button for mode selector 2. - Page 6 Set up Mounting Before doing any work on the machine itself, unplug the power cord. Changing the position of the auxiliary handle The auxiliary handle can be positioned in any position for a safe, comfortable and fatigue- free working posture. •...
- Page 7 Press the button for adjusting the depth stop (9) and insert the depth stop into • the auxiliary handle. The marked surface of the depth stop (10) must face downward. Insert the bit all the way into the chuck (1). Otherwise, the mobility of the bit may •...
-
Page 8: Maintenance And Service
Reversal of the direction of rotation The direction of rotation switch (4) is used to reverse the direction of rotation of the machine; however, this is not possible if the on / off switch (6) is actuated. Turn the drilling / hammer drilling selector (4) on both Right rotation sides up to the stop in position Turn the drilling / hammer drilling selector (4) on both... -
Page 9: Exploded View
For safe and proper operation, always keep the machine and the ventilation slots • clean. A damaged dust cap must be replaced immediately. We recommend that this be • carried out by an after-sales service. Clean the tool holder (1) each time you use it. •... - Page 10 ROTARY HAMMER DRILL...
