PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE.
ATTENTION:
1.
Please read these instructions carefully before assembly
2.
Aluminium is soft metal and over tightening may strip thread or break the part
3.
Please allow 45 minutes for assembly.
4.
Assembly will require 2 people
Care for the canopy:
• Simply clean the umbrella canopy with a soft brush and mild detergent.
• Do not machine wash or machine dry.
• Do not iron.
• Air-dry the canopy thoroughly in an open position before storing for extended periods of time.
IMPORTANT! Always close/put down the parasol when not in use. Do not use or assemble the parasol in heavy winds, rain, thunderstorms or if it's
snowing. In these weather conditions, we recommend to fold down or disassemble the parasol. Disassemble by following the setup steps in this
manual.
IMPORTANT! The parasol must be secured in place using a parasol base. Make sure the ground is level and firm.
IMPORTANT! If the crank gets too hard to turn, check if the rope has come off the pulley. If you continue to turn the crank, the rope or crank
handle could break.
IMPORTANT! Placing the parasol over or near a swimming pool can cause premature fading of the canopy.
WARNING:
To prevent damage to parasol, facing the canopy against the wind.
Do not assemble the parasol on sandy, muddy or loose soil.
Keep children and pets away while setting up the parasol.
Children must be supervised around the parasol.
This parasol is for outdoor use only.
Do not light any fires under or near the parasol!
This parasol is primarily intended to be used as a sunshade and not as wind protection.
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
Component's
Parts List
Parts Picture
A
B
C
D
E
F
For replacement or lost spare parts please go to
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product.
Q'
Component
Description
ty
no.
13402164A
Cross Base A
1
13402164B
Cross Base B
1
2100021
Bolts
4
2100022
Washers
4
2100023
Wrench
1
2100024
Crank Handle
2
http://faq.hartmanuk.co.uk/spares/
Component's
Parts List
Parts Picture
G
H
I
J
K
Missing
L
Q'
Component
Description
ty
no.
Parasol
13402164C
Frame with
1
Canopy
2100025
Solar Panel
1
13402164D
Cover
1
Blow
2100027
Molded
1
Base 1
Blow
2100028
Molded
1
Base 2
2100026
Cap
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Hartman DOVE 13402164
Summary of Contents for Hartman DOVE 13402164
- Page 1 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. ATTENTION: Please read these instructions carefully before assembly Aluminium is soft metal and over tightening may strip thread or break the part Please allow 45 minutes for assembly. Assembly will require 2 people Care for the canopy: •...
- Page 2 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. ASSEMBLY INSTRUCTIONS CARIBBEAN ROUND PARASOL (3.5M ROUND) (13402164 – DOVE) Step 1 Place Cross Base(A) on a soft surface, line up notches and place Cross Base(B) over Cross Base(A). Step 2 Find the plug at the top of the parasol.
- Page 3 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. CAUTION: YOU MUST CHARGE BATTERY BEFORE FIRST USE. Please note that battery can discharge if they are left unused or uncharged for a long period of time. Since there can be a six-month period between production and final customer purchase, we recommend you charge your solar parasol for at least 8 hours in direct sunlight before the first use.
- Page 4 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Step 4 Place Blow Molded Base (J & K) on the Cross Base assembly and fill with sand and water, cover with caps (L). Step 5 Unfasten the storage straps around the canopy. For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/ Should you have any queries about your furniture your first point of contact should be the retailer from whom...
- Page 5 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Step 6 Insert the Crank Handle (F). To open the parasol, squeeze the Glide Handle and Lever clamp together and slide up or down the pole to achieve the desired tilting angle. Release the Lever clamp to lock into place. To open the canopy, turn the crank handle clockwise until the canopy is fully open.
- Page 6 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Step 7 To rotate parasol, insert the Crank Handle (F) into pole and turn to desired position. The multiple position canopy can rotate 360° around the axis of the main pole to offer the shade on your expected area around the parasol.
- Page 7 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Step 8 Tilt the parasol to the desired angle. Step 9 To close the parasol, turn the Crank Handle counter clockwise until the canopy is fully closed. Squeeze the Glide Handle and Lever clamp together, then slide down the pole and release the grip to lock into place.
- Page 8 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Step 10 Fasten the storage straps around the canopy. Step 11 Use Cover (I) when your parasol is not in use. For replacement or lost spare parts please go to http://faq.hartmanuk.co.uk/spares/ Should you have any queries about your furniture your first point of contact should be the retailer from whom you purchased your product.
- Page 9 PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE. Battery Replacement Step 1 Twist counterclockwise and remove the solar panel from the top of the parasol. Step 2 Pull the plug out of the socket under the solar panel. Pull by holding the plug, not by pulling on the wires.
