Diagnostics
6. Adjust R81 potentiometer and verify the linearity accordingly. See Figure 4-11.
Specifications
7. Reassemble unit and verify the following static pressure points to ensure proper
Specifications
Static Calibration Setup
FIGURE 4-11 Static Calibration screen
4 - 10
150 mmHg +/- .1%
calibration.
30 mmHg,100 mmHg, 150 mmHg, 190 mmHg and
250 mmHg. +/-3 mmHg
Digital Mercury Manometer
150 mmHg
T - Fitting
Bulb
Valve
Bulb
Manually
Squeeze
Bulb
0070-10-0556-02
NIBP Test
Previous Menu
Overpressure Voltage Setpoint
Static Pressure Calibration
Static Pressure Calibration
Motor Pump Test Transducer: 150.0 mmHg
Leak Test
Dump Test
Bleed Rate Test
Overpressure Test
Abort Test
Select to return to previous menu.
NIBP Module
VR 81
693cc
Test Chamber
P/N 0138-00-0001-01
Spectrum
Calibration Procedure
Adjust
VR 81
Here
NIBP Front
Detail View
® ™
