S e r v i ce M a n u a l
0070-01-0556-02_revC_srvc color.indd 1
3/15/10 10:57:25 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spectrum and is the answer not in the manual?

Questions and answers

Related Manuals for Mindray Spectrum

Summary of Contents for Mindray Spectrum

  • Page 1 S e r v i ce M a n u a l 0070-01-0556-02_revC_srvc color.indd 1 3/15/10 10:57:25 AM...
  • Page 2 S e r v i ce M a n u a l...
  • Page 3 Microstream is a U.S. registered trademark of Oridion Medical Ltd. © Copyright Mindray DS USA, Inc., 2008. All rights reserved.Contents of this publication may not be reproduced in any form without permission of Mindray DS USA, Inc. ® ™ 0070-10-0556-02...

  • Page 4: Table Of Contents

    Trends Troubleshooting..........................1 - 36 Printer/Recorder Troubleshooting ......................1 - 36 Monitor/Display Troubleshooting ......................1 - 37 Installation Menu ............................1 - 38 Installation Mode.............................1 - 38 Transferring Monitor Default Settings......................1 - 40 Option Installation ...........................1 - 41 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02...
  • Page 5 Sensors.........................5 - 2 ® Cleaning and Re-use of a Nellcor Sensor....................5 - 3 Cleaning CO Sensors, Adapters and Sampling Components ................5 - 3 Sterilization and Cleaning of Reusable Cuffs ......................5 - 3 ® ™ 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 6 Warranty Statements ............................5 - 9 USA, Canada, Mexico, and Puerto Rico.....................5 - 9 International (excluding North America) .....................5 - 10 Phone Numbers and How To Get Help......................5 - 11 Manufacturer’s Responsibility ...........................5 - 11 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02...
  • Page 7 Table of Contents This page intentionally left blank. ® ™ 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 8: Foreword

    Foreword Introduction Foreword ® ™ The Spectrum /Spectrum OR Service Manual is intended as a guide for technically qualified personnel during repair and calibration procedures. This publication may have been updated to reflect product design changes and/or manual improvements. Note Unauthorized servicing may void the remainder of the warranty.
  • Page 9 Introduction Warning This page intentionally left blank. ® ™ 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 10: Repair Information

    2. The instrument covers must not be removed by other than qualified technical personnel who have received supplementary instructions regarding maintenance of medical equipment or has equivalent experience in this area. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 1...

  • Page 11: Troubleshooting Guidelines

    • Digital Mercury Manometer - 0 to 300 mmHg • Safety Analyzer • Patient Simulator • Test Chamber / Dummy Cuff (P/N 0138-00-0001-01 (700 cc) or -03 (500 cc) • BISx Sensor Simulator (P/N 0454-00-0060) ® ™ 1 - 2 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 12: Disassembly Instructions

    14. Remove the four screws that secure the Display assembly to the front housing brackets. 15. Slide the Display to the bottom of the front housing and lift the right side past the bracket to remove the display. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 3...
  • Page 13 4. Unfasten the NIBP fitting on the side of the back housing with a 3/8 inch nut driver. 5. Slide the NIBP module from the rear of the unit carefully and remove. ® ™ 1 - 4 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 14 3. Remove the recorder assembly as stated in “Removal of the Recorder Assembly” on page 1-5. 4. Remove the Cable assembly from J3. 5. Remove the two screws and pull the board from the unit. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 5...
  • Page 15 Removal of the 608 MHz Radio Assembly 1. Remove the 2 screws from the radio assembly base. 2. Pull the assembly back from the monitor and place to the side. ® ™ 1 - 6 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 16: Nurse Call Cable (3 Pin Circular To Unterminated)

    1 in +/- .13 in. 9 ft +/- 6 in. Cable shield Common Cable shield Connector Circuit Board shield FIGURE 1-1 Nurse Call Cable (3 Pin Circular to Unterminated) ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 7...

  • Page 17: Vga Extension Cables

    Length +/- 6" Length +/- 6" FIGURE 1-2 VGA Extension Cables DESCRIPTION PART NUMBER LENGTH (FT.) Terminated 0012-00-0852-01 Open Ended Unterminated 0012-00-0852-02 Open Ended Unterminated 0012-00-0852-03 Open Ended Unterminated 0012-00-0852-04 ® ™ 1 - 8 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 18: Serial Port To Gas Module Ii/Se/Se With Spirometry Cable (P/N 0012-00-1276-Xx)

    -02 72" 9 pin mini D serial to 25 pin D shell 1.00 +/-.13 SEE DETAIL DETAIL N.C. N.C. 24-25 N.C. N.C. 8-21 N.C. N.C. FIGURE 1-3 Serial Port to Gas Module II/SE/SE with Spirometry Cable (P/N 0012-00-1276-XX) ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 9...

  • Page 19: Serial Port To Serial Port Cable (P/N 0012-00-1275-01)

    (P/N 0012-00-1275-01) Female Female 10 ft +/-1 in. Cable Shield Connector Shield Connector Shield N.C. N.C. N.C. N.C. N.C. N.C. FIGURE 1-4 Serial Port to Serial Port Cable (P/N 0012-00-1275-01) ® ™ 1 - 10 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 20: Pin Molex To Mini Phone Plug (Dpd Sync Cable)

    RING SYNC FIGURE 1-5 26 pin Molex to Mini Phone Plug (DPD Sync Cable) PART NUMBER LENGTH 0012-00-1301-01 8 in. +/- 1 in. 0012-00-1301-02 10 ft. +/- 6 in. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 11...

  • Page 21: Ecg Shielded Lead Wires

    24" pinch 3 lead set International 40" pinch 3 lead set International 3/40", 2/60" pinch 5 lead set Domestic 3/40", 2/60" pinch 5 lead set International FIGURE 1-6 ECG Shielded Lead Wires ® ™ 1 - 12 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 22 ARE TO BE THE SAME COLOR AS LEAD WIRE BLACK TWO PINS SHORTED YELLOW YELLOW BLACK YELLOW YELLOW GREEN GREEN GREEN GREEN TWO PINS SHORTED WHITE WHITE FIGURE 1-7 ECG Shielded Lead Wires ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 13...

  • Page 23: Panorama Mobility Lead Wires

    24", snap, 5 lead set, Domestic 24", snap, 3 lead set, Domestic 24", snap, 5 lead set, International 24", snap, 3 lead set, International FIGURE 1-8 Panorama Mobility Lead Wires ® ™ 1 - 14 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 24: Ecg Cable Esis And Non Esis

    Right Arm (RA) White Right Arm (R) Left Leg (LL) Left Leg (F) Green Left Arm (LA) Black Left Arm (L) Yellow Right Leg (RL) Green Right Leg (N) Black ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 15...

  • Page 25: Panorama Mobility Cable (Esis And Non Esis)

    Right Arm (RA) White Right Arm (R) Left Leg (LL) Left Leg (F) Green Left Arm (LA) Black Left Arm (L) Yellow Right Leg (RL) Green Right Leg (N) Black ® ™ 1 - 16 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 26: View 12 ™ Card Assembly

    Cover Label ™ View 12 PCMCIA Card 0996-00-0065-01 1.18 12 Lead Wire Set ® P/N 0012-00-1411-02 (Domestic) and P/N 0012-00-1411-03 (IEC), Spectrum Only ™ (Not Included with View 12 Card Assembly) AAMI/ANSI (Domestic) IEC (International) FIGURE 1-12 12 Lead Wire Set ®...

  • Page 27: Cardiac Output Cable

    Cardiac Output Cable Repair Information 1.19 Cardiac Output Cable FIGURE 1-13 Cardiac Output Cable (P/N 0012-00-1447-01) ® ™ 1 - 18 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 28: Iabp Cable

    AOUT2 (PRESS) 2 GNDA 3 AIN 4 N.C. GND 5 N.C. P3, PRESS N.C. DOUT 6 RING Shield drain wire Connector shell FIGURE 1-15 IABP Cable (ECG/IBP) (P/N 0012-00-1650-01) ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 19...

  • Page 29: Serial Port To Rj 45 Cable (Visa)

    Serial Port to RJ 45 Cable (VISA) Repair Information 1.21 Serial Port to RJ 45 Cable (VISA) ® P/N 0012-00-1299-01, Spectrum only Connector shield Cable shield N.C. N.C. N.C. N.C. N.C. FIGURE 1-16 Serial Port to RJ 45 Cable (VISA) ®...

  • Page 30: Bisx Module

    BISx Interface Cable P/N 0012-00-1665-01 Patient Interface Cable (PIC) P/N 0012-00-1666-01 FIGURE 1-17 BISx Module (Front View) 1.23 BISx Sensors ™ (P/N 0020-00-0491-01, -02 and -03), Spectrum OR only FIGURE 1-18 BISx Sensors ® ™ Spectrum /Spectrum OR Service Manual...

  • Page 31: Beep Tones

    Beep Tones Repair Information 1.24 Beep Tones ® The following tables describe the beep tones associated with the Spectrum ™ Spectrum OR monitors: ® ™ POWER ON (SPECTRUM AND SPECTRUM OR Normal Operation 1 beep Runtime Stack Failure 2 beeps...

  • Page 32: Troubleshooting Menus

    This could be the patient’s Verify with a 12-lead electro- normal QRS complex. cardiogram. Electrode could be positioned Move ECG patches closer over a bone or muscle mass. towards each other. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 23...

  • Page 33: Nibp Troubleshooting

    A measurement has been Retry will be attempted. attempted but no reading was Check that appropriate possible. This results from patient size is set. inadequate cuff inflation. Preset initial inflation pressure. ® ™ 1 - 24 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 34 Reading too high or too low Incorrect cuff size Measure Patient limb, use correct cuff. Patient movement Wait until patient is calm or gently hold limb. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 25...

  • Page 35: Spo 2 Troubleshooting

    Check cable and sensor Low amplitude SpO sensor on same limb as Check sensor placement, move signal cuff. as necessary. Patient has poor perfusion. Switch limb / Notify physician. ® ™ 1 - 26 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 36: Temperature Troubleshooting

    Wait for the auto-zero to an auto-zero complete. : Auto-zero Requested An Auto-zero was Wait for the auto-zero to automatically requested by the complete. system. : Failure system failure. Contact Technical Support. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 27...

  • Page 37: Gas Module Troubleshooting

    Replace sampling line if necessary. Disconnect and reconnect the FilterLine from the Spectrum in order to clear this message. : Purge The system has detected a Check FilterLine and replace if ®...
  • Page 38 Gas Module has been on for a long Turn off Gas Module.Turn on period of time without the Spectrum Gas Module and Spectrum Monitor being on. Monitor. GM: Replace Trap Indicates residue build-up on the Replace water trap reservoir.
  • Page 39 Appears when the Gas Module Contact Customer Support. detects an unrecoverable error in its own operation GM: Disconnected Appears when the Spectrum cannot Ensure Gas Module is turned detect signals being sent by the Gas on and interface cable is Module properly connected.
  • Page 40 Customer Support. Calibration Error, Zeroing Appears when the Gas Module Repeat calibration Error cannot perform a Zeroing during procedure. If problem calibration persists, contact Customer Support. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 31...

  • Page 41: Ibp Troubleshooting

    Flush catheter, notify physician vessel PA catheter in Catheter in too far Notify physician immediately Spontaneous Wedge “Overwedging” or Balloon overinflated Deflate balloon, reinflate slowly, dampened PAWP notify physician ® ™ 1 - 32 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 42: Epm Cardiac Output Troubleshooting

    (>27ºC) or the fluid is not under warm lights, difference between the injectate and the near a warming blanket or blood temperature is <8ºC. over-chilled in the ice bath. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 33...

  • Page 43: Vigilance Cardiac Output Troubleshooting

    This message is displayed when an Refer to the Edwards Vigilance alert or alarm status has been sent Monitor Operator’s Manual or from the Vigilance to the Spectrum. contact Edwards Lifesciences Corporation for assistance. Within the USA: (800)-424-3278 Outside the USA: (949)-250-2500 1.25.11...

  • Page 44: Alarm Troubleshooting

    MUTE silence Check Patient No Alarm printout with Print on Alarm is set to Off Go to Print Menu and set Print Alarm violation on Alarm to On ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 35...

  • Page 45: Trends Troubleshooting

    Press PRINT TREND when trend window is open No Trends displayed Use scroll feature to scroll to the top of the trend then press PRINT TREND No paper Check / Replace paper ® ™ 1 - 36 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 46: Monitor/Display Troubleshooting

    Done when finished. Incorrect Date or Time Data not entered or entered Follow instructions from “How incorrectly. to Set the Clock / Date and Time”. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 37...

  • Page 47: Installation Menu

    The following items are set through the Installation Mode menu: Language, Country, Date Format, Time Format, NIBP Timeout, CO & PAWP Timeout, Enable EPM, Apnea Latch (Spectrum OR only), Enable Mute All Permanent Selection (Spectrum OR only), Enable Arrhythmia All Off Selection (Spectrum OR only), Temperature Units, Weight Units, Height...
  • Page 48 PCM2 Copy monitor defaults Select to copy the from card. monitor defaults and settings from a data transfer card inserted into PCM2 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 39...

  • Page 49: Transferring Monitor Default Settings

    4. Enter Installation Mode on the receiving monitor by pressing and holding the ® ™ DISCHARGE key (Spectrum ) or the TRENDS key (Spectrum OR ) while powering ON the monitor. 5. Select Copy monitor defaults to card. A status message will report completion of the transfer.

  • Page 50: Option Installation

    1. Install option PCMCIA card (P/N 0996-00-0053-XXXXX) into slot PCM2. ™ 2. Select “Install” from the menu selection. Press the Navigator knob to activate new option. 3. Verify proper operation as stated in chapter 4.0. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 41...

  • Page 51: System Information Menu

    Select to set up Contact Phone Select to set up Phone Accutor Baud Rate 9600, 1200 Select to change the Accutorr (Spectrum only) protocol baud rate DIAP Baud Rate 9600, 19200 Select to change the DIAP baud rate Enable Network...
  • Page 52 MENU TITLE ON MENU SCREEN CHOICES DEFAULT TEXT STRINGS Wireless Subnet Mask ID Select to set up Wireless Subnet (Spectrum only) Mask ID Laser Printer IP Address (Spectrum only) Network Name: Select to set up Network name Device ID ®...

  • Page 53: Trend Storage

    ® to 120 trend values for each parameter, and for Spectrum only, up to 6 minutes of OXY- CRG data. With the addition of the Extended Trend card (P/N 0996-00-0052-01), the ®...
  • Page 54 Contact customer service. Complete: This is displayed for a module when download is complete. NOTE: If a fault condition occurs, an error message will be recorded in the error log. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 1 - 45...
  • Page 55 Software Download Repair Information This page intentionally left blank. ® ™ 1 - 46 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 56: Block Diagrams

    The Block Diagrams indicate the internal organization of the instrument. The block diagrams are used to gain both familiarity with the instrument and to locate malfunctioning PC boards as readily as possible. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 2 - 1...

  • Page 57: Block Diagram

    SW11 Print SW14 SW17 View SW19 Mute Event Stop Trend SW21 SW20 SW12 SW15 ® FIGURE 2-1 Spectrum Block Diagram DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER Recorder Assembly 0683-00-0465-01 NIBP Board 0670-00-0798-01 Recorder Board 0670-00-0695 Patient Connector Board 0670-00-0682-01 0012-00-1622-01...
  • Page 58 SW14 SW17 View SW19 Mute Event Stop Trend SW12 SW15 SW21 SW20 BISX Sensors ™ FIGURE 2-2 Spectrum OR Block Diagram DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER Recorder Assembly 0683-00-0465-01 NIBP Board 0670-00-0746-01 Recorder Board 0670-00-0695 NIBP Board 0670-00-0798-01 0012-00-1622-01...
  • Page 59 Block Diagram Block Diagrams Spectrum CPU Board External Module See Previous Page Interface Board Keypad Patient Connector Board Keypad Overlay Temp External Module Main Board IBP 3 (P/N 0670-00-0734-01) IBP 4 External Device FIGURE 2-3 Block Diagram (External Parameter Module Main Board)

  • Page 60: Isometric Drawings And Part List

    Isometric Drawings and Part List Introduction This chapter provides information necessary to identify the replacement parts and assemblies of instruments. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 1...

  • Page 61: Top Level Assembly

    Top Level Assembly FIGURE 3-1 Top Level Assembly...
  • Page 62 Isometric Drawings and Part List Top Level Assembly ITEM DESCRIPTION PART NUMBER ® Label, Rear Information, Spectrum 0334-00-2623 ™ Label, Rear Information, Spectrum OR 0334-00-1724 Label, Right Side 0334-00-1528 Cover Assembly, Docking Connector 0198-00-0037 PCMCIA Card Dummy 0380-00-0372 ™ Bracket, View 12...
  • Page 63 Nellcor Oximax , Dutch 0334-00-1501-153 ® ® Label, Patient Connector w/CO no IBP Nellcor Oximax , Dutch 0334-00-1501-155 Label, Patient Connector w/CO2, w/IBP, Nell MP506, 0334-00-1501-181 Br. Portuguese ® ™ 3 - 4 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 64 Isometric Drawings and Part List Top Level Assembly ITEM DESCRIPTION PART NUMBER Label, Patient Connector w/CO2, w/o IBP, Nell MP506, 0334-00-1501-185 Br. Portuguese Rotary Knob 0366-00-0101 Label, Recorder Paper Loading 0334-00-1431 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 5...

  • Page 65: Front Housing Assembly

    Front Housing Assembly FIGURE 3-2 Front Housing Assembly...
  • Page 66 LCD TFT DISPLAY 12.1" Dress keypad Gnd Tail As Shown with Conductive Side Facing PBC and so as not to Interfere with Mounting Screws FIGURE 3-3 Front Housing Assembly...
  • Page 67 Front Housing Assembly Isometric Drawings and Part List ITEM NO DESCRIPTION PART NUMBER Front Housing 0380-00-0387-01 ® ™ Front Housing (Spectrum /Spectrum OR 0380-00-0387-02 Cable Assembly Speaker 0012-00-0257-06 Holder Speaker 0380-00-0352 Encoder Optical 32 Position Push button 0311-00-0132 Main Keypad 0331-00-0120-01 Display TFT Color LCD 12.1...

  • Page 68: Rear Housing Assembly

    Rear Housing Assembly FIGURE 3-4 Rear Housing Assembly...
  • Page 69 DETAIL B DETAIL A FIGURE 3-5 Rear Housing Assembly (Sealed Lead Acid battery configuration)
  • Page 70 ATTACH CONNECTOR PART OF ITEM 10 TO J3 OF ATTACH CONNECTOR PART ITEM 7 0F ITEM 7 TO J8 OF ITEM 12 (SEE S H E E T (0212-12-0603) ORIENT FAN LABEL 2 PLACES 2 PLACES S I D E DOWN WITH CABLE EXIT AS S H O W N...
  • Page 71 FIGURE 3-7 Rear Housing Assembly (For use with Spectrum P/N 0998-00-1000-XXXXX only)
  • Page 72 FIGURE 3-8 Rear Housing Assembly FIGURE 3-9 Rear Housing Assembly (For use with Spectrum P/N 0998-00-1000-XXXXX only) (For use with Spectrum P/N 0998-00-1000-XXXXX and Spectrum OR P/N 0998-00-1500-XXXXX)
  • Page 73 (Nellcor SpO Oximax) FIGURE 3-10 Rear Housing Assembly (For use with Spectrum P/N 0998-00-1000-XXXXX and Spectrum OR P/N 0998-00-1500-XXXXX)
  • Page 74 FIGURE 3-11 Rear Housing Assembly...
  • Page 75 FIGURE 3-12 Rear Housing Assembly (Sealed Lead Acid battery configuration)
  • Page 76 FIGURE 3-13 Rear Housing Assembly (Lithium-Ion battery configuration)
  • Page 77 WITHOUT RECORDER FIGURE 3-14 Rear Housing Assembly...
  • Page 78 (0212-12-0405) Note: Bracket is only required on units with Masimo SPo2 Note: Standoffs are only required on units with Nellcor SPo2. Use item # 60 screw to secure. FIGURE 3-15 Rear Housing Assembly (Sealed Lead Acid battery configuration)
  • Page 79 FIGURE 3-16 Rear Housing Assembly (Sealed Lead Acid battery configuration)
  • Page 80 (0212-12-0405) Note: Bracket is only required on units with Masimo SPo2 Note: Standoffs are only required on units with Nellcor SPo2. Use item # 60 screw to secure. FIGURE 3-17 Rear Housing Assembly (Lithium-Ion battery configuration)
  • Page 81 FIGURE 3-18 Rear Housing Assembly (Lithium-Ion battery configuration)
  • Page 82 0012-00-1233 Cable Assembly, Nellcor SpO 0012-00-1356 Cable Assembly, Nellcor SpO OxiMax 0012-00-1634 ® Board Assembly Masimo MS-3 0671-00-0055 Cable, Masimo SpO to Main Board 0012-00-1201 Spacer Nylon Richco 0361-45-0403 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 23...
  • Page 83 0670-00-0682-02 PC Board Assembly Patient Connector HP 0670-00-0680-01 Cable Panel to Main Board 0012-00-1206-01 Screw, Pan Head Cross Recessed #4.40 x 5/16 0212-12-0405 Pneumatic Fitting Male Panel Mount 0103-00-0489 ® ™ 3 - 24 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 84 Washer Shoulder .140 OD, -115 ID 0221-00-1026 Screw Pan Head 0212-12-0418 Cable Tie 0125-01-0001 Standoff Plastic 0361-30-0375 Cable, Interface to Main CPU Board for 0012-00-1596 0998-00-1000-XXXX Standoff 0361-30-0250 Clip, Plastic 0343-05-0001 ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 25...

  • Page 85: External Parameter Module

    External Parameter Module (0212-12-0605) 5 PLACES (0212-12-0420) 2 PLACES 2 PLACES 2 PLACES 2 PLACES 2 PLACES FIGURE 3-19 External Parameter Module...
  • Page 86 Label, Patient Connector (T2, CO) 0334-00-2582-023 Spanish, Italian Label, Patient Connector (T2, IBP3, IBP4, CO) 0334-00-2582-026 Dutch Label, Patient Connector (T2, IBP3, IBP4) 0334-00-2582-027 Dutch Label, Keypad Filler 0334-00-2624 Label, Part Number/Serial Number ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 27...

  • Page 87: Comm-Port

    Comm-Port FIGURE 3-20 Comm-Port...
  • Page 88 FIGURE 3-21 Comm-Port...
  • Page 89 0380-00-0347-04 Label, "RD1, NC1, SP1", Comm-Port 0334-00-1573 PCB Assembly, Comm-Port, SP1/NC1/SP2 0670-00-1140 Label, "SP1, NC1, SP2", Comm-Port 0334-00-2521 Label, "CS1, MB1, SP1", Comm-Port 0334-00-1541 PCB Assembly, Comm-Port, CS1/MB1/SP1 0670-00-0684-01 ® ™ 3 - 30 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 90 FIGURE 3-22 Base Station...
  • Page 91 FIGURE 3-23 Base Station Assembly...
  • Page 92 Bumper (Feet Base Station) 0348-03-0001 Standoff Hex Male/Female With Lock Washer 0361-00-0164 Label Part Number Serial Number Power Supply Assembly 0014-00-0070 Dashpot Assembly 0103-00-0465 MB1 Connector Shroud 0334-00-1668 N.A. Not Available ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 3 - 33...
  • Page 93 Comm-Port Isometric Drawings and Part List This page intentionally left blank. ® ™ 3 - 34 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 94: Calibration Procedure

    Calibration Procedure Introduction ® The following procedures are provided to verify the proper operation of the Spectrum ™ Spectrum OR Monitor. Service Diagnostics provide the capability of diagnosing ® ™ problems within the Spectrum /Spectrum OR hardware. A menu driven interface ®...

  • Page 95: Test Equipment And Special Tools Required

    P/N 0138-00-0001-01 (700 cc) or -03 (500 cc) Dummy Cuff • DVM • Patient Simulator • Digital Flow Meter • Safety Analyzer Dempsy Model or equivalent • BISx BIS Sensor Simulator P/N 0454-00-0060 ® ™ 4 - 2 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 96: Diagnostics

    Diagnostics Diagnostics To enter the diagnostic mode: 1. Turn the power OFF. ® 2. Pressing and hold the FREEZE key (Spectrum ) or the SPIROMETRY key ™ (Spectrum OR ) while powering ON the monitor. The Diagnostics Main Menu will appear on screen. Release the FREEZE key or the SPIROMETRY key.

  • Page 97: Keypad / Control Knob Test

    Press keys and the text will appear on screen. Rotate the control knob to move the cursor. Press and hold the Normal Screen Key to exit. FIGURE 4-3 Keypad / Control Knob Test ® ™ 4 - 4 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 98: Recorder Test

    Select the Chart Grid ASCII Characters menu. FIGURE 4-4 Recorder Test Menu The printer will print the Recorder Test pattern as shown in the figure below. FIGURE 4-5 Recorder Test Strip ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 5...

  • Page 99: Display Tests

    Pressing the Navigator knob a third time will activate the Display Test Menu screen. FIGURE 4-7 Pixel Test Menu ® ™ 4 - 6 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 100: Color Test

    The color test will verify the four basic colors of the display. Press the Navigator knob to view the selected color screens in full illumination. The colors are Red, Blue, Green and White. Blue White Green FIGURE 4-8 Color Test ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 7...

  • Page 101: Nibp Tests

    No manual adjustment is required. The voltage set point is controlled by software. If Check Calibration/Cuff Overpresssure appears in message area of the screen, replace the NIBP module accordingly. Specifications: .030 to .170 volts ® ™ 4 - 8 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 102 4. Locate R81 on the NIBP Module. Turn unit on and enter the Diagnostic Mode as stated in section 4.4. Reenter the diagnostics menu and select the Static Pressure Calibration Menu. 5. Manually inflate the chamber to 150mmHg. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 9...
  • Page 103 Select to return to previous menu. NIBP Module VR 81 Bulb Valve Bulb Adjust Manually 693cc VR 81 Squeeze Test Chamber Here Bulb P/N 0138-00-0001-01 NIBP Front Detail View FIGURE 4-11 Static Calibration screen ® ™ 4 - 10 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 104 300 mmHg will also be displayed on screen. Specifications Pump to 300 mmHg in < 35.0 seconds. – 500 cc test chamber Specifications: Pump to 300 mmHg in < 49.0 seconds – 700 cc test chamber ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 11...
  • Page 105 250, 150 and 50 mmHg. – 500 cc test chamber Specifications: Leak rate should not exceed 10mmHg / 10 seconds for the target values of 250, 150 and 50 mmHg. – 500 cc test chamber ® ™ 4 - 12 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 106 Dump Rate – 260 to 15mmHg / 14sec or less – Adult – 700cc test chamber Dump Rate – 150 to 5mmHg / 7sec or less - Neonate – 700cc test chamber ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 13...
  • Page 107 10 seconds. The result of the test will be displayed on the screen. Specifications: Bleed Rate = 6.0mmHg / sec ± 20% - 500cc test chamber Specifications: Bleed Rate = 6.0mmHg / sec ± 20% - 700cc test chamber ® ™ 4 - 14 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...
  • Page 108 Pediatric < or = 220 mmHg Neonate < or = 165 mmHg NOTE: For Spectrum only, due to safety conditions, the unit must be reset after each Overpressure Test (with software G.10 or lower.) 3. Press the print key to send the test result to the local printer.

  • Page 109: Error Log

    3. Use the Navigator Knob to move the cursor within the list of errors. 4. To clear all data from the error log, use the Navigator knob to select Clear. ® ™ 4 - 16 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 110: Microstream ® Co 2 Calibration

    1. Connect the tubing that comes with the calibration gas to the gas canister and to the ® FilterLine . Use calibration gas, (P/N 0075-00-0033-01) and a Microstream FilterLine. ® Attach the gas / tubing assembly to the CO input port on the Spectrum /Spectrum ™ ™ 2. Select the CO Parameter Tile using the Navigator Knob.
  • Page 111 Knob to select Previous Menu. 10. Use the Navigator Knob to select Normal Screen and return to the monitor’s normal display screen. ® ™ 11. When the Spectrum /Spectrum OR has detected valid breaths, data will display for the CO , Inspired CO and Respiratory Rate.

  • Page 112: Verification

    ECG 2 - V2 m. ECG 3 - V3 n. ECG 4 - V4 o. ECG 5 - V5 p. ECG 6 - V6 NOTE: 12 Lead applies to Spectrum only. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02...
  • Page 113 9. BISx Verification (optional) a. Expand view - no b. EEG setup menu - -25uV to +25uV c. Sensor Check • Pass or Fail • High impedance • Noise • Lead off ® ™ 4 - 20 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 114: Ecg Tests

    120 / 80 125 / 82 36.7 Mean (93) Mean (94) Interval : Off ET: 13 min Message Area B Expanded View with Pacer Enhancement On FIGURE 4-20 Pacer Setup Menu ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 4 - 21...

  • Page 115: Ibp 1, Ibp 2, Ibp 3 And Ibp 4 (Optional) Verification

    1. Set the Simulator to 37° C. Connect to the monitor using a 400 series probe. 2. Verify the temperature is 37° ± 2°C. 700 Series Probe 1. Repeat same test for 700 series probe. ® ™ 4 - 22 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 116: Verification

    1. Access the Installation Menu by pressing and holding the DISCHARGE key ® ™ (Spectrum ) or the TRENDS key (Spectrum OR ) while powering ON the monitor. 2. Select Enable EPM and change to Yes. 3. Select the weight units to kgs.

  • Page 117: Bisx Verification

    4. Select the CO Setup menu. Select the Injectate Temp sensor to Inline. Optional - Set the Patient Size (72.0 in) and Weight (200 lbs) accordingly. ® 5. Connect the Cardiac Output cable P/N 0012-00-1447-01 (P3) to the Spectrum ™ Spectrum OR 6.

  • Page 118: Leakage Current Tests

    4. On the safety analyzer depress the Apply 115 VAC button and note the reading. 5. Repeat the test for normal and open ground polarity combinations. Specifications: Verify the current readings of the test are below 50µA under a single fault condition. (Including 12 Lead for Spectrum only) ® ™ Spectrum /Spectrum OR...
  • Page 119 Verification Calibration Procedure This page intentionally left blank. ® ™ 4 - 26 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 120: Preventative Maintenance

    Preventative Maintenance Preventative Maintenance Schedule ® The following is a list of activities required for periodic maintenance of the Spectrum ™ Spectrum OR monitor. The physical inspection, replacement of consumable items and performance checks should be performed at the recommended intervals stated below.

  • Page 121: User Preventative Maintenance Introduction

    User Preventative Maintenance Introduction This section of the manual outlines routine user maintenance guidelines. ® ™ The Spectrum /Spectrum OR Monitor is designed for stable operation over long periods of time. Under normal circumstances the monitor should not require technical maintenance beyond that described in this section.

  • Page 122: Sensor

    Prolonged use of disinfectant may cause discoloration of the cuff. Replace the bladder after cleaning and disinfecting the cuff, as follows: 1. Place the bladder on the top of the cuff, as the figure shows. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 5 - 3...

  • Page 123: Reusable Bladderless Cuffs

    Antimicrobial Definition Bladderless cuffs are treated with an antimicrobial coating. Antimicrobial technology effectively controls a broad spectrum of bacteria, fungi, algae and yeasts on a wide variety of treated substrates. 5.7.3 Disposable Blood Pressure Cuffs Disposable cuffs are intended for single patient use only.

  • Page 124: Care And Cleaning Of 3 And 5-Lead Ecg Cables And Leadwires

    2% Glutaraldehyde solution (i.e., Cidex) is recommended. After cleaning, the ECG cables and leadwires should be wiped with water using a clean damp cloth then dried with a clean dry cloth. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 5 - 5...

  • Page 125: Care And Cleaning Of View

    ® ™ CAUTION: Recharge batteries in the Spectrum /Spectrum OR ® ™ CAUTION: Remove the batteries if the Spectrum /Spectrum OR is not likely to be used for an extended period of time. ® ™ 5 - 6 0070-10-0556-02 Spectrum...

  • Page 126: Recorder Paper Replacement

    Do not store the recordings in plastic bags, acetate sheet protectors, or similar items made from petroleum products. These products emit a small amount of vapor which will, over a period of time, deteriorate the image on the chart paper. ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 5 - 7...
  • Page 127 We recommend that if long term archives are required, make a photocopy of the recordings as back-up. Under normal office filing conditions, the recordings should retain acceptable image quality for about five years. ® ™ 5 - 8 0070-10-0556-02 Spectrum /Spectrum OR Service Manual...

  • Page 128: Warranty Statements

    Mindray DS USA, Inc.’s option at the factory or at an authorized Distributor, any product which shall under normal use and service appear to the Company to have been defective in material or workmanship.

  • Page 129: International (Excluding North America)

    Mindray DS USA, Inc.’s option at the factory or at an authorized Distributor, any product which shall under normal use and service appear to the Company to have been defective in material or workmanship.

  • Page 130: Phone Numbers And How To Get Help

    ® ™ Spectrum /Spectrum OR Service Manual 0070-10-0556-02 5 - 11...
  • Page 131 0070-10-0556-02 Revision M August 13, 2010...
  • Page 132 Tel: +31 33 25 44 911 • Fax: +31 33 25 37 621 Mindray (UK) Limited • 3 Percy Road • St. John’s Park • Huntingdon • Cambridgeshire PE29 6SZ • United Kingdom • Tel: 01480 416840 • Fax: 01480 436588 Mindray Medical France SARL •...

This manual is also suitable for:

Spectrum or

Table of Contents

Save PDF
