G12/G12x USER MANUAL
INDEX
(CLICK TO NAVIGATE TO PAGE)
PAGE
1
SLIDE KIT INSTALLATION
2
SLIDE MOUNT RACK EXTENDER KIT INSTALLATION
3
SLIDE MOUNT NOTATION REGARDING U HEIGHT
4
INSTRUMENT BRACKET INSTALLATION
5
CABLE TRAY INSTALLATION
6
KEYBOARD TRAY KIT INSTALLATION
8
TABLETOP RECEIVER MOUNTING
9
REAR COVER INSTALLATION
10
RACK MOUNT RECEIVER INSTALLATION
11
RACK MOUNT EXTENDER BLOCK KIT INSTALLATION
12
HANDLE REMOVAL AND REPOSITIONING
13
G12 ITA ENCLOSURE ASSEMBLY
14
G12X ITA ENCLOSURE ASSEMBLY
15
KEYING PIN KIT INSTALLATION
16
ITA & RECEIVER ENGAGEMENT
17
RECEIVER INSTALL/ UNINSTALL CAUTIONARY NOTE
18
TROUBLESHOOTING
19
PRECAUTIONARY NOTES
03/28/2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VPC G12
Summary of Contents for VPC G12
- Page 1 RECEIVER INSTALL/ UNINSTALL CAUTIONARY NOTE TROUBLESHOOTING PRECAUTIONARY NOTES Please note that any printed or downloaded User Manual may not reflect the most current revisions. The information contained herein is subject to change. For the most current information available, visit vpc.com. 03/28/2022...
- Page 2 FRONT OF RACK Figure A. If dimension C exceeds 1" use the Rack Extender Kit, Part # 310 113 INSTALLATION 406 for G12 or Part # 310 113 519 for G12x. Install slides using manufacturer’s instructions. A hard copy is included with the slide kit.
- Page 3 Do not fully tighten until the cover plate is attached. Attach the cover to the brackets with the flat head screws. With the extender kit in place, secure the G12 receiver to the mating surface on the extender brackets with #10-32 cap screws (provided with the G12).
- Page 4 U height on both sides of the receiver. For the above receivers, Dimensions A in the drawings below is .46” or 11.7 mm. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
- Page 5 NOTE: The middle section will not go into the outer section until the inner section has been fully installed into the middle section. Retighten the slide mounting screws. MAKE SURE ALL SCREW HEADS HAVE BEEN SECURELY TIGHTENED. ONLY USE #8-32 BUTTON HEAD SCREWS. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
- Page 6 Attach the cable tray to the slides with #8-32 screws ( Figure A). The angled side of the cable tray should face the G12/G12x receiver, and with shorter slide kits the cable tray will sit below the lip of the instrument brackets.
- Page 7 KEYBOARD TRAY KIT INSTALLATION PART # 310 113 439 NOTE: This optional keyboard mounts below the platform on the G12 or G12x receiver. The kit includes a keyboard with touchpad, 58" USB cable with connector, keyboard tray, and 12" slides. Dimensions shown: [millimeters]...
- Page 8 ). The remaining 4 #8-32 button head screws are used to attach the keyboard tray to the slides. The different hole patterns allow for variations in the overall extension of the keyboard tray. Figure C. Figure D. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
-
Page 9: Permanent Mounting
449.58 17.70 419.10 16.50 292.10 11.50 85.60 85.60 3.37 3.37 16.51 16.51 85.60 16.51 3.37 Figure A. Receiver with 15" Platform Figure B. Receiver with 20" Platform Dimensions shown: [millimeters] inches RETURN TO INDEX For more information visit vpc.com. 03/28/2022... -
Page 10: Rear Cover Installation
Rear covers can be permanently mounted to the tabletop using the dimensions provided in Figure B. Hardware for this is not included. Rubber feet included with rear cover are not necessary when permanently mounting the G12/G12x receiver. Dimensions shown: [millimeters] inches 287.19... - Page 11 Allen Wrench INSTALLATION This rack mount version of the 15” G12 includes a base shelf which can support up to 275 lbs. total in combination with the mounted G12 receiver. Place receiver over clip/cage nuts on rack, making sure they are aligned (Figure A).
- Page 12 3.5“[88.9mm] [101.6] screws. 4.00 With the extender kit in place, secure the G12 receiver to the mating surface on the extender brackets with #10-32 cap screws (provided with the G12). Figure A. Rack Extender Kits are used when the rails are recessed more than 1".
- Page 13 PART # 310 104 325, 310 104 334, 310 104 408, 310 104 409, 310 104 356, 310 104 359, 310 104 385, 310 104 386, 310 104 410, 310 104 411 NOTE: The G12/G12x receiver handle requires approximately 90° of counter- clockwise travel for engagement and 90° of clockwise travel for disengagement of the ITA.
- Page 14 ON THE RECEIVER. THERE IS NO LIMIT TO THE HEIGHT 84.84 OF THE ENCLOSURE. 3.34 Figure A. Enclosures must be flush with the ITA bottom to ensure the proper function of the G12 system. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
- Page 15 ON THE RECEIVER. THERE IS NO LIMIT TO THE HEIGHT OF THE ENCLOSURE. 136.40 5.37 Figure A. Enclosures must be flush with the ITA bottom to ensure the proper function of the G12x system. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
- Page 16 PIN B PIN D SCREW B SCREW D OPEN INSTALLED INSTALLED OPEN OPEN INSTALLED INSTALLED OPEN DETAIL B SCALE 1 : 1.5 DETAIL A SCALE 1 : 1.5 Figure A. Figure B. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
- Page 17 - All ITA modules must match their respective receiver modules. It is crucial for all modules to be installed properly. *G12x Only: The lower four module rows share the same description as on G12 (i.e. A1-A4). The extended tier of the G12x is considered to be rows 5 or 6.
- Page 18 Figure A. BEFORE INSTALLING RECEIVER TO RACK When installing or removing the G12/G12x Receiver to a rack, be sure the handle is not in the disengaged/vertical position (Figure A). Tension springs are located inside the mounting holes used to mount the receiver to the rack. While the handle is in the disengaged/ vertical position, these springs are present in the mounting holes and can be damaged by the introduction of mounting screws.
-
Page 19: Troubleshooting
Excessive force is needed to engage the handle • With a typical contact load, approximately 35lbs force is needed to engage the handle. Consult with VPC for detailed contact loading information. • If excessive force is required, this may indicate that the ITA is out of alignment or that a module is not mating with its intended module. -
Page 20: Precautionary Notes
It is advisable that power to the interface system be disconnected prior to handling and maintenance. • Caution should always be used when engaging, making sure that all foreign objects are removed from the system. RETURN TO INDEX For more information visit vpc.com. 03/28/2022...
