G2, G6 & G10 USER MANUAL
INDEX
(CLICK TO NAVIGATE TO PAGE)
PAGE
1
REMOVING ITA BACKSHELL
2
MICROSWITCH INSTALLATION
3
ENGAGING ITA WITH RECEIVER
4
KEYING PIN KIT USAGE
5
CABLE BUNDLE WIRE INFORMATION
6
VERTICAL HINGED MOUNTING FRAMES
7
G2 RECEIVER MOUNTING SPECIFICATIONS
8
G6 RECEIVER MOUNTING SPECIFICATIONS
9
G10 RECEIVER MOUNTING SPECIFICATIONS
10
G10 RECEIVER PANEL CUT OUT SPECIFICATIONS
11
SLIDE MOUNT NOTATION REGARDING U HEIGHT
12
PRECAUTIONARY NOTES/ TROUBLESHOOTING
Please note that any printed or downloaded User Manual may not reflect the most current revisions.
The information contained herein is subject to change.
For the most current information available, visit vpc.com.
03/23/2022
Advertisement
Related Manuals for VPC G2
Summary of Contents for VPC G2
- Page 1 SLIDE MOUNT NOTATION REGARDING U HEIGHT PRECAUTIONARY NOTES/ TROUBLESHOOTING Please note that any printed or downloaded User Manual may not reflect the most current revisions. The information contained herein is subject to change. For the most current information available, visit vpc.com. 03/23/2022...
- Page 2 The G2, G6, and G10 ITAs are equipped with removable EMI-shielded backshells. The backshells slide up to provide access to wires and connectors. To slide the backshell up, be sure to first remove the screw(s) located at the base of the ITA. The G2 and G10 have two screws at the base, and the G6 has one. Once the backshell is put back into place, be sure to secure the screw(s) back in place, as the EMI shielding provided by the backshell will not take effect otherwise.
- Page 3 MICROSWITCH INSTALLATION PART # 310 113 180 This microswitch is compatible with the G2, G6 and G10 receivers. A microswitch will alert users as to the presence of an engaged ITA in the system. DISCONNECT ALL ELECTRICAL SUPPLIES TO THE SYSTEM PRIOR TO INSTALLATION OF MICROSWITCH.
- Page 4 If there is any resistance when engaging, double-check module alignment and check for debris. If still experiencing difficulty engaging, contact VPC and speak to a VPC Engineer for assistance. Proceeding or using force may cause damage to the system that voids any warranty.
- Page 5 SCREW D PIN B PIN D SCREW B SCREW D PIN B OPEN INSTALLED INSTALLED OPEN OPEN INSTALLED INSTALLED OPEN Additional details can be found by accessing the drawing for this part number online at vpc.com. RETURN TO INDEX 03/23/2022...
- Page 6 The table below shows a sampling of the maximum number of wires that will fit in: the single cable exit on the G2; each of the two oblong cable exits on the G6; or three oblong cable exits on the G10. For example, each exit will hold a maximum of 683 signal (20 AWG) wires OR 202 coax (RG316) wires.
- Page 7 G2, G6 & G10 USER MANUAL G2, G6 & G10 VERTICAL HINGED MOUNTING FRAME PART # 310 113 391, 310 113 341, 310 113 342 G2 • PART # 310 113 391 G10 • PART # 310 113 342 G6 • PART # 310 113 341...
- Page 8 G2, G6 & G10 USER MANUAL RECEIVER MOUNTING SPECIFICATIONS G2 PART # 310 120 110 RETURN TO INDEX 03/23/2022...
- Page 9 G2, G6 & G10 USER MANUAL RECEIVER MOUNTING SPECIFICATIONS G6 PART # 310 104 318 RETURN TO INDEX 03/23/2022...
- Page 10 G2, G6 & G10 USER MANUAL RECEIVER MOUNTING SPECIFICATIONS G10 PART # 310 104 317 RETURN TO INDEX 03/23/2022...
- Page 11 G2, G6 & G10 USER MANUAL RECEIVER PANEL CUTOUT G10 PART # 310 104 317 RETURN TO INDEX 03/23/2022...
- Page 12 G2, G6 & G10 USER MANUAL SLIDE MOUNT NOTATION REGARDING U HEIGHT PART # 310 104 419, 310 120 100, 310 120 146, 310 120 158, 310 120 208 The slide mechanism protrudes downward into the next u height on both sides of the the receiver.
-
Page 13: Precautionary Notes
ITA frame is not lined up when engaging with receiver • May indicate ITA was dropped and is out of alignment or a module is not mating properly. Remove and inspect the ITA for damage. Contact VPC - user adjustments to system, unless authorized, will void warranty.
