VTAC USER MANUAL
INDEX
(CLICK TO NAVIGATE TO PAGE)
PAGE
2
VTAC PASS-THRU INSERT FEATURE IDENTIFICATION
3
SIM MODULE FEATURE IDENTIFICATION - RECEIVER
4
SIM MODULE FEATURE IDENTIFICATION- ITA
5
i2 MX FEATURE IDENTIFICATION- RECEIVER
6
i2 MX FEATURE IDENTIFICATION- ITA
7
i2 MX VTAC RAIL INSTALLATION/ REMOVAL- RECEIVER & ITA
8
INSERT INSTALLATION/ REMOVAL SIM MODULE & i2 MX- RECEIVER
9
INSERT INSTALLATION/ REMOVAL SIM MODULE- ITA
10
INSERT INSTALLATION/REMOVAL I2 MX- ITA
11
SPECIAL NOTE REGARDING VTAC PATCHCORD INSTALLATION
12
RIGHT ANGLE RETENTION & HEADER FEATURE IDENTIFICATION
13
USING VTAC RIGHT ANGLE HEADER INSTALLATION TOOL
16
MATING SIM MODULES/ i2 MX RECEIVERS TO PCB-MOUNTED VTAC HEADERS
17
RETENTION INSERT INSTALLATION/REMOVAL- SIM MODULES & i2 MX- RECEIVER
18
VERTICAL HEADER PART IDENTIFICATION
20
USING VERTICAL HEADER INSTALLATION TOOL
Please note that any printed or downloaded User Manual may not reflect the most current revisions.
The information contained herein is subject to change.
For the most current information available, visit vpc.com.
Visit VPC on YouTube
for VTAC instructional
videos- Click Here
10/10/2022
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for VPC VTAC
Summary of Contents for VPC VTAC
- Page 1 SPECIAL NOTE REGARDING VTAC PATCHCORD INSTALLATION RIGHT ANGLE RETENTION & HEADER FEATURE IDENTIFICATION USING VTAC RIGHT ANGLE HEADER INSTALLATION TOOL MATING SIM MODULES/ i2 MX RECEIVERS TO PCB-MOUNTED VTAC HEADERS RETENTION INSERT INSTALLATION/REMOVAL- SIM MODULES & i2 MX- RECEIVER VERTICAL HEADER PART IDENTIFICATION USING VERTICAL HEADER INSTALLATION TOOL Please note that any printed or downloaded User Manual may not reflect the most current revisions.
- Page 2 VTAC PASS-THRU INSERT FEATURE IDENTIFICATION PART # 610 151 103 The VTAC Pass-Thru Insert has both a front mating end (Figure A) and rear NOTE: The blue VTAC Insert used for patchcord termination, mating end (Figure B). The front mating end is used to mate with the front versus the VTAC Pass-Thru Insert has raised circular bosses mating end of additional VTAC Pass-Thru Inserts (Figure D).
- Page 3 INDICATES 5 POSITIONS FRONT REAR (MATING) SIDE SIDE EXTRACTION TOOL CAVITY MOUNTING SCREW (2 PLACES) BOTTOM Figure C. Front view (mating side). Figure B. Side view. Figure A. Rear side/ wiring exit side. RETURN TO INDEX For more information visit vpc.com 10/10/2022...
- Page 4 DETAIL B FRONT REAR MATING WIRING SIDE SIDE FRONT MATING REAR SIDE WIRING SIDE BOTTOM Figure C. Front view (mating side). Figure B. Side view. Figure A. Rear view (wiring side). RETURN TO INDEX For more information visit vpc.com 10/10/2022...
- Page 5 Position A1 is located on the front by a cavity marked in black in the top left corner (Figure B). An additional Position A1 indicator can be found in the bottom tier of slots (Tier B), in the top left corner. The cavities are used to place pins from the VTAC Extraction Tool.
- Page 6 (Figure B). An additional position A1 indicator can be found in the bottom tier of slots (Tier B) , in the top right corner. The cavities are used to place pins from the VTAC extraction tool. LOCKING TABS The rear side can be identified as the side that the backshell attaches to (Figure C).
-
Page 7: Installation
Phillips Head Screwdriver INSTALLATION To install VTAC Adapter Rails into the i2 MX Receiver or ITA, first separate the two halves of the frame by unscrewing the Phillips head screws (Figures A and B). Rails are installed in the bottom portion of the frame. - Page 8 PART # 510 170 101, 310 130 113, 310 130 114, 910 112 130 INSTALLATION Ensure the VTAC Insert(s) is in line with the corresponding module/ receiver slot(s). Inserts are installed from the rear side of the receiver/ module. When installing a patchcord containing multiple...
- Page 9 PART # 510 171 101, 910 112 130 INSTALLATION Ensure the VTAC Insert(s) is in line with the corresponding module slot(s). Inserts are installed from the rear side of the ITA module. Place the insert in with the (3) circular bosses facing down(Figure A).
- Page 10 As with installation of any multi-VTAC insert patchcord, the blue insert should be installed on top. To maximize use of the i2 MX bend radius area, it is recommended to first install VTAC patchcords in Tier A (top) ( Figure A). However, special care must be taken when using thicker wire such as RJ45 and Dacar 535.
- Page 11 A is especially important with the i2 MX ITA with housing, as it allows for better utilization of the bend radius. NOTE: Since use of larger diameter VTAC patchcords will not allow full population of all available module/ receiver slot positions, be sure to compensate for this reduced patchcord capacity in your overall system design.
- Page 12 RIGHT ANGLE RETENTION INSERT & HEADER FEATURE IDENTIFICATION PART # 610 151 105, 610 151 104 RIGHT ANGLE RETENTION INSERT LATCH The top of the VTAC Retention Insert is located opposite of the PCB PCB MOUNTING SURFACE mounting surface( Figure A).
- Page 13 USING VTAC RIGHT ANGLE HEADER INSTALLATION TOOL PART # 910 112 132 , 610 151 104 The VTAC Right Angle Header is installed via press fitting, using VPC's CENTER POSITION special installation tool. For a brief video version of these instructions,...
- Page 14 VTAC USER MANUAL USING VTAC RIGHT ANGLE HEADER INSTALLATION TOOL (cont'd) PART # 910 112 132 , 610 151 104 ALIGNING PCB AND USING PRESS Position the board so that the contacts and alignment pins are aligned with the proper holes (Figure F).
-
Page 15: Remove Base
VTAC USER MANUAL USING VTAC RIGHT ANGLE HEADER INSTALLATION TOOL (cont'd) PART # 910 112 132 , 610 151 104 REMOVING FROM PRESS 11. Once done pressing, remove the tool base (Figure J). 12. Remove top half of the tool from the PCB assembly by pushing on the front surface. -
Page 16: Tools Required
Ensure that the necessary module slots contain mating inserts for the PCB's mounted headers. For the purpose of this application, the mating side of the VTAC Pass-Thru insert is the rear. Mate module with PCB assembly. Both ITA and receiver modules will mate to the PCB via the rear side. - Page 17 VTAC Extraction Tool INSTALLATION Install VTAC Right Angle Insert(s) onto PCB (see previous pages). Fasten VTAC Retention Insert to PCB using the two provided pan head Phillips screws. Ensure that the VTAC Retention insert(s) is aligned with the corresponding module/ receiver position(s). Also, ensure that any VTAC Right Angle Inserts are aligned with corresponding VTAC Pass-Thru Inserts.
- Page 18 The top/ mating end is located opposite of the compliant pins (Figure A). The compliant pins mate with the PCB via use of VPC Insertion Tool p/n 910 112 133. The top mates with the VTAC Pass-Thru Insert (Figure A).
- Page 19 PART # 910 112 133, 610 151 107 INSERTING HEADERS INTO TOOL The VTAC Vertical Header Insertion Tool is a two-piece assembly, comprised of a top and a base (Figure A ). Remove the top from the base. Notice the alignment pins on either side of the base.
- Page 20 VTAC Vertical Header drawing (p/n 610 151 107) at vpc.com or use this With the top removed, insert the alignment pins into the alignment holes of the PCB (Figure A).
