Do not open during installation
This product is factory-sealed.
Refer to the instructions contained in this
document for details.
Installation tools
Mounting hardware used on this product
includes fasteners with hexalobular socket
heads (ISO 10664). Installation requires the use
of matching tools.
Surge Protection
This product features built-in surge protection circuitry in compliance with
applicable standards.
For comprehensive protection of a luminaire installation against lightning and
electrical surges, it is essential to cover mains supply and data input lines at
the distribution board level, by using respective primary (Type 1) and secondary
(Type 2) surge arrestors in compliance with EN61643-11/IEC61643-1.
Warning
Ensure that all required surge protection measures are in place and activated
prior to luminaire installation. Also, disconnect luminaires before operating
high-power devices such as, for example, electrical arc welders.
WE-EF LEUCHTEN
Installation and Maintenance
Instructions
Bollards and Pathway Luminaires
MRY224
Advertisement
Related Manuals for WE-EF MRY224
Summary of Contents for WE-EF MRY224
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Bollards and Pathway Luminaires MRY224 Do not open during installation Surge Protection This product is factory-sealed. This product features built-in surge protection circuitry in compliance with Refer to the instructions contained in this applicable standards.
- Page 2 Bollards and Pathway Luminaires MRY224 IP66, IK10, Ta = 25°C for 15 W with 1-10 V dimming, for other T a = 40°C Tool required – Torx T25 (provided by WE-EF) Weight for MRY224 for MRY224 10.8 for MRY224 1000 12.4...
-
Page 3: Maintenance
Light Source Maintenance Apart from cleaning the product’s exterior surfaces, no special maintenance work is required. Do not use high-pressure cleaners. In case of component failure due to abnormal circumstances or at end of life, replacement must be carried out Warning: Do not open luminaire while mains supply is switched on. -
Page 4: Installation
Installation The product must be installed and maintained by a building/construction and/or electrical regulations and relevant legislation. Warning: Switch off mains electrical supply prior to installing and connecting the luminaire. Notice: than the original manufacturer, then the warranty will no longer be valid and shall become the full respon- sibility of the modifying person/organisation. -
Page 5: Installation Procedure
Installation Procedure 1) Switch off mains electrical supply. 2) Loosen screw A. 3) Remove sleeve B including luminaire head 4) Pull cable D through centre-hole. Ensure from post C. orientation of post C allows easy access to terminal block G with M10 bolts/nuts to ground. - Page 6 5) Check that rating shown on luminaire label of light is opposite terminal block G. conforms to mains electrical. Orientation of light must be decided prior to 04/20 IP66/IP67 installation of post C. MRY224 220-240V/50 Hz 1-10 115-XXXX SOE XXXXXXX LED 3000K 15W item no. XXX (example)
- Page 7 8) Align sleeve B 9) Tighten screw A with Torx T25 tool (provided by WE-EF).
- Page 8 WE-EF HELVETICA WE-EF LIGHTING Switzerland United States of America Tel +41 22 752 49 94 Tel +1 724 742 0030 Fax +41 22 752 49 74 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com TO9268W0521 © WE-EF 2021 subject to change.
