Hearth & Home MESH-RETRO1928 Instructions

MESH-RETRO1928, MESH-RETRO2819, MESH-RETRO3028,
MESH-RETRO3121, MESH-RETRO3625, MESH-RETRO4226, MESH-RETRO2125
Leave this manual with party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
fl ammable materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
This kit has adjustable top brackets that are designed to
hook into the top louver assembly.
HOOD
TOP LOUVER
BOTTOM LOUVER
Figure 1. Fireplace Front (Generic-Not a Specifi c Model)
Hearth & Home Technologies • Mesh Safety Barrier Instructions • 2012-699 Rev. D • 7/14
Mesh Safety Barrier Instructions
The top and bottom brackets will ship in a fl at position and
must be bent. See Figure 2. The brackets are intended to
be bent by hand, but a needle-nose pliers may also be used.
Figure 2. Mesh Bracket Locations
1. Bend two bottom brackets as shown in Figure 3.
Figure 3. Bend Bottom Brackets
2. Bend top bracket as shown in Figure 4.
Figure 4. Bend Top Brackets
TOP
NOT BENT
BOTTOM
VELCRO
2ND BEND
BENT
1ST BEND
