RNX-G100 / RNX-G200 / RNX-G300(E)

3.2 Install Adapter

3.2.1 Cardbus Adapter- RNX-G200
Power on your notebook, let the operating system boot up completely, and log in as needed.
Hold the adapter with the LOGO facing up and insert it into a Cardbus slot.
If the Found New Hardware Wizard displays, choose Install the software automatically
(Recommended), and click Next button. The driver will be installed automatically.
3.2 .2 PCI Adapter- RNX-G300(E)
Open your PC case and locate an available PCI on the motherboard.
Slide the PCI Adapter into the PCI slot. Make sure that all of its pins are touching the slot's
contacts. You may have to apply a bit of pressure to slide the adapter all the way in. after the
adapter is firmly in place, secure its fastening tab to your PC's chassis with a mounting
Figure 3-1
Figure 3-2
7
