KMC Controls FlexStat BAC-19 Series Installation Manual

Hide thumbs Also See for FlexStat BAC-19 Series:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
Quick Start ............................................... 1
Wiring Considerations................................. 2
Mounting .................................................. 2
Network Connections ................................. 4
Input Connections ................................... 5
Output Connections ................................. 5
Power Connection ...................................... 6
Configuration and Programming ................... 7
MS/TP Network Access Port ........................ 7
Maintenance ............................................. 7
Additional Resources .................................. 8
Important Notices ...................................... 8

QUICK START

Complete the following steps to select and install
a KMC Conquest BAC-19xxxx FlexStat:
1. Select the appropriate model for the intended
application and options (see the
Series FlexStats Data Sheet
com).
2. Mount and wire the unit (see this document
and the
BAC-19xxxx FlexStat Sequence of
Operation and Wiring
3. Configure and operate the unit (see this docu-
ment and the
BAC-19xxxx FlexStat Applica-
tion
Guide).
4. If necessary, troubleshoot any issues (see the
BAC-19xxxx FlexStat Application
NOTE: This document gives basic mounting,
wiring, and setup information. For
additional information, see the KMC
Controls web site for the latest
documents.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
BAC-190000
at
kmccontrols.
Guide).
Guide).
BAC-19xxxx FlexStat
KMCConquest
Automation Hardware
CAUTION
The BAC-19xxxx models are
NOT compatible with the
backplates of older BAC-
10xxx/12xxxx/13xxxx/14xxxx
FlexStats! If replacing an older
FlexStat, replace the backplate as
well.
/
877.444.5622
/
Fax: 574.831.5252
Installation Guide
TM
NOTICE
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
SENSITIVE DEVICES
/
www.kmccontrols.com

Advertisement

Table of Contents
loading

Related Manuals for KMC Controls FlexStat BAC-19 Series

Summary of Contents for KMC Controls FlexStat BAC-19 Series

  • Page 1: Table Of Contents

    FOR HANDLING ELECTROSTATIC NOTE: This document gives basic mounting, SENSITIVE DEVICES wiring, and setup information. For additional information, see the KMC Controls web site for the latest documents. KMC Controls, 19476 Industrial Drive, New Paris, IN 46553 877.444.5622 Fax: 574.831.5252 www.kmccontrols.com...

  • Page 2: Wiring Considerations

    FlexStat installation. Cable insulation must meet local building codes. CAUTION Use only the mounting screw supplied by KMC Controls. Using other screws may damage the FlexStat. Do not turn the screw in farther than necessary to remove the cover.
  • Page 3 See also the BAC-19xxxx FlexStat Sequence of Operation and Wiring Guide, and the BAC- 19xxxx FlexStat Application Guide.) NOTE: SC = Switched Ethernet Network (relay) Common Connector (Optional, on NOTE: IN1 is reserved for Cover) the internal temp sensor Outputs Illustration 2—Unlocking the Cover from the Backplate Analog 9 MS/TP Network...

  • Page 4: Network Connections

    CAUTION When reinstalling the cover on the backplate, be careful not to damage or dislodge any wiring or components. Do not use excessive force. If there is any binding, pull off the cover and examine pins and terminal socket connectors. Illustration 9—Ethernet Network Connection ("E"...

  • Page 5: Sensor And Equipment Connections

    SENSOR AND EQUIPMENT CONNECTIONS NOTE: The S (Shield) terminal in KMC controllers is provided as a connecting Input Connections point for the shield. The terminal is not connected to the ground of 1. Wire any additional sensors to the appropriate the controller.

  • Page 6: Power Connection

    (See Illustration 11.) For the relay 2. Connect a 24 VAC, Class-2 transformer (or circuit, the phase side of the AC 24 VDC power supply) to the power terminals should be connected to the SC (see Illustration 12): terminal. FlexStat relays are NO, SPST A.

  • Page 7: Configuration And Programming

    CONFIGURATION AND PROGRAMMING MS/TP NETWORK ACCESS PORT To set up the FlexStat from the touchscreen: The MS/TP EIA-485 data port on the bottom of the cover provides technicians temporary access 1. Push and hold the upper left corner of the to an MS/TP network (not Ethernet) using an screen (space temperature reading) to start.

  • Page 8: Additional Resources

    KMC Controls, Inc. makes no representations or • Input/output objects and connections warranties with respect to this document. In no event shall KMC Controls, Inc. be liable for any See the BAC-19xxxx FlexStat Application Guide damages, direct, or incidental, arising out of or for: related to the use of this document.
