APPENDIX D

AUDIBLE ALARM CODES

CAUSE
COMMON ALARM DUE TO VIOLATION OF
LIMITS
LOSS OF POWER (INCLUDES TURNING OFF)
INTERFACE PROCESSOR FAILURE
SOLENIOD PROCESSOR FAILURE
SOLENOID A
SOLENOID B
PROCESSOR COMMUNICATION OR
TRANSDUCER ERROR
SOLENOID D1
SOLENOID D2
SOLENOID D3
SOLENOID E2
BEEPER CONTROL CIRCUIT
APPENDIX E

CHARGERS AND INVERTERS

This explains some of the requirements for connecting a Bio-Med Devices Crossvent ventilator to a charger or AC adapter.
It is important that the correct charger be used and if a Crossvent is to be used in a vehicle with an AC generating device
(inverter), it must comply with certain requirements.
1. LAND OPERATION
When using an AC adaptor to either run the Crossvent or to charge the batteries, only the Jerome Industries model
WSZ116M (16VDC 3A) charger supplied by Bio-Med Devices should be used.
The Bio-Med charger has been thoroughly tested for proper operation with the Crossvent to make sure that all standards are
met. This includes all of the applicable standards for safety, EMI/RFI, power surges, and leakage. It is approved for medical
applications and conforms to FDA, UL, and other required standards.
Although other forms and brands of chargers may operate the Crossvent, there is no guarantee of system reliability or
conformance to required standards.
Should an emergency arise and it becomes necessary to operate the Crossvent without the Bio-Med charger, use only a
charger that is approved for medical use and complies with all applicable standards. It must produce filtered DC voltage
ranging between 12 and 28 volts DC and be rated for continuous 2.5 amps of current.
Should a Crossvent fail to operate or charge from a charger, both the Crossvent and the charger should be returned together
to Bio-Med Devices for evaluation.
AUDIBLE SEQUENCE
1 LONG
1 LONG
2 LONG
3 LONG
1 LONG, 1 SHORT
1 LONG, 2 SHORT
1 LONG, 3 SHORT
2 LONG, 1 SHORT
2 LONG, 2 SHORT
2 LONG, 3 SHORT
2 LONG, 4 SHORT
CONTINUOUS
84
___
___ ___
___ ___ ___
CONTINUOUS
