IV. S E T U P A N D

B- OPERATING INSTRUCTIONS

The following describes the procedure for setting up and operating the Crossvent-2i+ Ventilator. It is assumed that the
operator is thoroughly familiar with the Specifications, Theory of Operation, Tests and Calibration procedures as
outlined in this manual. It is also assumed that the ventilator is already fully assembled, has been tested and calibrated
and is connected to a test lung.
This equipment has been tested and found to comply with the limits for a class B digital device. These limits are
designed to provide reasonable protection against harmful interferences in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures: reorient or relocate the receiving antenna, increase the separation between
the equipment and the receiver, connect the equipment into an outlet on a circuit different from that to which the
receiver is connected, or consult the dealer or an experienced radio/TV technician for help.
WARNINGS
ONLY QUALIFIED MEDICAL PERSONNEL SHOULD OPERATE THE
VENTILATOR.
DO NOT ATTEMPT TO VENTILATE A PATIENT UNTIL THOROUGHLY
FAMILIAR WITH ALL OF THE OPERATING INSTRUCTIONS.
THE
RECOMMENDED CLINICAL PROTOCOLS.
ALWAYS TEST THE VENTILATOR PRIOR TO EACH USE. AFTER SET UP,
VENTILATE A TEST LUNG TO VERIFY PROPER OPERATION PRIOR TO
CONNECTING THE VENTILATOR TO A PATIENT.
IF A MALFUNCTION SHOULD OCCUR, THE UNIT SHOULD BE REMOVED
FROM USE AND REPAIRED PRIOR TO USING IT AGAIN ON PATIENTS.
WHENEVER AN ALARM CONDITION EXISTS IT SHOULD BE RECTIFIED
IMMEDIATELY.
CONDITION FOR AN EXTENDED LENGTH OF TIME.
DO NOT CONTINUE USING A VENTILATOR WHICH HAS BEEN
SIGNIFICANTLY IMPACTED OR ABUSED.
NOTE: Since it is not possible to damage the Crossvent-2i+ Ventilator by normal use of its keys and
control knobs, the user is encouraged to experiment with the Crossvent-2i+ settings while the unit is
not connected to a patient.

1- PRELIMINARY STEPS

Verify the BMD power supply output connector is plugged into to the mating connector of the ventilator and plug the
power supply into an external electrical outlet.
Connect a patient circuit to the ventilator. Connect a test lung (BMD #1021) to the proximal airway connector.
Turn on the gas supply source to the input connector.
O P E R A T I N G I N S T R U C T I O N S -
OPERATING INSTRUCTIONS
NEVER ALLOW VENTILATION WITH AN ALARM
C O N T .
ARE NOT
25
