III. S P E C I F I C A T I O N S ,

B- SPECIFICATIONS

Parameter
CMV Rate
SIMV Rate
CPAP Rate
Tidal Volume
Inspiratory Time
Flow Rate
Peak Pressure (PIP)
PEEP Pressure
Flow Trigger
Pressure Support
O Sensor
2
EXHTV
EXHMV
1. Readings below 10 ml may be considered relative rather than absolute values.
2. NOTE: All values are expressed under ATPD conditions (ambient temperature & pressure dry)

C- ADDITIONAL SPECIFICATIONS

Base Flow
Continuous Flow
Maximum Safety Pressure:
Pneumatic Power Source
Audible Alarm Characteristics
Electrical Power Source
See Appendix E
Output:
Output Protection:
Isolation:
Maximum Ripple:
Safety:
EMC:
Overall Dimensions
Height:
Width:
Depth:
Weight:
Operating Temperature:
C O N N E C T I O N S
Range
1- 150 bpm 1 bpm
0.6- 50 bpm 0.1 bpm below 1, 1 bpm above 1
5- 150 bpm 1 bpm
5- 750 ml 1 ml below 200; 10 ml above 200
0.1- 3.0 .05 below 1.00, 0.1 above 1.00
1- 15 lpm 0.1 lpm below 10; 1 lpm above 10
0- 80 cmH O 1 cmH
2
0- 20 cmH O 1 cmH
2
1- 20 (scale) 1 unit
1- 50 cmH O 1 cmH
2
0- 100 % 1%
0- 1300 ml 0.1 ml below 50; 1 ml from 50-200, 10 ml thereafter
0- 45 L 0.1 L below 10, 1 L thereafter
2.5 lpm
1 – 15 lpm
96 cmH
17 – 55 psi (117 kPa – 380 kPa)
90 dB at 10cm (25°C)
16.0 VDC, 3 A
Short Circuit and Overload
Meets IEC601.1, classification BF, UL 544 Patient Care, CSA 125 Risk Class
2G
<100 mVp-p
Approved to UL 544/2601.1, CLU (CSA) 22.1 #125/601.1, TUV
EN60601.1 & CE LVD
Designed to Level B Requirements of FCC part 15, CISPR11 (EN55011).
Less than 1 Volt Output Deviation for IEC801-2, 3, 4, 5, Immunity Tests.
7.5" (191 mm)
8.4" (213 mm)
4.4" (112 mm)
7.65 lbs. (3.5 kg)
32 to 104 degrees F. (0 to 40 degrees C)
A N D U S E R I N T E R F A C E -
Resolution of Display
O
2
O (above baseline)
2
O (above baseline)
2
O
2
11
C O N T .
Accuracy
±10%
±10%
±10%
±10%
±10%
±10%
±3% FS
±3
N/A
±3
±3% FS
±15%
1
±15%
1
1
