To our customers,
Old Company Name in Catalogs and Other Documents
st
On April 1
, 2010, NEC Electronics Corporation merged with Renesas Technology
Corporation, and Renesas Electronics Corporation took over all the business of both
companies. Therefore, although the old company name remains in this document, it is a valid
Renesas Electronics document. We appreciate your understanding.
Renesas Electronics website:
Issued by: Renesas Electronics Corporation (http://www.renesas.com)
Send any inquiries to http://www.renesas.com/inquiry.
http://www.renesas.com
st
April 1
, 2010
Renesas Electronics Corporation

Advertisement

Table of Contents
loading

Related Manuals for Renesas FP-256H

Summary of Contents for Renesas FP-256H

  • Page 1 On April 1 , 2010, NEC Electronics Corporation merged with Renesas Technology Corporation, and Renesas Electronics Corporation took over all the business of both companies. Therefore, although the old company name remains in this document, it is a valid Renesas Electronics document. We appreciate your understanding.
  • Page 2 Renesas Electronics. Renesas Electronics shall not be in any way liable for any damages or losses incurred by you or third parties arising from the use of any Renesas Electronics product for an application categorized as “Specific”...
  • Page 3 SH7058 Group FP-256H User System Interface Board HS7058ECF61H User’s Manual Renesas Microcomputer Development Environment System SuperH™ Family/SH7050 Series Rev.6.0 2004.01...
  • Page 4 6. The prior written approval of Renesas Technology Corp. is necessary to reprint or reproduce in whole or in part these materials. 7. If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license from the Japanese government and cannot be imported into a country other than the approved destination.
  • Page 5 Preface The HS7058ECF61H is a user system interface board that connects a user system for the SH7058 FP-256H package to the SH7058 E6000H emulator (HS7058EPH60H).

  • Page 6: Table Of Contents

    Section 1 Configuration...1 Section 2 Connection Procedures ...3 Connecting User System Interface Board to User System ... 3 2.1.1 Installing IC Socket... 3 2.1.2 Installing IC Socket Connector ... 4 Fastening IC Socket Connector... 5 2.1.3 Exchanging the Spacer of the EV-Chip Board... 6 Connecting User System Interface Board to EV-Chip Board ...

  • Page 7: Section 1 Configuration

    Section 1 Configuration Figure 1 and table 1 show the configuration and components of the user system interface board for the FP-256H package. Please make sure you have all of these components when unpacking. EV-chip board Spacer Board Screw M3 ×...
  • Page 8 Use a TQPACK256RD socket and a TQSOCKET256RDP (manufactured by Tokyo Eletech Corporation) for the FP-256H package IC socket and IC socket connector on the user system. Table 1 HS7058ECF61H Components No. Component Board IC socket IC socket connector Screw (M3 x 5 mm) Spacers (2.6MP x 25 mm) 2...

  • Page 9: Section 2 Connection Procedures

    2.1.1 Installing IC Socket 1. Solder the IC socket for an FP-256H package to the user system (figure 2). Be sure to completely solder the leads so that the solder slops gently over the leads and forms solder fillets. (Use slightly more solder than the MCU.)

  • Page 10: Installing Ic Socket Connector

    2. After checking the location of pin 1 on the IC socket connector and pin 1 on the IC socket, align the guide pins on the IC socket connector with the guide holes on the IC socket, and insert the IC socket connector into the IC socket (figure 2). Check the location of pin 1 before inserting.

  • Page 11: Fastening Ic Socket Connector

    2.1.3 Fastening IC Socket Connector 1. Use a hexagonal wrench ( 1.5 mm). 2. Stop tightening when the force required to turn the screw becomes significantly greater than that needed when first tightening. If a screw is tightened too much, the screw head may break or an IC socket contact error may be caused by a crack in the IC socket solder.

  • Page 12: Exchanging The Spacer Of The Ev-Chip Board

    Exchanging the Spacer of the EV-Chip Board While the user system interface board is connected to the user system, force must not applied to the user system. Exchange the spacer (2.6MP x 10 mm) of the EV-chip board with another spacer (2.6MP x 25 mm) provided for the user system interface board.

  • Page 13: Connecting User System Interface Board To Ev-Chip Board

    Connecting User System Interface Board to EV-Chip Board Observe the precautions listed below. Failure to do so will result in a FIRE HAZARD and will damage the user system and the emulator product or will result in PERSONAL INJURY. The USER PROGRAM will be LOST.
  • Page 14 Figure 5 Connecting User System Interface Board to EV-Chip Board EV-chip board Connector No. Board EV-Chip Board Board Connector No. Connector No. UCN1 UCN1 UCN2 UCN2...

  • Page 15: Recommended Dimensions For User System Mount Pad (Footprint)

    Figure 6 shows the recommended dimensions for the mount pad (footprint) for the user system with an IC socket for an FP-256H package (TQPACK256RD: manufactured by Tokyo Eletech Corporation). Note that the dimensions in figure 6 are somewhat different from those of the actual chip's mount pad.

  • Page 16: Dimensions For Ev-Chip Board And User System Interface Board

    Dimensions for EV-Chip Board and User System Interface Board The dimensions for the EV-chip board and the user system interface board are shown in figure 7. Spacer Figure 7 Dimensions for EV-Chip Board and User System Interface Board 120.0 EV-chip board 100.0 84.0 50.0...

  • Page 17: Resulting Dimensions After Connecting User System Interface Board

    Resulting Dimensions after Connecting User System Interface Board The resulting dimensions, after connecting the user system interface board to the user system, are shown in figure 8. IC socket connector (Tokyo Eletech Corporation TQSOCKET256RDP) EV-chip board IC socket (Tokyo Eletech Corporation TQPACK256RD) User system Spacer ( 6.0)

  • Page 18: Section 3 Verifying Operation

    Section 3 Verifying Operation 1. Turn on the emulator according to the procedures described in the SH7058 E6000H Emulator User's Manual (HS7058EPH60HE). 2. Verify the user system interface cable connections by checking the pin states with the CHECK command (emulator command) and checking the bus states with the FILL command (emulator command).
  • Page 19 To use the crystal oscillator mounted on the EV-chip board Install a crystal oscillator into the crystal oscillator terminals on the EV-chip board. Crystal oscillator terminals Figure 10 Installing the Clock Oscillator Enlarged view Crystal oscillator Evaluation chip board...

  • Page 20: Section 4 Notice

    The MCU cannot be installed directly into the IC socket provided for connecting this user system interface board. Before connecting any parts or cables, make sure that pin 1 on the both sides are correctly aligned. Do not apply excessive force to the user system interface board while it is connected to the user system.
  • Page 21 HS7058ECF61H User's Manual Publication Date: Rev.6.00, January 29, 2004 Published by: Sales Strategic Planning Div. Renesas Technology Corp. Edited by: Technical Documentation & Information Department Renesas Kodaira Semiconductor Co., Ltd. 2004 Renesas Technology Corp. All rights reserved. Printed in Japan.
  • Page 22 SH7058 Group FP-256H User System Interface Board HS7058ECF61H User’s Manual 1753, Shimonumabe, Nakahara-ku, Kawasaki-shi, Kanagawa 211-8668 Japan REJ10B0089-0600H...
