Routine Maintenance

C
Main Brush
C1
* Clean every 2 weeks and replace every 6-12 months
C1-1—Main Brush Cover
C1-2—Latches
C1-3—Main Brush
C1-4—Main Brush Caps
C1-5—Main Brush Bearing
C1-6—Turn over the robot and press the
latches to remove the main brush cover.
C1-7—Pull out the main brush and remove
the main brush bearing.
C1-8—Rotate the main brush caps in the
indicated unlock direction to remove the caps.
C1-9—After removing the tangled hair or dirt
at both ends of the main brush, reinstall
it, press on the main brush cover to
lock it in place. Make sure that the
main brush cover has been properly
attached. When properly installed,
all four tabs should be hidden.
Notes:
• Main brush should be wiped down with wet cloth and left to
dry away from direct sunlight.
• Do not use corrosive cleaning fluid or disinfectant to clean
the main brush.
Side Brush
C2
* Clean every month and replace every 3 to 6 months
1. Unscrew the side brush screw.
2. Remove and clean the side brush. Reinstall
the brush and tighten the screw.
Omni-Directional Wheel
C3
* Clean as needed
C3-1—Use a tool, such as a small
screwdriver, to pry out the axle and
take out the wheel.
Note: The omni-directional wheel bracket cannot be removed.
C3-2—Rinse the wheel and the axle with
water to remove any hair and dirt.
Air-dry, reinstall, and press the wheel
and axle back in place.
Main Wheels
C4
* Clean every month
Clean the main wheels with a soft, dry cloth.
Dustbin and Washable Filter
C5
* Clean every week and filter should be replaced every 6-12 months.
C5-1—Open the upper cover of the robot
and take out the dustbin.
C5-2—Remove the washable filter and
empty the dustbin.
C5-3—Fill the dustbin with clean water.
Gently shake the dustbin, and then
pour out the dirty water.
Note: To prevent blockage, only use clean water without any
cleaning liquid.
C5-4—Rinse the washable filter repeatedly and tap
it to remove as much dirt as possible.
Note: Do not touch the surface of the filter with your hands,
brush, or hard objects to avoid potential damage.
C5-5—Leave the dustbin and the washable
filter to dry and reinstall them.
10
Mop Cloth
C6
* Clean after each use and replace every 3 to 6 months
C6-1—Remove the mop cloth from the
mopping module. Wash and air dry
the mop cloth.
Notes:
• After cleaning, always remove the mop cloth to prevent dirty
water from leaching back into the clean water tank.
• A dirty mop cloth will compromise the washing
performance. Clean it before use.
Filter Components
C7
* Replace them every 1 to 3 months
C7-1—Mop Attachment Slot
1. Move your finger along the notch to
remove each filter.
2. Insert new filter components and make
sure they are properly installed.
Note: To ensure cleaning performance, replace the filter
components every 1 to 3 months, depending on the water
quality and how often you use the robot.
Dust Bag Replacement
C8
* Replace as needed.
C8-1—Remove the dustbin cover vertically
as shown.
C8-2—Lift the dust bag out of the dustbin
and discard it.
Note: The dust bag handle seals the bag on removal to prevent
dust leakage.
C8-3—Clean the filter with a dry cloth.
