Summary of Contents for Hay CAN SOFA
- Page 1 – INSTRUCTION MANUAL – CAN SOFA DESIGN BY RONAN & ERWAN BOUROULLEC...
- Page 3 – PARTS 1-SEATER – Seat frame x1 Front leg x2 Bag leg x2 Armrest tube x2 Backrest tube x1 Canvas x1 Side pillow x2 Back pillow x1 Seat pillow x1 Allen key x1 Screw x12...
- Page 4 – PARTS 2-SEATER – Front leg x2 Bag leg x2 Armrest tube x2 Seat frame x1 Backrest tube x1 Canvas x1 Side pillow x2 Back pillow x2 Seat pillow x1 Screw x12 Allen key x1...
- Page 5 – PARTS 3-SEATER – Front leg x2 Bag leg x2 Armrest tube x2 Seat frame x1 Backrest tube x1 Canvas x1 Side pillow x2 Back pillow x3 Seat pillow x1 Screw x12 Allen key x1...
- Page 6 Locate the backside of the seat frame , marked with a white sticker, and insert the back legs into each back corner.
- Page 7 Secure the back legs to the seat frame by slightly fastening one screw in the hole closest to the centre of the sofa.
- Page 8 Pull the legs gently outwards.
- Page 9 Insert the backrest tube into the middle part of the canvas. NOTICE 2- and 3-seaters – Make sure the Backrest tube is facing the right way. The Backrest tube is marked with a white sticker that should face the outside of the sofa.
- Page 10 Insert the backrest tube into both back legs . Make sure the canvas is mounted with the cotton strap facing outwards. Twist to hear a “click”.
- Page 11 Insert the armrest tube into the canvas. Make sure the canvas is kept on the inside of the back leg C. .
- Page 12 Insert the armrest tube into the back leg Twist to hear a “click”.
- Page 13 Insert the front leg gently into the frame and armrest tube Repeat step 6, 7 and 8 on the other side.
- Page 14 Gently secure the front legs and back legs to the frame fastening the screws in all four corners. NOTICE It is important NOT to tighten the screws completely yet.
- Page 15 Turn the frame forward to give easy access to the bottom of the seat frame. Make sure to place it on the box to avoid scratching the frame.
- Page 16 Secure the front legs and back legs to the frame from the bottom side by fastening the screws in all four corners.
- Page 17 MOUNTING CANVAS Slide the plastic profile onto the bottom of the seat frame. It is important to start at one end and work your way to the opposite side. Make sure the canvas is fully stretched all the way to the corners.
- Page 18 Secure the front legs and back legs to the frame by fastening the screws in all four corners.
- Page 19 MOUNTING CANVAS Place the cotton strap around the front leg and slide it through the leather ring. Adjust the canvas and then tighten it by pulling the cotton strap and fastening it to the velcro. Make sure all velcro is covered.
- Page 20 ADJUSTING CANVAS Adjust the canvas at the frame. Start at one end and work your way to the opposite side. Make sure the canvas is not folded or misplaced anywhere.
- Page 21 Place the seat cushion while also pushing it back, so that it is as far back as possible.
- Page 22 Place the back pillow and side pillows in the frame.
- Page 23 Over time, your sofa will need some attention to ensure that the cushions remain plump and the seat cushion keeps its shape. Straighten out any creases and lumps in the seat cushion with your hands.
- Page 24 Plump the cushions regularly.
-
Page 25: Care And Maintenance
Please find our Care & Maintenance guide by scanning the QR code You can find more relevant information on Can Sofa by scanning the QR code You can also find the same information here hay.dk/downloads... - Page 28 Havnen 1 8700 Horsens Denmark +45 4282 0282 / hay@hay.com www.hay.com 22/12/2021...
