SMAY WKP Installation Manual

Type multi-blade fire damper

Table of Contents

Need help?

Do you have a question about the WKP and is the answer not in the manual?

Page 2 Both opening and closing should proceed smoothly. During the testing of WKP-T fire damper, check the operation of the ratchet mechanism by cutting off the power and waiting approx. 1-4 seconds (lock response time) from the time of cutting of the power to the release of the release mechanism.
Page 3 Installation manual WKP type multi-blade fire damper Remarks on WKP-T fire damper Screw the last board (thick. 12.5 [mm] and a width of 300 [mm]), which covers the lever system side, leading the screws along the length of the section at a distance of no more than 25 [mm] from the clearance of the fire damper - (see Fig.
Page 4 Installation manual WKP type multi-blade fire damper Figure 1. Installation method of the WKP type multi-blade fire dampers in lightweight partition walls Version: 2.0.1 page 4 z 6...
Page 5 1.2. Concrete or brickwork walls INSTALLATION TECHNOLOGY According to the Figure 2 1. Make an opening in the wall with dimensions shown in the figure 2. 2. In case of installing the fire damper with actuator set on different than first axis, the opening intended for actuator should be moved downwards respectively by dimension N x 100, where N - the number of blade driven directly by the actuator.
Page 6 Installation manual WKP type multi-blade fire damper Figure 2. Installation method of the WKP type multi-blade fire dampers in concrete or brickwork walls Version: 2.0.1 page 6 z 6...
