- Page 1 USER MANUAL Longo programmable controller LPC-2.NE1 module Version 4 SMARTEH d.o.o. / Trg tigrovcev 1 / 5220 Tolmin / Slovenia / Tel.: +386 (0)5 388 44 00 / e-mail: info@smarteh.si / www.smarteh.si...
- Page 2 Longo programmable controller LPC-2.NE1 module Written by Smarteh d.o.o. Copyright © 2012, SMARTEH d.o.o. User Manual Document Version: 004 July 1, 2012...
- Page 3 Vibrations and climatic-mechanical: EN 60068-2-6, EN 60068- • 2-27, EN 60068-2-29 Smarteh d.o.o. operates a policy of continuous development. Therefore we reserve the right to make changes and improvements to any of the products described in this manual without any prior notice.
-
Page 4: Table Of Contents
Longo programmable controller LPC-2.NE1 module Longo programmable controller LPC-2.NE1 module 1 DESCRIPTION....................1 2 FEATURES....................2 3 INSTALLATION...................3 3.1 Connection scheme example............3 3.2 Mounting instructions...............5 3.3 Module labeling................6 4 OPERATION....................7 4.1 IP and MAC setting................7 4.2 Modbus protocol usage..............7 5 TECHNICAL SPECIFICATIONS..............9 6 CHANGES....................10... -
Page 5: Description
Longo programmable controller LPC-2.NE1 module 1 DESCRIPTION LPC-2.NE1 Ethernet module is intended to connect LPC-2 standalone system with LAN . It acts as Modbus slave device, using TCP/IP protocol. IP and MAC addresses are configurable from main controller module application. -
Page 6: Features
Longo programmable controller LPC-2.NE1 module 2 FEATURES Figure 1: LPC-2.NE1 communication module Table 1: Technical data Compliant to Ethernet II and IEEE802.3 10Base5, 10Base2, 10BaseT, 10Mbps IP and MAC address management Modbus slave device mode, TCP/IP protocol Modbus commands support... -
Page 7: Installation
Longo programmable controller LPC-2.NE1 module 3 INSTALLATION 3.1 Connection scheme example Figure 2: Connection scheme example... - Page 8 Longo programmable controller LPC-2.NE1 module Table 1: K3 communication port ETH.1 Tx data + transmit wire pair ETH.2 Tx data - ETH.3 Rx data + receive wire pair ETH.6 Rx data - Table 2: internal bus Connection to other comm.
-
Page 9: Mounting Instructions
Mounting instructions: 1. Switch OFF main power supply. 2. Mount LPC-2.NE1 module to the provided place inside an electrical panel (DIN EN50022-35 rail mounting) to the left side of the LPC-2 controller module. 3. Mount other LPC-2 modules (if required). Mount each module to the DIN rail first, then attach modules together through K1 and K2 connectors. -
Page 10: Module Labeling
00000002 and the next one 00000004. Label 3 description: 1. 20-41-5A-1A-00-0C is a unique MAC dedicated to each NE1 module 20-41-5A: 24-bit first portion is the OUI value assigned to Smarteh by the IEEE • Registration Authority 1A-00-0C: 24-bit second portion is the OUI value assigned by Smarteh... -
Page 11: Operation
NE1_x_MAC6 last hex noted pair of OUI 48-bit MAC notation 4.2 Modbus protocol usage LPC-2.NE1 Ethernet adapter is Modbus slave device and supports Modbus commands as defined in protocol specification V1.1a, using TCP/IP protocol, RTU transmission mode, ISO OSI model. - Page 12 Longo programmable controller LPC-2.NE1 module Memory layout: LPC-2 ETHERNET LPC-2.NE1 direction memory sector modbus direction Modbus variable address functions NE1_x_bOUT001 Discrete input [bit size] 0x02 NE1_x_bOUT002 -->> -->> NE1_x_bOUT128 NE1_x_bIN001 Coil [bit size] 0x05 NE1_x_bIN002 <<-- -->> 0x0F <<-- 0x01...
-
Page 13: Technical Specifications
Longo programmable controller LPC-2.NE1 module 5 TECHNICAL SPECIFICATIONS Table 5: Technical specifications Power supply from internal BUS Power consumption 0.5 W Connection type RJ45 FM connector suitable mating RJ45 male, cable connector Dimensions (L x W x H) 90 x 18 x 60 mm... -
Page 14: Changes
Longo programmable controller LPC-2.NE1 module 6 CHANGES The following table describes all the changes to the document. Date Description 1.7.2012 CGP General update. 11.5.2010 Updated warranty permanence. 23.3.2010 added Label 3 description 23.4.2007 The basic version, issued as User Manual user manual . -
Page 15: Notes
Longo programmable controller LPC-2.NE1 module 7 NOTES...
