Legend
1 Beam entrance
2 Scan head
3 Objective (not shown true-to-
scale)
4 Emerging beam
5 Image field
Dimensions
A = 390 mm
B = 32 mm
C = 94 mm
D = 120 mm
E = 57.15 mm
Note: drawing not true-to-scale
Working Distance A, distances B-E (see
®
hurrySCAN
Rev. 2.6 e
4 Installation
A
chapter 4.4) and dimensions (hurrySCAN
10, digital, 1064 nm, f = 254 mm
E
1
3
4
®
10 with objective SCANLAB #100832)
2
B
ØD
5
C
8
