Scanlab hurrySCAN 10 Installation & Operation Manual page 19

2
1
Legend
1 Mounting screws *
2 Laser system flange *
3 Alignment pins *
4 Scan head mounting bracket
(* not included)
Scan head with mounting assembly (all dimensions in mm)
®
hurrySCAN 10, digital, 1064 nm, f = 254 mm
Rev. 2.6 e
4 Installation
5
1 6
5
4
3
1 1
4
5 Possible positions of electrical connectors
5
5
1 7
(the actual connector type and position of this
scan head are shown in figure
1 1
8
5)
6
19
