Scanlab hurrySCAN 10 Installation & Operation Manual page 20

Mounting bracket with holes for beam-in, alignment pins and mounting screws
Bottom view and beam displacement
Scan head mounting bracket and bottom view (all dimensions in mm)
®
hurrySCAN 10, digital, 1064 nm, f = 254 mm
Rev. 2.6 e
4 Installation
57.15
H7
Ø6
Ø20
M6
114
12.56
Beam in
42.8
38.1
M6
H7
Ø6
7
20
