EU-293 User manual
4.1.

BLOCK DIAGRAM - MAIN MENU

Automatic manual mode
Pre-set comfort temperature
Pre-set economical temperature
Pre-set temperature hysteresis
Temperature sensor calibration
Maximum floor temperature*
Minimum floor temperature*
Floor temperature hysteresis
*These functions are displayed only after the additional sensor has been connected to the floor sensor contact and
activated in the controller menu by selecting ON in the Floor sensor submenu.
4.2.

DAY OF THE WEEK

After entering the main menu, all icons which are not connected with the
parameter which is being edited are not displayed. The first parameter is
day of the week. Press
displayed.
Press MENU to confirm and move on to the next parameter or press EXIT
to confirm and return to the main screen view.
Day of the week
Clock settings
Day from...
Night from...
Button lock
Optimum start
Weekly program
Floor sensor
Service menu
or until the current day of the week is
Heat/Cool
Edition min. pre-set temperature
Edition max. pre-set temperature
Factory settings
15
