EU-297

VIII. CONTROLLER FUNCTIONS

The user navigates in the menu structure using touch buttons: EXIT,
parameters, press MENU. By pressing MENU the user may preview the controller functions. The edited parameter is
flashing. Use the buttons
to edit the next parameter.
1.

BLOCK DIAGRAM - MAIN MENU

1.1.

CLOCK

In order to set the time, press MENU button until the clock settings appear on the screen.
The settings concern the flashing parameter.
Use or to set the hour. Next, press MENU to move to the next parameter - minutes.
1.2. PRE-SET DAY TEMPERA TURE
In order to define the pre-set day temperature, press MENU button until a flashing
icon appears on the screen.
Use or to set the day temperature.
to change the parameter settings. Press MENU to confirm the changes and move on
Clock

Pre-set day temperature

Day from...
Pre-set night temperature
Night from...
Hysteresis
Floor heating ON/OFF
Button lock ON/OFF
13
and MENU. In order to edit particular
Maximum temperature
Minimum temperature
Hysteresis
