en 14 | VDI III | Operation
4. Establish a connection to VDI III in VCI
Manager.
5. Select the "Network setup" tab.
6. In the "Wireless (802.11)" tab, select the
option "Activate wireless interface"
 The "IP address configuration" input field
will become active.
7. Select the option "Automatic assignment
of IP address" if your network assigns IP
addresses automatically.
i
If your network uses fixed IP addresses, your
IT administrator will assign the IP address
and subnet mask.
8. Select <Access Point >>.
9. Assign network name:
$
If the network uses a hidden SSID or is
not within range, "Enter network name
(SSID)" can be used to enter the network
name.
$
If the network is within range, the option
"Select from list of available networks" can
be used to select the network. Use <Up-
date> to have VDI III search for available
WLAN signals.
10. After the network name has been entered,
continue with <Configure>.
11. Enter the security settings for the network,
and select <Next>.
12. Select <Yes> to reconfigure VDI III or <No>
to cancel the procedure.
13. Select the "Settings" tab and check if
VDI III has been configured correctly.
14. By disconnecting the USB connection, you
can check if the configuration has been
successful.
15. Save the settings for future changes.
|
1 689 989 458 2020-01-01
5.4.2 Enabling a direct point-to-point wire-
less connection
VDI III can be configured for a point-to-point wi-
reless connection. The following figure shows a
single diagnostic device connected to a compu-
ter using a point-to-point wireless connection.
The following steps are required to configure
VDI III for a point-to-point connection.
For the descriptions listed below, it is assumed
the computer runs Windows 7. The steps re-
quired may differ depending on the operating
system.
1. Plug the WLAN USB adapter into an availab-
le USB port on the computer.
!
Do not plug the WLAN adapter into a USB hub.
2. Switch on the computer.
3. Use the USB connecting cable to connect
VDI III to the computer, and allow VDI III to
boot completely.
!
Do not connect the USB connecting cable of
VDI III to a USB hub.
4. Start the "VCI Manager" program.
i
The point-to-point connection is automatical-
ly configured. The wireless connection will
be available as soon as power is supplied by
the DLC cable.
