- Page 1 MWL-1300 Wheel-Lok Vehicle Restraint Installation Manual MADE IN U.S.A. This Manual Covers Restraints Built After Serial Numbers: 10HG900001M and up PRINTED IN U.S.A. PUBLICATION NO. 1301 RITE-HITE PRINT SHOP NOVEMBER 2014...
- Page 2 Call your local representative or the Rite-Hite at 414-355-2600. The Rite-Hite products in this manual are covered by one or more of the following U.S. patents: 5,546,623; 5,553,987; 5,582,498; 5,664,930; 5,702,223; 5,762,459 (RE: 37,570); 5,882,167; 6,065,172; 6,070,283; 6,085,375;...
- Page 3 RITE-HITE ® Corporation does not recommend any particular lockout device, but recommends the utilization of an OSHA approved device (refer to OSHA regulation 1910.147). RITE-HITE ® Corporation also recommends the review and implementation of an entire safety program for the Control of Hazardous Energy (Lockout/Tagout). These regulations are available through OSHA publication 3120.
- Page 4 5. Install conduit guard. 20 amp feeder circuit per the current N.E.C. Paragraph 6. Test operation. #430-53. WHEN IN DOUBT, CALL YOUR LOCAL RITE-HITE REPRESENTATIVE OR RITE-HITE AT (800) 456-0600. INSPECT COMPONENTS Open and inspect all materials. Immediately report any damage or material shortage.
- Page 5 See Figure 2. 4. The MWL-1300 vehicle restraint can be installed and shimmed up to 1" without modification. If greater than 1" of shimming is necessary, longer anchors will be required. Please consult RITE-HITE. Pub. No. 1301 - November 2014...
- Page 6 RITE-HITE ® MWL-1300 Installation Manual INSTALLATION INSTRUCTIONS CONTINUED INSTALLATION OVER A TRENCH DRAIN AND SHIMMING INSTRUCTIONS Additional Plate Welded To Base Plate When Base Plate Bridges A Trench Drain. See Note 2 Plate For Center Support Not To Protrude Into Tire Path.
- Page 7 RITE-HITE ® MWL-1300 Installation Manual INSTALLATION INSTRUCTIONS CONTINUED LOCATE THE CENTERLINE LIFTING INSTRUCTIONS 1. Secure a 20' length of string at the lower right edge NOTE: DO NOT FORK BENEATH WHEEL GUIDE! of the dock leveler pit at the dock face. Measure out 1.
- Page 8 RITE-HITE ® MWL-1300 Installation Manual INSTALLATION INSTRUCTIONS CONTINUED Position left wheel guide so left rear corner of rear mounting plate is 184” from bumper face and right Loading Dock rear corner of rear mounting plate is 47.75” from centerline. Position so that right rear corner of front mounting plate is 50.75”...
- Page 9 RITE-HITE ® MWL-1300 Installation Manual INSTALLATION INSTRUCTIONS CONTINUED INSTALL ELECTRICAL COMPONENTS AND SIGNS When working with electrical or electronic • When drilling holes in the box, DO NOT allow controls, make sure that the power source has the drill to go too deeply into the box.
- Page 10 (1) 20 amp feeder circuit per the current N.E.C. maintained between conduit connections by Paragraph #430-53. using ground bushings and a jumper wire. When in doubt, call your RITE-HITE representative or RITE-HITE at (800) 456-0600 Control Box Installation Guidelines - The MWL-1300 vehicle restraint assembly includes Temperature Controlled Applications.
- Page 11 RITE-HITE ® MWL-1300 Installation Manual ELECTRICAL SCHEMATIC (STANDARD) FROM CUSTOMER MAIN POWER & SAFETY PROTECTION DEVICE. 110-120v. 1PH. 60HZ. USE 3.0A DUAL ELEMENT TIME DELAY FUSES SEE NOTE 2 1FU1 (1L1) DUMMY FUSED DISCONNECT SCOM(RD) (BY OTHERS) SEE NOTE 8...
- Page 12 RITE-HITE ® MWL-1300 Installation Manual ELECTRICAL SCHEMATIC (OPTIONS MODULE) NOTE: The standard wiring is not shown in this drawing to better show the option module wiring. For information on standard wiring, see previous page. power module L1 L2 MCOM M1...
- Page 13 Outside lights should change to RED. If light sequence differs from what is described above, check the electrical installation. If the situation can not be resolved, call RITE-HITE for assistance. NEVER leave the job site with the MWL-1300 vehicle...
- Page 14 RITE-HITE ® MWL-1300 Installation Manual NOTES Pub. No. 1301 - November 2014...
- Page 15 RITE-HITE ® MWL-1300 Installation Manual NOTES Pub. No. 1301 - November 2014...
- Page 16 Rite-Hite in writing. In the event of any defects covered by this warranty, Rite-Hite will remedy such defects by repairing or replacing any defective equipment or parts, bearing all the costs for parts, labor, and transportation. This shall be the exclusive remedy for all claims whether based on contract, negligence, or strict liability.
