MWL-1300 Wheel-Lok
This Manual Covers Restraints Built After Serial Numbers:
10HG900001M and up
PRINTED IN U.S.A.
RITE-HITE
PRINT SHOP
Vehicle Restraint
Owners Manual
TM
MADE IN U.S.A.
PUBLICATION NO. 1307
JULY 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wheel-Lok MWL-1300 and is the answer not in the manual?

Questions and answers

Related Manuals for RITE-HITE Wheel-Lok MWL-1300

Summary of Contents for RITE-HITE Wheel-Lok MWL-1300

  • Page 1 MWL-1300 Wheel-Lok Vehicle Restraint Owners Manual MADE IN U.S.A. This Manual Covers Restraints Built After Serial Numbers: 10HG900001M and up PRINTED IN U.S.A. PUBLICATION NO. 1307 RITE-HITE PRINT SHOP JULY 2013...

  • Page 2: Table Of Contents

    Rite-Hite representative. The MWL-1300 vehicle restraint by Rite-Hite is intended to provide a safer workplace for workers in shipping and receiving dock areas. The MWL-1300 vehicle restraint is a restraint device that, when properly installed and operated, retains a secure connection between the truck and dock.

  • Page 3: Safety Warnings

    Rite-Hite Corporation does not recommend any particular lockout device, but recommends the utilization of an OSHA approved device (refer to OSHA regulation 1910.147). Rite-Hite Corporation also recommends the review and implementation of an entire safety program for the Control of Hazardous Energy (Lockout/Tagout).

  • Page 4: Owner Responsibility

    Program (P.M.P.). As part of this service, your local The manufacturer shall publish, provide to the initial Rite-Hite representative will do all routine purchaser, and make the following information maintenance, lubrication, and adjustments. readily available to owners: Dock equipment that is structurally damaged shall •...

  • Page 5: Definition And Function

    RITE-HITE ® MWL-1300 Owner’s Manual DEFINITION AND FUNCTION The MWL-1300 vehicle restraint is a truck and trailer The proper activation of the wheel restraint is monitored locking system used to help secure trucks and trailers to the face of a loading dock. The barrier is deployed in front of the tire after the trailer has been positioned •...

  • Page 6: Features

    RITE-HITE ® MWL-1300 Owner’s Manual FEATURES See Figure 4 for locations of these features. WHEEL GUIDE The main weldment which is bolted onto the approach. It aligns the truck to the dock and also holds the wheel restraint in a locked position.
  • Page 7 RITE-HITE ® MWL-1300 Owner’s Manual Anchor Kit Outside Lights Control Box with Horn Inside Sign Outside Signs Operation Sign Wheel Guide Carriage Stored Sensor Barrier Locked Sensor Barrier Stored Sensor Photo-Eye Barrier Link Barrier Carriage Barrier FIGURE 4 - FEATURES OF MWL-1300...

  • Page 8: Operating Procedures & Testing

    Owner’s Manual. flashing, the Barrier is stored. A truck backs in. When • Call your local representative or RITE-HITE the truck is parked firmly against the bumpers, the at (800) 456-0600 with any questions. operator can now lock the vehicle.
  • Page 9 RITE-HITE ® MWL-1300 Owner’s Manual Restraint LOCKED Restraint UNLOCKING, LOADING If the MWL-1300 vehicle restraint is in the LOCKED OPERATION COMPLETE Button Pressed position (Barrier is down in front the tire), the Light In order to release the truck after completion of the...
  • Page 10 RITE-HITE ® MWL-1300 Owner’s Manual FAULT State From LOCKING State In case the Barrier does not engage properly or if it does not sense a tire, the alarm will sound. The outside and inside lights will show flashing RED. The light communication, alarm and truck position are shown in Figure 7.

  • Page 11: Maintenance (Based On Typical Applications Of 8 Trucks Per Day)

    (extreme climates, corrosive 6. Verify decals are present and legible, replace as chemicals, frequency of usage exceeding 8 required. trucks per day, etc.). Consult RITE-HITE if these conditions exist for accelerated maintenance requirements. NOTE: Your local Rite-Hite representative provides a Planned Maintenance Program (P.M.P.) which...
  • Page 12 RITE-HITE ® MWL-1300 Owner’s Manual Some Items Removed For Clarity Track Coil Cord Support Cable Coil Cord Trolley Wheel Trolley Slider Trolley Carriage Roller Carriage Photo-Eye FIGURE 9 - INSPECTION SENSOR TESTING Unlocked: 3. If switch is adjusted properly, verify switch operation.
  • Page 13 RITE-HITE ® MWL-1300 Owner’s Manual Sensing Switch Test Procedure Mag Res. Sensor: Sensing Switch 1. Locate sensor wires and disconnect. 2. Set multi-meter to Continuity setting. 3. Attach leads to switch wires and place a magnet in Magnet front of switch: a.

  • Page 14: Horn Override Code

    RITE-HITE ® MWL-1300 Owner’s Manual HORN OVERRIDE CODE SETTING HORN OVERRIDE CODE 1. Press and hold DIAGNOSTIC button until horn chirps (approximately three seconds). 2. Enter the factory preset HORN OVERRIDE code:1223. 3. Enter the new HORN OVERRIDE code. The code can be one to four numbers in length.
  • Page 15 RITE-HITE ® MWL-1300 Owner’s Manual LED STATUS CHART LED Inputs LED Outputs STORED (UNLOCKED) LOCKING LOCKED STORING (UNLOCKED) HORN SILENCED SWI = MAG RES 1 (LOCK) ISR = Inside Red Light SW2 = MAG RES 2 (STORED) ISG = Inside Green Light...

  • Page 16: Electrical Schematic

    RITE-HITE ® MWL-1300 Owner’s Manual ELECTRICAL SCHEMATIC (STANDARD) To Customer Power Supply, Ground Terminals 120V, 1PH, 60HZ, 30 AMP. Fused Disconnect with 3 AMP. Dual Element Time Delay Fusing (L2/N) (L1) Supplied By Others. Inside Lights, Horn and Push Button Wiring...
  • Page 17 RITE-HITE ® MWL-1300 Owner’s Manual ELECTRICAL SCHEMATIC (OPTIONS MODULE) NOTE: The standard wiring is not shown in this drawing to better show the option module wiring. For information on standard wiring, see previous page. power module circuit breaker reset button...
  • Page 18 RITE-HITE ® MWL-1300 Owner’s Manual OUTSIDE LIGHT BOX WIRING #40 Wire White Wire Red Wire #42 Wire Red Lamp Black Wire Horn Red Wire Red Wire Green Lamp #41 Wire White Wire Light Box Cover FIGURE 13 - OUTSIDE LIGHT BOX WIRING...
  • Page 19 RITE-HITE ® MWL-1300 Owner’s Manual NOTES Pub. No. 1307 - July 2013...

  • Page 20: Replacement Parts

    RITE-HITE ® MWL-1300 Owner’s Manual WHEEL GUIDE REPLACEMENT PARTS Pub. No. 1307 - July 2013...
  • Page 21 RITE-HITE ® MWL-1300 Owner’s Manual WHEEL GUIDE ASSEMBLY PARTS LIST Order Parts for the restraint that matches your loading dock. Left Side Right Side Part Number Item Description Left Right WHEEL GUIDE 135625 134763 PIN, SPRING ROLL 1/4" X 1-3/4" LONG...
  • Page 22 RITE-HITE ® MWL-1300 Owner’s Manual CARRIAGE REPLACEMENT PARTS 36 34 SEE WHEEL-GUIDE COMPONENTS Pub. No. 1307 - July 2013...
  • Page 23 RITE-HITE ® MWL-1300 Owner’s Manual TROLLEY ASSEMBLY PARTS LIST Order Parts for the restraint that matches your loading dock. Left Side Right Side Part Number Item Description Left Right CARRIAGE ASSEMBLY 135773 135739 (INCLUDES ITEMS: 1, 3, 5, 10, 11, 16, 17, 19, 20)
  • Page 24 RITE-HITE ® MWL-1300 Owner’s Manual BARRIER REPLACEMENT PARTS Order Parts for the restraint that matches your loading dock. Left Side Right Side Part Number Item Description Left Right BARRIER 142107 142105 SWITCH 134808 134808 SWITCH MOUNT 135617 134805 LOCKWASHER 1/4"...
  • Page 25 RITE-HITE ® MWL-1300 Owner’s Manual NOTES Pub. No. 1307 - July 2013...
  • Page 26 RITE-HITE ® MWL-1300 Owner’s Manual ELECTRICAL REPLACEMENT PARTS 0104862 0104860 0104860 0104861 0104861 #14 ga. wire x 5” long with ring terminal existing black wire light base control box Pub. No. 1307 - July 2013...
  • Page 27 RITE-HITE ® MWL-1300 Owner’s Manual ELECTRICAL REPLACEMENT PARTS LIST Item Description Part Number CONTROL BOX ASSM., COMP. (CONSULT RITE-HITE FOR SPECIFIC PART) 103.XXX ELECTRICAL SCHEMATIC DECAL (CONSULT RITE-HITE FOR SPECIFIC PART) 108.XXX LIGHT BULB (#194-INCADESCENT) 55768 INSIDE RED LED 116363...
  • Page 28 RITE-HITE ® MWL-1300 Owner’s Manual MISCELLANEOUS REPLACEMENT PARTS 10” 25-1/4” 8” 8” 4” 4” MWL-1300 Wheel-Lok Vehicle Restraint Owners Manual 12-1/4” 10” MADE E I I N N U.S.A. U.S.A. This Manual Covers Restraints Built After Serial Numbers: ???? and up PRINTED IN U.S.A.
  • Page 29 RITE-HITE ® MWL-1300 Owner’s Manual OPTIONAL EQUIPMENT REPLACEMENT PARTS (Right Side Facing Dock) Also used as optional protective guide for Lefts Side Facing Dock MWL installations. (Left Side Facing Dock) Also used as optional protective guide for Right Side Facing Dock MWL installations.
  • Page 30 RITE-HITE ® MWL-1300 Owner’s Manual NOTES Pub. No. 1307 - July 2013...
  • Page 31 RITE-HITE ® MWL-1300 Owner’s Manual NOTES Pub. No. 1307 - July 2013...

  • Page 32: Warranty

    Rite-Hite in writing. In the event of any defects covered by this warranty, Rite-Hite will remedy such defects by repairing or replacing any defective equipment or parts, bearing all the costs for parts, labor, and transportation. This shall be the exclusive remedy for all claims whether based on contract, negligence, or strict liability.
