- Page 1 Instruction manual Version 16.01 Heat press Big-O-Lite pneu plus Version 16.01 1 / 18...
-
Page 2: Table Of Contents
Introduction Content 1. Introduction 1.1 Content 1.2 Illustration of the heat press 1.3 Technical data 1.4 Exchangeable heating plates 1.5 Exchangeable base plates 1.6 Safety arrangements of the press 1.7 Safety arrangements at the workspace 2. Initiation Tips for transport Installation of the heat press Connection of the press to compressed air Power supply... -
Page 3: Illustration Of The Heat Press
Illustration of the heat press The press table 11. Connector of the heating plate Base 12. Spiral tube Base plate with silicon rubber 13. The drawer Extractable handles for the heating plate 14. Handle to pull out the base plate Heating plate 15. -
Page 4: Exchangeable Heating Plates
Exchangeable heating plates For the press there are several heating plates available. The instruction for the exchange you can find in chapter 3.7. 1. Heating plate 40 x 50 cm 2. Heating plate 50 x 80 cm 3. Heating plate 70 x 90 cm 4. -
Page 5: Safety Arrangements At The Workspace
2.1 Tips for transport The SCHULZE Big-O-Lite is covered in protective foil for transport and fixed onto the pallet. Right after the receiving you should check if the foil and the press are in good condition. Later on, if you have to send the press somewhere, we ask you to fix the press in the same way on the pallet. -
Page 6: Connection Of The Press To Compressed Air
Place the press on the closet and connect it using screws. It will prevent the press from sliding. (photos 8-9) Connection of the press to compressed air The Airpress is a pneumatic press, which has to be connected to compressed air. The maximum pressure inside the press must not exceed 6 bar. -
Page 7: Working With The Heat Press
3. Working with the heat press 3.1 Programming of electronic devices Version 16.01 7 / 18... - Page 8 Pre-pressing To activate the pressing process, press button 1 (confirmation). On the display there's the pre- pressing time 2. After the pre-pressing the adjusted time for the normal pressing appears on the display. Programming of the electronic devices 1. Press button 1 for 5 seconds. The display shows: Temperature.
-
Page 9: Resetting Of The Electronic Devieces
The display shows: Energy-saving-mode. 11. With the buttons + and – you can switch the energy-saving-mode on/off. 12. Press button 1. The display shows: Overall counter. Here you can see the number of all pressing activations. 13. Press button 1. The display shows: Hours of work. -
Page 10: Eco Mode
3.4 „ECO“ mode With the ECO mode you will save power. If the ECO mode 1, 2 or 3 is active, the electronic devices will control the progress of work of the press. If you should have forgotten to turn-off the press, never mind, the ECO mode will deactivate it. In phase 1 of the ECO mode, while the press is momentarily not in use, the temperature will decrease 50°C (a 3 second long acoustic signal will sound). -
Page 11: Exchanging The Heating Plate
3.8 Exchanging the heating plate To exchange the heating plate, the press must be disconnected from electricity and cold. Now disconnect the spiral tube plug of the heating plate. (photos 1-2). Loosen fixation screw with a wrench (photo 3). The heating plate must be placed exactly on the lower plate. Large heating plates have handles for transport. -
Page 12: Maintenance
4. Maintenance 4.1 Daily Maintenance The working surface of the heating plate and the base plate have to be clean. The heating plate can be cleaned with a clean, dry cloth. Avoid contact with the heating plate – risk of burns. The silicon gum can be cleaned with a soft cloth. -
Page 13: Replacing The Power Supply
4.4 Replacing the power supply To exchange the power supply, turn the press off and disconnect it from power first. Unscrew the cover of the press, as in chapter 4.4. Remove the stopper of the power supply (photo 1) and pull out the green plug (photo 2). Replace the power supply (photo 3). Connect the green plug and fasten the power supply in the upper part of the press again. -
Page 14: Replacing The Silicon Mat
4.7 Replacing the silicon mat To exchange the silicon mat the press must be disconnected from the electricity and cold. For the exchange you need a new silicon mat, silicon glue, acetone and a notched trowel. 1. Remove the silicon mat with a knife restless. 2. -
Page 15: Troubleshooting
Reset the electronic devices, but Malfunction of the electronic devices Temperature on the display – Temperature too high/low first contact Walter Schulze GmbH The press heats up very slowly – over 30 minutes One of the tow heating elements is defect... -
Page 16: Connection Diagram
4.10 Connection diagram Version 16.01 16 / 18... -
Page 17: Controlling Of The Pneumatics
4.11 Controlling of the pneumatics Version 16.01 17 / 18... -
Page 18: Testing Report
Berlin , .._____________________________ Peter Meidinger President All SCHULZE machines are exempt from the waste disposal law under reg. no. DE 231060054. Manufacturer ROMANIK, ul. Przemysłowa 10, 84-240 Reda, www.romanik.pl Distributor: Walter Schulze GmbH Haberstraße 15-19, 12057 Berlin, www.schulzeshop.com Version 16.01...
